- Page 1 Wet and dry vacuum cleaner V V V V V entos 25 entos 25 entos 25 entos 25 entos 25 V V V V V entos 35 entos 35 entos 35 entos 35 entos 35...
-
Page 2: Dear Customer
- Vehicles - Building sites - Furniture - Buildings - Containers, etc. Technical Kränzle Kränzle specifications Ventos 25 Ventos 35 Power intake 350 - 1.200 W 350 - 1.200 W Mains voltage 230V 50/60 Hz 230V 50/60 Hz Admissible voltage range 220 - 240 V;... - Page 3 Description 7 . 1 Construction The KRÄNZLE VENTOS 25 / 35 are mobile machines. The construction is shown in the plan. Function Accessories box Suction hose Brake Suction handle 1 0 Lock slide for accessories box Front nozzles 1 1 Lock bracket for accessories box...
-
Page 4: Correct Use
Description Correct use The vacuum cleaners are designed for vacuuming non-hazardous dust, dirt, sand, chips etc. The cleaners are also suitable for vacuuming water. The cleaners are suitable for heavy-duty use as set forth in EN 60335-1 and EN 60335-2-69. The appliances have been inspected by TÜV Eschenborn in accordance with the CB procedure and also bear the GS and CE symbols. - Page 5 Description Accessories box All Ventos 25 and Ventos models are equipped with an accessories box (8) for convenient storage of both the vacuum accessories and the power cable. The box has two locking slides (10) - one on the front side and the other at the rear of the cleaner - fitted to the open surface of the suction head.
- Page 6 Description Storage bin (only on Ventos 35) The Ventos 35 is equipped with a storage bin (7). This offers convenient space for vacuuming utilities and other work materials. This bin is opened with a handle (7.1). Brake The brake (9) is used to lock the wheels and prevent th cleaner from rolling away out of control.
-
Page 7: Suction Hose
Description Suction hose The standard suction hose (1) is 3.5 m long and has a coupling at both ends. The larger coupling is fitted into the suction opening (4) of the vacuum. The somewhat thinner coupling is used to accommodate the suction nozzles or to connect the suction pipe. -
Page 8: Safety Instructions
Safety Instructions Safety Instructions - Only use accessories approved by Kränzle - Never vacuum combustible or explosive dust (eg, magnesium, aluminium etc.) - RISK OF EXPLOSION!!! - Never vacuum combustible or explosive liquids (eg, petrol, paint thinners etc.) - RISK OF EXPLOSION!!! - Never vacuum aggressive liquids or solid matter (acides, lyes, solvents etc.). - Page 9 You have purchased all this: 1. KRÄNZLE - Wet/dry vacuum cleaner Ventos 25 / Ventos 35 1. Suction hose ∅ ∅ ∅ ∅ ∅ 36mm x with accessories box 3 . 5 m 2. Suction handle 3. Suction nozzle set...
- Page 10 Assemble and configure the cleaner Fit extension Unlock suction handle by pushing red button into direction of arrow (1). Insert the extension into the suction handle (2). Attach the suction handle holder Fit a square nut (E) into the Hold the suction handle holder outer recess (F) on the rear of from behind against the cleaner the cleaner.
- Page 11 Start-up 1. Take the power cable, suction hose and nozzles out of the accessories box 2. Connect the suction hose to the suction aperture 3. Lay out the suction hose without kinks...
- Page 12 Start-up 4. Connect the hose to the suction handle First put the hose through the sling, then pull it through the guide tunnel and plug it into the nozzle holder. or 4 a) Connect the hose to the reduction piece 5.
-
Page 13: Compressed Air
Start-up Vacuuming dry material Put a filter bag in the container before starting the cleaner. The filter element will be wet after vacuuming wet material. A damp filter element blocks quicker when vacuuming dry matter. For this reason you should always use a dry filter element when vacuuming dry material. - Page 14 Handling Opening/closing the cleaner To change the filter bag or remove the dirt container you must first open the cleaner. To open the cleaner, slacken the locking brackets (13) on both sides of the cleaner and swivel the top part (23) upwards until the lug (20) engages.
-
Page 15: Changing The Filter Bag
Handling Changing the filter bag To change the filter bag first open the cleaner. Remove filter bag cap Close the opening with Lift the bag out of the dirt from suction orifice the plastic cap. chamber and dispose of it (see print on bag). -
Page 16: Emptying The Dirt Container
Handling Emptying the dirt container To empty the dirt container, first open the cleaner. Take out the container Lift the lid slightly from ... and pull it backwards and dispose of the the rear ... out of the container. contents responsibly. Replace the container in the cleaner. - Page 17 Handling Removing the suction head To empty the dirt chamber, first take off the top part of the cleaner - the suction head. Taking off the suction head Open the cleaner (see page 11). Lift the top part (23) slightly and press the lug (20) from the side.
- Page 18 Handling Changing the filter elements Open the cleaner. Remove the filter Clean the dirt chamber Press the locking buttons element and dispose and the space around of the filter cassette. Tilt of it responsibly. the suction turbine the cassette downwards. (wipe with a damp cloth).
- Page 19 What you must never do Never put the nozzles, suction pipes and hose close to your eyes or ears when using the cleaner! Do not damage the cable or repair it incorrectly! Do not loop or kink the hose or cable! Never pull the hose or cable over sharp edges!
- Page 20 Automatic power-up Automatic power-up Automatic power-up Order number 58 405 1 Additional dirt container Additional dirt container Additional dirt container Additional dirt container Additional dirt container Ventos 25, order number: 45 302 9 Ventos 35, order number: 45 303 0...
- Page 21 (eg, brass and Cleaning carpets and other floor surfaces aluminium) by simply changing the dirt with the carpet nozzle container. (Ventos 25 order number: 45 302 (order number 58 401 8) 9 Ventos 35 order number: 45 303 0)
- Page 22 Complete cleaner...
- Page 23 KRÄNZLE VENTOS 25 / 35...
- Page 24 Cover...
- Page 25 KRÄNZLE VENTOS 25 / 35...
- Page 26 Turbine...
- Page 27 KRÄNZLE VENTOS 25 / 35 Turbinengehäuse 45 306 3 Dämmatten Turbine (5-teilig) 45 277 9 Netzanschlußkabel 45 235 7 Zugentlastungsschelle 45 306 4 Anschlußklemme 45 209 9 Deckel Klemmkasten 45 306 5 Turbinengehäuse 45 306 6 Dichtungen Luftkanal (3-teilig) 45 306 7...
- Page 28 Chassis...
- Page 29 KRÄNZLE VENTOS 25...
- Page 30 Chassis...
- Page 31 KRÄNZLE VENTOS 35...
-
Page 32: Dirt Container
Dirt container... - Page 33 KRÄNZLE VENTOS 25 / 35...
- Page 34 Suction handle...
- Page 35 KRÄNZLE VENTOS 25 / 35...
- Page 36 KRÄNZLE VENTOS 25 / 35...
-
Page 37: Circuit Diagram
Circuit diagram... -
Page 38: Servicing And Care
Servicing and Care CAUTION!!! Always remove the plug from the electrical socket before carrying out servicing and care work!!! Servicing and care All servicing and repair work requiring the cover of the motor to be opened may only be carried out by authorised customer-service workshops. Electrical inspections must be carried out in accordance with the accident prevention rules (VBG 4) and DIN VDE 0701 parts 1 and 3. -
Page 39: Ec Declaration Of Conformity
High-pressure-cleaners Nettoyeurs À Haute Pression I. Kränzle GmbH Elpke 97 . 33605 Bielefeld EC declaration of conformity Herewith we declare Kränzle Ventos 25 that Kränzle Ventos 35 comply with the following Maschinenrichtlinie 89/392/EWG provisions applying to it Niederspannungsrichtlinie 73/23 EWG EMV-Richtlinie 89/336 EWG Lärmrichtlinie 2000/14/EG... - Page 40 Reprint only allowed with the authorization of As date of 23. 11. 2004...
