User Manual
Thank you for using our DSPPA public address system. Please read this User Manual carefully to make better
use of this equipment.
100V Network Terminal
VOL+
Net Service
Timing
Signal
USB
F1
Set
VOL-
Public Address System
100V Network Terminal MAG6701
STBY
100V Backup
Protect
Guangzhou DSPPA Audio Co., Ltd
MAG6701
http: //www.dsppatech.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DSPPA MAG6701
Summary of Contents for DSPPA MAG6701
- Page 1 Net Service STBY Timing 100V Backup Signal Protect VOL- User Manual Thank you for using our DSPPA public address system. Please read this User Manual carefully to make better use of this equipment. Guangzhou DSPPA Audio Co., Ltd http: //www.dsppatech.com...
- Page 2 This page is left blank for the user’s notes.
- Page 3 About this User Manual This User Manual is available and effective upon completion of development of the 100V Network Terminal MAG6701. The User Manual includes system description, matters needing attentions in use, instructions on system connection, instructions on use of product and technical specifications of the terminal.
- Page 4 Matters needing attention Please read the following before operating the product. Warning The following basic requirements must be strictly observed, to avoid potential personal injury and equipment or property damages to you or any person nearby. The basic requirements include without limitation to the following: Power source/power cable When abnormal conditions are realized...
-
Page 5: Table Of Contents
2.1 Front panel..............................2 2.2 Side panel................................3 2.3 Introduction to remote controller........................5 3. Connection Diagram..............................6 3.1 Application of MAG6701 in Network PA system..................6 3.2 MAG6701 connection diagram........................6 4. Operation Instruction..............................8 5. Installation.................................8 6. Operating Instructions for Setting Up the Terminal on the Host Computer............9 6.1 IP Address Setting............................9... -
Page 6: Product Description
Product Description About MAG6701 network terminal MAG6701 100V Network terminal is a network full digital analog-digital signal conversion processor based on TCP/IP communication protocol. Dual-network redundancy design makes it possible to any place where there is network. Remote digital data flow could export audio signal through this device, which is controlled by host. -
Page 7: Description Of Appearance
Network PA System Description of Appearance 2.1 Front panel 100V Network Terminal MAG6701 VOL+ Net Service STBY Timing 100V Backup Signal Protect VOL- 1 2 3 4 5 6 10 11 12 13 14 15 16 Pic. (1) Front panel signal output from this terminal. -
Page 8: Side Panel
AUX lN 100V 100V COM SC ~220V/50Hz POWER /100W 警告 MIC2 MIC1 AUX OUT 请勿打开，以免触电 广州市迪士普音响科技有限公司 Guangzhou DSPPA Audio Co.,Ltd. Pic. (2) Side panel LAN1 LAN2 USB Disk Micro SD AUX lN 100V 100V COM SC MIC2 MIC1 AUX OUT... - Page 9 Network PA System Network interface (LAN1/LAN2) On-demand terminal connection interface Dual Network design to connect with Network To connect with on-demand terminal by using POE. 8-core Network cable. Connection instruction please refer to User Manual of on-demand terminal. USB interface (USB Disk) 9 MIC2 interface Insert U disk or mobile hard disk with MP3 program inside to provide MP3player with program.
-
Page 10: Introduction To Remote Controller
Introduction to remote controller The structure of the remote controller is as shown on the right: 1. Mute. 2. Numbers: To set IP address and parameters. 3. F5: After inserting U disk, press F5 to play and stop. 4. Previous one CH+ is used to play previous program. -
Page 11: Connection Diagram
VOL- Note: This diagram is only the application diagram of MAG6701. As for the connection diagram of the whole system please refer to user manual of network PA system control host. This diagram is only one example. As for specific connection method, please refer to system connection diagram. - Page 12 100V MIN MAX AUDIO OUTPUT MIC1 MUTE EMC OUT AUX OUT IN- IN+ A ~220V/50Hz/10A 广州市迪士普音响科技有限公司 Guangzhou DSPPA Audio Co.,Ltd. Connect to a 60W speaker Amplifier Note: 100V output and input cable cannot be tangled together to avoid signal interference.
-
Page 13: Operation Instruction
4. Operation Instruction 1. Volume adjustment: Press “VOL+” or “VOL-” to adjust playing volume. Press “F1” to switch between volumes of different audio source. Audio source options are AUX.1, MIC.2, MP3.3 (“AUX.1” is input volume. “MIC.2” is acquisition volume. “MP3.3” is volume of AUX OUT output.) After setting, it will go to countdown status automatically. -
Page 14: Operating Instructions For Setting Up The Terminal On The Host Computer
6. Operating Instructions for Setting Up the Terminal on the Host Computer 6.1 IP Address Setting This speaker can be customized to modify the network parameters. Please read this section in detail if you need to use this function. The alteration methods are as follows: Method 1：... -
Page 15: Instruction For The Terminal Function Setting
(Pic. 2) Instruction for the Terminal Function Setting As the Method 1 in 6.1 above, it ensures host computer/ computer and the terminal in the same network segment, and input the IP address of the terminal on IE browser to get into the following page, and then click “Public Address”... - Page 16 the function, select "Enable "option and press the" Submit "button; instead, select" Disable "option. 100V constant voltage backup function: a. Without network; if chose “Enable” before, when the network play is abnormal or the terminal drops, it will switch to 100V audio signal automatically; if chose “Disable”...
- Page 17 Safety Precautions 1. Safety Precautions Please do NOT connect this device to the power source, before the system is correctly wired. It is important to ensure that input voltage to the device is the same as required voltage of the device, ...
-
Page 18: Packing List
Packing List List Quantity MAG6701 1 set 1500MM/AV terminal audio cable 1 pc 3000MM/8-core network cable 1 pc User Manual 1 copy Warranty card 1 copy Certificate 1 copy 7P green plug 3.81MM plug 1 set 8P green plug 2.54MM plug... -
Page 19: Specification
Specification Indicator item Indicator Input sensitivity ±30mV Frequency response 80Hz-16kHz(±3dB) AUX IN Distortion ≦1% Noise Signal-to-noise ratio ≥77 Input sensitivity 1000m ±100mV Frequency response 35Hz-20KHz(±3dB) AUX OUT Distortion 0.1% Noise 0.12 Signal-to-noise ratio ≥77 Maximum output power of the built-in Single channel mode 60W/160Ω... - Page 20 ● This is connected to power source via the plug and any failure or danger occurs, the user can disconnect the device from power source by pulling out the plug out from the socket, therefore, it is required that the power socket should be located somewhere with easy access. Guangzhou DSPPA Audio Co., Ltd.
