VL PPC 3000
A configurable industrial computer platform
Data sheet
3386_en_C
1
Description
The VL PPC 3000 is a configurable industrial computer
platform that can be fitted with various display, processor,
memory, and mass storage options. This large combination
of options and convenient form factor allow the VL PPC
3000 to be suitable for countless industrial applications. The
robust modular design simplifies the manufacturing
process, resulting in a high-quality product with fast product
delivery times.
NOTE:
Circuit ground (0 V) and functional earth ground (FE) are connected.
Make sure you always use the latest documentation.
It can be downloaded at phoenixcontact.com.
This document is valid for all products listed in the "Ordering data" on page 2.
© PHOENIX CONTACT 2015-09-29
2
Features
Compact, rugged housing
Flexible mounting options
Wide variety of touch screen display sizes with or
without a USB port
Removable hard-disk drive, solid-state drive and
®
CFast
Two integrated 10/100/1000 Ethernet ports with
independent MAC addresses
Up to 16 GB RAM
Two optional slots allow installation of PCI cards for
direct connection to fieldbus networks or other
applications
USB 2.0 and 3.0 ports
IP65 rating in front panel, IP20 rating in back
data storage options
