WNA-100
Wireless Network Adapter

User Guide

Guide d'utilisation
Guida dell'utente
Benutzerhandbuch
Guía del usuario
Guia do Usuário
www.xerox.com/office/wna

Advertisement

   Related Manuals for Xerox WNA-100

   Summary of Contents for Xerox WNA-100

  • Page 1: User Guide

    WNA-100 Wireless Network Adapter User Guide Guide d’utilisation Guida dell'utente Benutzerhandbuch Guía del usuario Guia do Usuário www.xerox.com/office/wna...
  • Page 2 Copyright © 2007 Xerox Corporation. All Rights Reserved. Unpublished rights reserved under the copyright laws of the United States. Contents of this publication may not be reproduced in any form without permission of Xerox Corporation. Copyright protection claimed includes all forms of matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as styles, templates, icons, screen displays, looks, etc.
  • Page 3: Table Of Contents

    Online Support Assistant ..........3-3 Adapter Specifications Security and Regulations Index Xerox WNA-100 Wireless Network Adapter...
  • Page 4: Features

    Features This chapter includes: Introduction on page 1-2 ■ ■ Package Contents on page 1-2 ■ Hardware on page 1-3 Xerox WNA-100 Wireless Network Adapter...
  • Page 5: Introduction

    The Wireless Network Adapter is a LAN bridge that transparently transmits network traffic from the wireless LAN to the wired network. It can be used with a large number of Xerox printers and multifunction devices and can also be configured to work in a large number of wireless environments.
  • Page 6: Hardware

    Hardware Status LEDs The following table provides an overview of each LED: LED Number LED Definition Power Ethernet Xerox WNA-100 Wireless Network Adapter Color Description Green On: Power enabled. Orange Flashing: Internal error. Off: No power. Green On: 10/100 Base Tx Link.
  • Page 7 LED Number LED Definition Wireless Error Xerox WNA-100 Wireless Network Adapter Color Description Green On: Link > 11 Mbps. Green Flashing: Data > 11 Mbps. On: Link ≤ 11 Mbps. Orange Flashing: Data ≤ 11 Mbps. Orange Off: No Wireless network activity.
  • Page 8 Power Connector Only use the power adapter supplied with the Xerox Wireless Network Adapter. Ethernet Port Use the included Ethernet crossover cable to connect directly to your PC, and then your Ethernet enabled product. Default (Reset Button) A quick press of the Reset button prints a configuration page.
  • Page 9: Configuring The Adapter

    Configuring the Adapter This chapter includes: Setting Up the Adapter on page 2-2 ■ ■ Configuring the Adapter Using Your Web Browser ■ Configuring the Screens on page 2-6 Xerox WNA-100 Wireless Network Adapter on page 2-4...
  • Page 10: Setting Up The Adapter

    Setting Up the Adapter To set up your Wireless Network Adapter: Connect the antenna to the adapter. Connect the power cord to the adapter. Xerox WNA-100 Wireless Network Adapter Setting Up the Adapter...
  • Page 11 The adapter is not intended for use on a switch or hub. The adapter is expecting to be connected to a single device using the Ethernet crossover cable provided. See also: Installation Guide at www.xerox.com/office/wna Xerox WNA-100 Wireless Network Adapter Setting Up the Adapter...
  • Page 12: Configuring The Adapter Using Your Web Browser

    Click the Restart button in the Reset section of the Administrative Utilities page. Xerox WNA-100 Wireless Network Adapter Configuring the Adapter Using Your Web Browser on page 1-5 for more information.
  • Page 13: Optimizing The Wireless Network Connection

    Use a wireless repeater to extend the range of your wireless adapter. ■ Avoid using cell phones or other wireless electronics nearby. Xerox WNA-100 Wireless Network Adapter Configuring the Adapter Using Your Web Browser Hardware on page 1-3 for more information.
  • Page 14: Configuring The Screens

    SSL (HTTPS) Settings: Secure HTTP allows you to encrypt the transmission to the device during configuration. ■ SNMP Settings (Simple Network Management Protocol): Allows you to use standard SNMP tools to configure the wireless interface. Xerox WNA-100 Wireless Network Adapter Configuring the Screens...
  • Page 15: Administrative Utilities

    Default Configuration Interface: Allows you to change the default configuration interface. ■ Reset: Allows you to reset the interface or configuration. Support The Support page lists helpful links on the Xerox website. Xerox WNA-100 Wireless Network Adapter Configuring the Screens...
  • Page 16: Troubleshooting

    Troubleshooting This chapter includes: Troubleshooting Wireless Configuration Problems ■ See also: Online Support Assistant at www.xerox.com/office/wna Xerox WNA-100 Wireless Network Adapter on page 3-2...
  • Page 17: Troubleshooting Wireless Configuration Problems

    If you are connected to a printer, you can print an adapter configuration page with a short click of the Reset button. ■ Is the correct IP address in the browser? Does the IP address match the IP address of the adapter? Xerox WNA-100 Wireless Network Adapter Troubleshooting Wireless Configuration Problems on page 2-4...
  • Page 18: Online Support Assistant

    Online Support Assistant The Online Support Assistant is a knowledge base that provides instructions and troubleshooting help to solve your adapter problems. To access the Online Support Assistant, go to www.xerox.com/office/wna. Xerox WNA-100 Wireless Network Adapter Troubleshooting Wireless Configuration Problems...
  • Page 19: Adapter Specifications

    Operating: 10% – 90% non-condensing (40% – 60% recommended) Electrical Specifications Available in three configurations: ■ North America: Part number 097S03740 United Kingdom: Part number 097S03741 (available in 2007) ■ ■ European Union: Part number 097S03742 (available in 2007) Xerox WNA-100 Wireless Network Adapter...
  • Page 20 ■ Minimum: 16 dBm at 54 Mbps Controller Specifications 166 MHz processor ■ Memory 2 MB of flash memory ■ ■ 4 MB of SDRAM Interfaces ■ Ethernet 10 Base T and 100 Base Tx Xerox WNA-100 Wireless Network Adapter...
  • Page 21 Security and Regulations Xerox has tested this product to electromagnetic emission and immunity standards. These standards are designed to mitigate interference caused or received by this product in a typical office environment. Information for United States Users This equipment has been tested and found to comply within the limits for Class B digital device pursuant to Part 15 of the FCC Rules.
  • Page 22 According to 47CFR, Part 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU Boards and Power Supplies used with Class B Personal Computers, Xerox declares under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device FOR HOME OR OFFICE USE.
  • Page 23 (pacemakers, hearing aids, etc.) regarding any restrictions on the use of 802.11x wireless technology. Xerox Corporation cannot be responsible for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product. Declaration of Conformity (CE) Product: Ethernet and Wireless 802.11a, 802.11b, and 802.11g-enabled print server...
  • Page 24 EAP settings, 2-6 electrical specifications, A-1 environmental specifications, A-1 hardware, 1-3 memory, A-2 network services, 2-6 Online Support Assistant, 3-3 Xerox WNA-100 Wireless Network Adapter package contents, 1-2 passwords change, 2-7 performance specifications, A-2 physical specifications, A-1 printer physical specifications, A-1...
  • Page 25 TCP/IP configuration configuration screens, 2-6 TCP_IP settings, 2-6 troubleshooting, 3-2 Online Support Assistant, 3-3 trusted root certificate, 2-7 update firmware, 2-7 WEP settings, 2-6 wireless configuration configuration screens, 2-6 WPA settings, 2-6 Xerox WNA-100 Wireless Network Adapter Index-2 Index...
