CyberView RP-HW719 User Manual

19” widescreen high brightness lcd
Hide thumbs Also See for RP-HW719:

Advertisement

Quick Links

User Manual
Designed and manufactured by Austin Hughes
UM-CV-751-RP-HW719-Q322V1
dedicated KVM switch and rackmount screen technology
19" Widescreen High Brightness LCD 1000 cd/m²
RP-HW719
7U Rackmount Display Panel
Options :
- SDI / MCS
- AV / HDMI / Audio
- Touchscreen / DC power
- MIL-type or lockable connector
www.austin-hughes.com
751

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP-HW719 and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberView RP-HW719

  • Page 1 KVM switch and rackmount screen technology User Manual 19” Widescreen High Brightness LCD 1000 cd/m² RP-HW719 7U Rackmount Display Panel Options : - SDI / MCS - AV / HDMI / Audio - Touchscreen / DC power - MIL-type or lockable connector...
  • Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
  • Page 3: Table Of Contents

    Contents < Part. 1 > RP-HW719 Package Content Structure Diagram & Dimension Installation < Part. 2 > Specifi cations / OSD Product Specifi cations On-screen Display Operation ( OSD ) < Part. 3 > Options 3G / HD / SD-SDI Broadcast-grade input Multi display OSD controller ( MSC ) AV4.4, HDMI, S-Video + BNC, Audio...
  • Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
  • Page 5: Rp-Hw719

    < Part 1 > RP-W719 < 1.1 > Package Content RP-HW719 RP-HW719 unit X 1 - 6ft VGA cable X 1 - Power adapter X 1 - Power cord X 1 < 1.2 > Structure Diagram Front view Power adapter...
  • Page 6 (W x D x H) Weight 480 x 58 x 310 mm 529 x 124 x 495 mm 5.8 kg 7.9 kg RP-HW719 18.9 x 2.3 x 12.2 inch 20.8 x 4.9 x 19.5 inch 12.8 lb 17.4 lb UM-CV-751-RP-HW719-Q322V1...
  • Page 7: Installation

    < 1.3 > Installation RP-HW719 Step ■ Mount the display panel with M6 screw set. ■ M6 screw x 4 pcs required ( Left & right side ). M6 screw sets are not provided. Step ■ Fix the LCD into the rack.
  • Page 8: Specifi Cations / Osd

    Auto-sensing 100 to 240VAC, 50 / 60Hz Power Consumption Screen ON Max. 34W Power saving mode Max. 2W Power button OFF Max. 1W Compliance FCC & CE Safety CE / LVD & UKCA Environmental RoHS3 & REACH / WEEE UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
  • Page 9 RP-HW719 Environmental Operating Temperature 0 to 55°C degree Conditions Humidity 10~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random Physical...
  • Page 10: On-Screen Display Operation ( Osd )

    ( a ) Press the button to call up the on-screen video mode on top right corner. ( b ) Use up/down arrow to the select the video input ( c ) Press the button to confi rm the selection UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
  • Page 11 < 2.2 > On-screen Display Operation ( OSD ) RP-HW719 Picture Brightness : Adjust the screen brightness Contrast : Adjust the diff erence between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen...
  • Page 12: Options

    Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
  • Page 13 LCD displays cascade together via CAT 5/6 cable, and daisy chain up to 1,000 meters. Designed for use with CyberView LCD displays, Austin Hughes provides a MCS input module without using additional space or power and it comes standard with a 2-year warranty.
  • Page 14: Av4.4, Hdmi, S-Video + Bnc, Audio

    ( HDMI 1.4, HDCP 1.4 ) - Audio ( Audio input & output ) BNC Option - BNC ( Composite, BNC ) - Audio ( Audio input & output Audio DVI-D Power HDMI out - in - in Video PC P.10 UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
  • Page 15 < 3.4 > Touchscreen & driver RP-HW719 Resistive 1-pt Touch screen Specifi cation Model e-Resistive Technology 5-Wire Resistive Touch Point Single Method Stylus or Finger Activation Force ≤ 50g / Stylus=R0.8 Durability 10 million touches Response Time 15 ms Optical Transmittance 80% ±...
  • Page 16 600 mA Output rating Output voltage: 12-Volt 12-Volt 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.16A 6.25A 12.5A Effi ciency For DC power option : ( 1 ) If the unit with LCD, earthing may be required P.12 UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
  • Page 17: Mil-Type Or Lockable Connector

    < 3.6 > MIL-type or Lockable Connector RP-HW719 Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl...
  • Page 18 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2022 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-RP-HW719-Q322V1 www.austin-hughes.com...
