CyberView RP-X924 User Manual

24” wuxga 1920x1200 led-backlit lcd
Hide thumbs Also See for RP-X924:

Advertisement

Quick Links

User Manual
Designed and manufactured by Austin Hughes
UM-CV-751-RP-X924-Q124V1
dedicated KVM switch and rackmount screen technology
24" WUXGA 1920 x 1200 LED-backlit LCD
RP-X924
9U Rackmount Display Panel
Options :
- SDI / MCS
- Audio
- Touchscreen / DC power
- MIL-type or lockable connector
www.austin-hughes.com
751

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP-X924 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CyberView RP-X924

  • Page 1 KVM switch and rackmount screen technology User Manual 24” WUXGA 1920 x 1200 LED-backlit LCD RP-X924 9U Rackmount Display Panel Options : - SDI / MCS - Audio - Touchscreen / DC power - MIL-type or lockable connector Designed and manufactured by Austin Hughes UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 3: Table Of Contents

    Contents < Part. 1 > RP-X924 Package Content Structure Diagram & Dimension VESA mount Installation Rear Mounting Bracket Installation < Part. 2 > Specifi cations / OSD Product Specifi cations On-screen Display Operation ( OSD ) < Part. 3 >...
  • Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 5: Rp-X924

    < Part 1 > RP-X924 RP-X924 < 1.1 > Package Content RP-X924 unit X 1 - 6ft VGA cable X 1 - Power adapter X 1 - Power cord X 1 - Fastener screw for rear bracket x 2 < 1.2 > Structure Diagram...
  • Page 6 (W x D x H) Weight 553 x 70 x 385 mm 645 x 155 x 530 mm 11.4 kg 12.7 kg RP-X924 21.8 x 2.8 x 15.2 inch 25.4 x 6.1 x 20.9 inch 25.1 lb 28 lb UM-CV-751-RP-X924-Q124V1...
  • Page 7: Vesa Mount Installation

    < 1.3 > VESA mount Installation RP-X924 M4 screw VESA mount ( 100*100mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 8: Rear Mounting Bracket Installation

    Mount the rear bracket with M6 screw set. ■ 8 x M6 screw set are required. M6 screw sets are not provided. Step ■ Insert the RP-X924 display panel into the rear bracket. Step ■ Fix the unit to the bracket with the top latch. Step...
  • Page 9: Specifi Cations / Osd

    < Part 2 > Specifi cations / OSD RP-X924 < 2.1 > Product Specifi cations LED-backlit LCD Panel Panel Size ( diagonal ) 24.1-inch Widescreen TFT color LED-backlit LCD Display pixel ( dots x lines ) 1920 x 1200 Brightness ( typ. ) Contrast Ratio ( typ.
  • Page 10 640 x 350 x 70Hz HDMI Input * PC Signal Same as VGA Video Signal 1080p : 60Hz 720p : 50 / 60Hz 480p : 60Hz 576p : 50Hz Audio Signal 2ch Linear PCM ( 32 / 44.1 / 48 KHz ) UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 11: On-Screen Display Operation ( Osd )

    < 2.2 > On-screen Display Operation ( OSD ) RP-X924 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control...
  • Page 12 Red / Green / Blue color balance Sharpness : Adjust the image from weak to sharp : Adjust the screen hue value Saturation : Adjust the saturation of the image color Dynamic luminous control : Control the dynamic brightness UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 13 RP-X924 OSD Set Language : Select the language in which the OSD menu is displayed - English OSD H-Position : Align the screen image left or right OSD V-Position : Align the screen image up or down OSD time out...
  • Page 14: Options

    Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
  • Page 15 LCD displays cascade together via CAT 5/6 cable, and daisy chain up to 1,000 meters. Designed for use with CyberView LCD displays, Austin Hughes provides a MCS input module without using additional space or power and it comes standard with a 2-year warranty.
  • Page 16 Audio Audio Power DVI-D Video BNC-HDMI Option - BNC - HDMI ( HDMI 1.4, HDCP 1.4 ) - Audio ( Audio input & output ) Audio Audio Power Video HDMI Either HDMI or DVI-D can be selected. P.12 UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 17 < 3.4 > Options : Touchscreen & driver RP-X924 Resistive 1-pt Touchscreen Specifi cation Model e-Resistive Technology 5-Wire Resistive Touch Point Single Input Type Finger or Stylus Resolution 2048 x 2048 Touch Point Accuracy Response Speed 15 ms Activation Force ≤...
  • Page 18 Step 2. Double click the Setup.exe Step 3. Follow the installation instruction to fi nish the setup Step 4. After installation, run the TouchKit program & the “4 point calibration” Please do the initial calibration after the fi rst setup P.14 UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
  • Page 19 < 3.5 > Options : DC Power RP-X924 Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load...
  • Page 20: Mil-Type Or Lockable Connector

    The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2024 Austin Hughes Electronics Ltd. All rights reserved. P.16 UM-CV-751-RP-X924-Q124V1 www.austin-hughes.com...
