User Manual
Designed and manufactured by Austin Hughes
UM-CV-751-RP-F719-Q421V1
dedicated KVM switch and rackmount screen technology
19" FHD 1080p LCD
RP-F719
7U Rackmount Display Panel
Options :
- SDI / MCS
- HDMI / DP / Audio
- DC power
- MCS
- MIL-type or lockable connector
www.austin-hughes.com
751
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CyberView RP-F719
Summary of Contents for CyberView RP-F719
- Page 1 KVM switch and rackmount screen technology User Manual 19” FHD 1080p LCD RP-F719 7U Rackmount Display Panel Options : - SDI / MCS - HDMI / DP / Audio - DC power - MCS - MIL-type or lockable connector...
- Page 2 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-RP-F719-Q421V1 www.austin-hughes.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > RP-F719 Package Content Structure Diagram Dimension Installation < Part. 2 > Specifi cations / OSD / Remote Controller Product Specifi cations On-screen Display Operation ( OSD ) < Part. 3 > Options 3G / HD / SD-SDI Broadcast-grade input P.10... - Page 4 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-RP-F719-Q421V1 www.austin-hughes.com...
-
Page 5: Rp-F719
< Part 1 > < 1.1 > Package Content RP-F719 RP-F719 unit X 1 - 6ft VGA cable X 1 - Power adapter X 1 - Power cord X 1 < 1.2 > Structure Diagram Front view Rear view Power adapter... -
Page 6: Dimension
(W x D x H) Weight 480 x 57.5 x 310 mm 529 x 124 x 451 mm 5.8 kg 7.9 kg RP-F719 18.9 x 2.3 x 12.2 inch 20.8 x 4.9 x 17.8 inch 12.8 lb 17.4 lb UM-CV-751-RP-F719-Q421V1... -
Page 7: Installation
< 1.3 > Installation RP-F719 Step ■ Mount the display panel with M6 screw set. ■ M6 screw x 4 pcs required ( Left & right side ). M6 screw sets are not provided. Step ■ Fix the LCD into the rack. -
Page 8: Product Specifi Cations
Environmental Operating Temperature 0 to 55°C degree Humidity 20~90%, non-condensing Conditions Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random UM-CV-751-RP-F719-Q421V1 www.austin-hughes.com... - Page 9 RP-F719 Physical Product ( W x D x H ) 480 x 57.5 x 310 mm Specifi cation 18.9 x 2.3 x 12.2 inch Packing ( W x D x H ) 529 x 124 x 451 mm 20.8 x 4.9 x 17.8 inch Net Weight 5.8 kg / 12.8 lb...
- Page 10 Intentionally Left Blank UM-CV-751-RP-F719-Q421V1 www.austin-hughes.com...
-
Page 11: On-Screen Display Operation ( Osd )
< 2.2 > On-screen Display Operation ( OSD ) RP-F719 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control... - Page 12 OSD time out : Adjust the screen timeout OSD transparency : Adjust the screen transparency OSD size : Adjust the screen size - Normal / Small OSD rotation : Rotate the screen - 90° / 180° / 270° UM-CV-751-RP-F719-Q421V1 www.austin-hughes.com...
- Page 13 RP-F719 Reset Reset : Return the adjustment back to factory setting PIP ( Not Applicable to F17 / MF17 ) PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) /...
- Page 14 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
- Page 15 LCD displays cascade together via CAT 5/6 cable, and daisy chain up to 1,000 meters. Designed for use with CyberView LCD displays, Austin Hughes provides a MCS input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 16 USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc ■ For detailed information, please refer to the attached CD disc ■ As the touchscreen unit is not made of toughened glass, please handle it carefully UM-CV-751-RP-F719-Q421V1 P.12 www.austin-hughes.com...
- Page 17 < 3.4 > Options : Touchscreen & driver RP-F719 Audio Power HDMI-1.4 DVI-D Video PC USB Touchscreen Please follow the below steps to setup the touch screen:- Step 1. Run the bundled CD disc or download the driver from the link below : http://www.austin-hughes.com/resources/driver/rackmount-display...
- Page 18 1220 mA 749 mA Output rating Output voltage: 12-Volt 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.16A 6.25A Effi ciency For DC power option : ( 1 ) If the unit with LCD, earthing may be required UM-CV-751-RP-F719-Q421V1 P.14 www.austin-hughes.com...
-
Page 19: Mil-Type Or Lockable Connector
< 3.6 > Options : MIL-type or Lockable Connector RP-F719 Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl... - Page 20 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2021 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-RP-F719-Q421V1 P.16 www.austin-hughes.com...
