- Page 1 Signal User Manual Thank you for using our DSPPA public address system. Please read this User Manual carefully to make better use of this equipment. G u a n g z h o u D S P PA A u d i o C o . , L t d .
- Page 2 About the instructions The instructions are used from the development completion date of the poe public address display MAG6401 The instructions include product introduction, precautions for terminal use, instructions for system connection, instructions for product use, and technical indicators of the product and other contents of the four-way network public address terminal.
- Page 3 Precautions Please carefully read the following careful prior to operation and use. Warning In order to avoid the possible personal injuries, equipment or property loss to you and others surrounding, please comply with the following basic precautions. These precautions include but are not limited to the following cases: Power / power cord damages to the internal components, do not •...
- Page 4 metal) from inserting or falling into any gap or opening of the equipment. If it happens, please immediately disconnect the power supply. • Do not press the body on the equipment, or place any heavy object on it. Avoid overexertion during button or switch operation or machine connection.
-
Page 5: Table Of Contents
2.3 Instructions for remote controller structure ....................4 III. Connection legend ............................. 6 3.1 Schematic diagram of application of POE6401 terminal in the system ............6 3.2 Schematic diagram of connection of interface of POE6401 terminal ............6 IV. Instructions for use and operation ......................... 8 Packing list ................................ -
Page 6: Product Description
I. Product description 1.1 About POE6401 display terminal POE6401 network display terminal is a networked all-digital analog-digital conversion signal processor based on TCP/IP transmission protocol, which adopts the dual network redundancy design, and can be coupled at any place with access to network. The remote audio data stream can output the audio signal through the machine with intelligent control of the host machine;... -
Page 7: Description Of The External Appearance
When the local MP3 program is played, the key 4 Timing is used to conduct play / pause operation; during address settings, the key is used to save setting The terminal can be separated from the host POE6401 Network Display terminal... -
Page 8: Introduction Of The Side Panel
请勿打开,以免触电 MIN MAX MIC1 MUTE AUX OUT IN- IN+ A 广州市迪士普音响科技有限公司 POE LAN Guangzhou DSPPA Audio Co.,Ltd. Figure (2) Side panel POE LAN player. Micro SD Connect 48V output, support AT mode, POE output port power outputs above 25.5W POE... -
Page 9: Instructions For Remote Controller Structure
Press Enter key to adjust output at the idle state Bass components (circulating adjustment from 0 to 15) 8. Next track selection key: CH- is used to select the next program of the current track. Figure (3) POE6401 Network Display terminal... - Page 10 Select the audio source to be modified. Press V+ and V- to modify the volume after selection. (AUX1 is auxiliary input, MIC1 is microphone input, and MP3 is network audio source or U disk) 13. Standby key POE6401 Network Display terminal...
-
Page 11: Connection Legend
Signal Signal Note: 1. Only the schematic description for connection of rough application of POE6401 terminal is made in the above figure. For connection of the whole system, please refer to operation instructions for the networked control host. 2. It is illustrated by examples in the above figure. For specific connections, please refer to the schematic diagram of system connection. - Page 12 MIC1 IN- IN+ A Power amplifier The power amplifier is 2×10W output (note: please adopt two-way simultaneous output with caution due to POE switch supply power restrictions), which is as follows: Connect 4Ω, constant resistance sound POE6401 Network Display terminal...
-
Page 13: Instructions For Use And Operation
U disk cannot be played. Because the priority level of the host machine is higher than that of U disk. Note: turn off the power supply during SD card swapping. Otherwise, it may damage SD card; when the nixie tube displays "err", it indicates invalid operation. POE6401 Network Display terminal... - Page 14 Please properly keep the instructions and warranty card. For the non-mentioned problem or precautions in the instruction, please contact the dealer or visit our company's web page http://www.DSPPA.com; http://www.dsppatech.com In case of failure in the warranty period, please contact our company's service personnel (or contact the dealer) for repair or handling.
-
Page 15: Packing List
1 copy Guarantee card 1 copy Conformity certificate 1 copy 7P green plug 3.81MM plug 1 set 4P green plug 3.81MM plug 2 sets AMP crystal head 8P8 2 pieces Gold 3.5MM audio plug 1 pieces POE6401 Network Display terminal... -
Page 16: Performance Specifications
Noise Signal-to-noise ratio Capacity of external U disk supported 32GB Range of power supply voltage 45-256V/50Hz OVERCURRENT, overheat, over-voltage Conforming to under-voltage protection Package size (L×W×H mm) 270×210×110 Machine size (L×W×H mm) 190×195×50 Net weight 1.45kg POE6401 Network Display terminal... - Page 17 Therefore, it is required to place the power socket at the position convenient for swap operation of the power cord. Guangzhou DSPPA Audio Co., Ltd.
