2x2 Dante Audio Terminal DT2200 DT2200 2X2 Dante interface INPUT OUTPUT POWER User's Manual Welcome to use DSPPA public address system. For the better use of this product, please read this instruction carefully prior to use. Guangzhou DSPPA Audio Co., Ltd http://www.dsppatech.com...
Page 2
2x2 Dante Audio Terminal Caution To assure the finest performance, please use or operate the product in accordance with corresponding instructions. This symbol indicates "forbidden content" This symbol indicates "compulsory content" ■ Please make sure that the ■ When the equipment is in use, DO NOT block the air power wire is NOT damaged.
6. Construction of the whole system and matters needing attention .........................29 6.1 Construction of the whole system ............. 34 6.2 How to use control software of other brand to control DSPPA Dante devices ................................37 Safety Precautions ..............................37 Matters needing attention ...................................
1. Product Introduction 1.1 About DT2200 DT2200 is the Hi-Fi audio terminal included in a distributive system and adopts the digital audio transmission technology through Dante LAN network. The matrix function is realized when we utilize the local input and the output of another Dante device simultaneously.
2.Description of Appearance 2.1 Description of Front Panel DT2200 2X2 Dante interface INPUT OUTPUT POWER 1. Input Indicator 3. Power Indicator The indicator is on while there is any line input The indicator is on while being electrified 2. Output Indicator The indicator is on when there is any line output 2.2 Description of Rear Panel...
3.1 System connection diagrams Correct connection 1 Dante MIC DT4200E Gigabit Network Standard +48V POE switch CAUTION! RISK OF ELECTRIC SHOCK DO NOT OPEN Guangzhou DSPPA Audio Co.,Ltd. LINE LINE DATA/POE ( +48V ) CH1 IN CH2 IN CH1 OUT CH2 OUT...
Page 7
Wrong connection 2 DT2200 CAUTION! RISK OF ELECTRIC SHOCK DO NOT OPEN Guangzhou DSPPA Audio Co.,Ltd. LINE LINE DATA/POE ( +48V ) CH1 IN CH2 IN CH1 OUT CH2 OUT Gigabit Network Standard +48V POE switch OUT B OUT A...
Page 8
Correct connection 3 Dante MIC DT4200E DT2200 CAUTION! RISK OF ELECTRIC SHOCK Guangzhou DSPPA Audio Co.,Ltd. DO NOT OPEN LINE LINE Gigabit Network Standard+48V POE switch DATA/POE ( +48V ) CH1 IN CH2 IN CH1 OUT CH2 OUT CD/MP3 PLAYER...
3. Each of our Dante devices is compatible to +48V POE switch in Gigabit Ethernet standard 4. We suggest using CAT 6 cable when connecting it with audio devices with power switch 3.2 Device connection diagram DT2200 2X2 Dante interface DT2200 2X2 Dante interface DT2200 2X2 Dante interface...
4. Operation Instruction 4.1 Matters need attention (1) Set firewall permission On the computer with firewall, you need to set firewall permission or close it. Steps are as follows: Step 1: open “Computer” and click “System properties” Step 2: enter following interface and click “Control Panel Home”...
Page 11
Step 3: after open the interface, click “Windows Firewall”.
Page 12
Step 4: in “Windows Firewall” interface, click “Turn Windows Firewall on or off”. Step 5: enter the following interface and select “Turn off Windows Firewall” and click “OK”.
Page 13
(2) Set IP address Firstly, connect PC with one Dante device with Network cable and set IP according to user’s PC. Dante Terminals should be configured first. Steps are as follows: Step 1: click on the right corner to open Network and sharing center. Step 2: click “Local connection”...
Page 14
Step 3: enter local connection interface and click “Properties” Step 4: enter following interface and double click “Internet Protocol Version 4 (TCP/IPv4)”. Step 5: enter following interface and IP address in the red box could be changed. After changing, click “OK”.
Note: If you need to use in more than one LAN, you can add new Network in “Advanced”. (Enter “Advanced” interface and click “Add” then enter IP.) When configuring IP address, Network segment will not influence current one. The Network segment ...
4.2.1 Operation interface After logging in successfully, you will enter operation interface. Please make sure that all devices have been connected then you can follow steps in the following picture. Menu Click to enter system setting interface 2 Double click on the Amplifier Audio Adjustment for volume adjustment of relevant device Volume adjustment of relevant device Maximum Volume...
4.2.2 System Setting You need to enter password before entering “System setting” interface. Double click any menu to enter corresponding interface. To choose audio input channel To choose audio output channel Double click enter the interface 1. Binding IP address Please binding IP address before operating.
Page 19
2) Click “Local connection” 3) Click “Details” to see your IP address.
Page 20
4) IPv4 address is the IP address of your computer...
Page 21
5) Double click “Other setting” and copy IP address to “Binding IP”. Then click binding and you will see “The change will take effect after rebooting.”. Next, restart the software. After restarting, please pay attention whether the IP is the same as that of your computer. Note: you can also set language in this interface.
Page 22
② ③ ① 3. Channel configuration When configuring channels, you need to choose audio input channel of device in input channel (such as input CH1 of DT4300 in the following picture) and then choose corresponding device name of output channel (DT4106 in the following picture).
Page 23
3)Both red and green indicate that the channel is open. Red specially represents all matching output channel of current input channel. Open...
Page 24
To choose device type Open status matching channel 4. Software update 16×16 network interface: please make sure that there is newest update package under “……\update\16x16”. Step: choose 16×16 network interface and check devices that need to be updated. Then click “Update”. Other devices: please make sure that there is newest update package under “……\update\16x16”.
Page 25
5. Change password Double click “Change password” to enter the interface. Password is 6-bit.
4.3 PC Dante ID setting (1) IP setup Step1: After installing “DanteSetID” software, right-click and choose “run as administrator” to enter IP modify interface. Step2: Copy local IP address to dialog box of “Binding IP” (IP acquisition method please refer to text above). Next, click “Binding”...
Page 28
(2) ID setting You can only change ID of devices that are connected successfully. Two devices cannot use the same ID address. You can change ID after the device is detected by software. First, place your mouse in the dialog box. Next, input ID and then click “Set”.
5. DanteControlSystem Common Problems and solutions Case 1: There is no DanteSetID.exe and DanteControlSystem but when open the software, it pop up the following window: Reason: unknown reason to make it close and there is residue during the process of running. Solution: open “Task manager”...
Page 30
Solution: wait for 2 minutes after it finish refreshing. Case 3: device is not displayed in the software after connected successfully. Reason and solution: 1. Please make sure device is connected successfully to Network. 2. Open Channel configuration interface to check whether it exists. 3.
Page 31
Picture 1 Picture 2 Picture 3 2. On a computer with WIN10 system, right click on desktop and click “Display settings” and you will enter setup interface. Click “Display” and set the one in red box to be 100%. Click “Apply” and log off your computer. Note: if content is too small after setting, you can change screen resolution.
(DanteControlSystem will open multicast automatically. Official software needs manual setup) 2. Enable multicast function (official software needs manual setup) Step 1: double click device needs to be changed on interface 1 (such as DSPPA-00023) and you will enter interface 2.
Page 33
Interface 1 Interface 2 Step 2: Click “Transmit” on menu bar and click on interface 3 which is “Create a new multicast flow” to create multicast.
Page 34
Interface 3 Interface 4 Step 4: click channel that needs to enable multicast and click “Create”.
Page 35
Interface 5 Step 5: if you want to delete multicast, click “Delete” on interface 6. Multicast is deleted in Interface 7. Interface 6...
Page 36
Interface 7 3. Occupancy of Network bandwidth after multicast is enabled 4*4 audio interface: 6Mbps 2*2 audio interface: 4Mbps (Smaller) Dante MIC: 2Mbps 16*16 audio interface with 8 multicast channels: 12Mbps Results: 4*4 audio interface: 6Mbps. Total bandwidth is 60Mbps after connecting 10 devices. 2*2 audio interface: 4Mbps.
6.2 How to use control software of other brand to control DSPPA Dante devices 1. If you want to make control software with DSPPA products compatible, you need to make following configuration: DanteController Open official software DSPPA-00023 Step 1: double click device that need to be modified (such as ) in interface 1 and you will enter interface 2.
Page 38
Interface 2 Step 2: select Network Config and we can see IP address of current device. State IP is in use. Interface 3 Obtain an IP Address Automatically (default) and click “Apply”. System will pop up a Step 3: Select dialogue box.
Page 39
Interface 4 Interface 5 After finish all steps above, device will gain IP address automatically to make it compatible with Dante system of other brand. Summary: Due to limitations of Dante device, number limitation of data stream and Network bandwidth, we make some changes to take best advantage of it.
For issues and precautions not mentioned in this User Manual, if required, please contact the distributor or visit our website at http://www.DSPPA.com In case of any failure in the warranty period, please contact service personnel (or distributor) of our ...
Model DT2200 Input Voltage ≥1V Local imbalanced Frequency 20Hz~20kHz input is 250mv/1kHZ, Response(±3dB) imbalanced output of ≥80dB another DT2200 is 1V Input Dynamic Range ≥18dB Input Distortion ≤0.5% Output Voltage ≥1V Local Microphone Frequency Response 50Hz~20kHz input is 2.5mv/1kHZ , (±1dB)...
Page 42
● This is connected to power source via the plug and any failure or danger occurs, the user can disconnect the device from power source by pulling out the plug out from the socket, therefore, it is required that the power socket should be located somewhere with easy access. Guangzhou DSPPA Audio Co., Ltd...
