Hobo Pendant UA-00 Series Quick Start

HOBO® Pendant® Data Logger (UA-00x) Quick Start
1
Open HOBOware® software. (Get the latest software at www.onsetcomp.com/hoboware-free-download.)
2
Attach the USB Optic Base Station (BASE-U-4) or HOBO Waterproof Shuttle (U-DTW-1) to a USB port on the computer (refer to the
hardware manual at www.onsetcomp.com/resources for details).
3
Insert the logger and the base station into the coupler, as shown in the following diagrams. If the logger has never been connected
to the computer before, it may take a few seconds for the new hardware to be detected.
Firmly insert the optical end of the base station into the
D-shaped end of the coupler and make sure that the
ridge on the logger is aligned with the groove in the
coupler. If you are using the HOBO Waterproof Shuttle,
briefly press the coupler lever to put the shuttle into
base station mode.
22136-D MAN-UA-QSG
HOBO® Pendant® Data Logger (UA-00x) Quick Start
1
Open HOBOware® software. (Get the latest software at www.onsetcomp.com/hoboware-free-download.)
2
Attach the USB Optic Base Station (BASE-U-4) or HOBO Waterproof Shuttle (U-DTW-1) to a USB port on the computer (refer to the
hardware manual at www.onsetcomp.com/resources for details).
3
Insert the logger and the base station into the coupler, as shown in the following diagrams. If the logger has never been connected
to the computer before, it may take a few seconds for the new hardware to be detected.
Firmly insert the optical end of the base station into the
D-shaped end of the coupler and make sure that the
ridge on the logger is aligned with the groove in the
coupler. If you are using the HOBO Waterproof Shuttle,
briefly press the coupler lever to put the shuttle into
base station mode.
22136-D MAN-UA-QSG
To BASE-U-4 or HOBO
Waterproof Shuttle
COUPLER2-A
To BASE-U-4 or HOBO
Waterproof Shuttle
COUPLER2-A
Optical communication
LOGGER
window
Right side down
Coupler lever (for use with
HOBO Waterproof Shuttle)
Optical communication
LOGGER
window
Right side down
Coupler lever (for use with
HOBO Waterproof Shuttle)
