- Page 1 MAG6402 Directions for Use Thank you for choosing DSPPA PA System. To ensure better use of the equipment, please read this manual carefully before usage. G u a n g z h o u D S P PA A u d i o C o . , L t d .
-
Page 2: About The Instructions
About the instructions The instructions are used from the development completion date of the Network PA System On-Demand Terminal MAG6402. The instructions include product introduction, precautions for use, instructions for system connection, instructions for product use, and technical indicators of the product and other contents of the Network PA System On-Demand Terminal. -
Page 3: Introduction Of Main Menu
Network PA System On-Demand Terminal 1. Features Touch panel control, luxurious design, TFT true color screen display; Equipped with the basic operation functions of the host, including audio source choosing and etc; Can play the files chosen by the host, and also can choose the files that stored in the terminal for play;... -
Page 4: Zone Paging
Network PA System On-Demand Terminal 3. Instructions File choosing, playing mode, volume control, download and refresh file list, paging and system setting can be realized by touching the corresponding button on the main interface. Remark: When receiving host paging, host emergency alarm, telephone override, and paging between terminals, the on-demand terminal will enter the correspondent interface. -
Page 5: Playlist Setup
Network PA System On-Demand Terminal 2. Playlist setup: Click the playlist button on the interface, as shown below. Select the server song directory, and click the “Add” button, and then the song can be added to the local directory. When you want to delete a song, you can remove it, or move up and down. - Page 6 Network PA System On-Demand Terminal 4. Dimension Dimension of the front panel Inlet hole Dimension of the package box 5. Connection The On-demand terminal and the Output only terminal can be connected by the network cable. The network cable and the 8-pin cable should be connected as below: 8-pin port plug 棕...
- Page 7 Network PA System On-Demand Terminal 8-pin data plug 8位数据插头 棕白 Brown/white 棕 Brown 蓝-蓝白 Blue-Blue/white 橙 - 橙白 Orange-Orange/white 12-24V color on-demand terminal Green terminal connection port of the network terminal Note: The brown/white cable corresponds to the terminal A of the color on-demand terminal, the brown cable corresponds to terminal B, the blue and blue/white cables correspond to COM terminal, and the orange and orange/white cables corresponds to voltage terminal (12V-14V).
-
Page 8: Remote Controller
Network PA System On-Demand Terminal 6. Remote controller Please find below the control panel of the remote controller. 1. Stand-by 2. Catalogue Selection 3. Page Up/ Page Down 4. Play 5. Previous/ Next File 6. File Selection 7. Volume Control 8. -
Page 9: Specification
Network PA System On-Demand Terminal Specification Item Index Input Voltage DC24V Input Current（24V） ≤100mA Power Consumption ≤3W Standby Power ≤1.5W Consumption Infrared Ray Control ≥10M Distance Line Transmission ≥300M Distance Data Interface RS485 Play Mode, Volume Control, Zone On/Off, File Selection, Screen Calibration, Functions Paging, etc Display Screen... - Page 10 Therefore, it is required to place the power socket at the position convenient for swap operation of the power cord. Guangzhou DSPPA Audio Co., Ltd.
