DSPPA MAG6104C Datasheet

Description
The 1-channel network audio output terminal is a fully digital analog-to-digital signal processor based on
TCP/IP transmission protocol, designed with a single network port, which can be mounted in any place
where the network can reach. The machine can output audio signals through remote audio data streams,
which can be intelligently controlled by the host; it is provided with an emergency audio input interface for
connecting the emergency signals of the fire center, and an emergency audio output interface for
connecting the emergency amplifier; requiring no local control, it can be used after the proper remote
configuration through the management software.
Features
 Can be mounted in any place where the network can reach, and support LAN.
 Support the decoding of 16-bit digital audio stream with the maximum sampling rate of 48KHz.
 Can broadcast background music, timed tasks, emergency paging, alarm signals, etc. from the system
host.
 With one-channel auxiliary audio input interface for expanding the local program source.
 With one-channel auxiliary audio output interface for connecting an amplifier for sound reinforcement.
 With 4 LED state indicators, it can display the terminal power state, server connection state, and
network audio stream state, as well as local audio output state, so that the working state of the
equipment can be seen at a glance.
 Support remote modification of the network parameters of the machine through the web page.
 It is designed to be 1U in height, and up to 4 units can be assembled on the cabinet for space-saving
installation.
Specifications
LINE IN
export@dsppa.com /
1-Channel Network Audio Output Terminal
Test Items
CH1 Rated Output
Input Sensitivity
www.dsppatech.com
MAG6104C
MAX:
MIN:
The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd. All rights reserved.
Indicator Parameters
1V
4V
250mV
