HOBO® Light On/Off Data Logger (UX90-002x) Manual
HOBO Light On/Off
Data Logger
Models: UX90-002
UX90-002M
Included Items:
• Command™ strip
• Double-sided tape
• Hook & loop strap
Required Items:
• HOBOware 3.3 or later
• USB cable (included with
software)
Accessories:
• Light pipe (UX90-LIGHT-
PIPE-1)
• U-Shuttle (U-DT-1)
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Phone: 021-8690 6777 (Hunting)
The HOBO Light On/Off data logger monitors indoor light changes with an internal sensor.
Using HOBOware®, you can easily configure the logger to record light on and off conditions
making it ideal for building energy audits and light usage analysis. This compact data logger has
a built-in LCD screen for checking status, remaining battery level, and memory consumption.
You can also use the LCD screen to quickly calibrate the logger to the light level in your building
or you can set calibration to preset sensitivity thresholds with HOBOware. There are two
models of the HOBO Light On/Off data logger: the UX90-002 has 128 KB of memory while the
UX90-002M has 512 KB.

Specifications

Light Threshold
> 65 lux
Light Type
LED, CFL, fluorescent, HID, incandescent, natural
Memory Modes
Wrap when full or stop when full
Start Modes
Immediate, push button, date & time, or next interval
Stop Modes
When memory full, push button, or date & time
Time Accuracy
±1 minute per month at 25°C (77°F) (see Plot A)
Power Source
One 3V CR2032 lithium battery and USB cable
Battery Life
1 year typical use
Memory
UX90-002: 128 KB (84,650 measurements, maximum)
UX90-002M: 512 KB (346,795 measurements, maximum)
Download Type
USB 2.0 interface
Full Memory Download
10 seconds for 128 KB; 30 seconds for 512 KB
Time
Logger Operating Range
Logging: -20° to 70°C (-4° to 158°F); 0 to 95% RH (non-condensing)
Launch/Readout: 0° to 50°C (32° to 122°F) per USB specification
LCD
LCD is visible from: 0° to 50°C (32° to 122°F); the LCD may react slowly or
go blank in temperatures outside this range
Size
3.66 x 5.94 x 1.52 cm (1.44 x 2.34 x 0.6 in.)
Weight
23 g (0.81 oz)
Environmental Rating
IP50
The CE Marking identifies this product as complying with all relevant
directives in the European Union (EU).
Plot A: Time Accuracy
Mobile: +62 816 1740 8925
Fax: 021-8690 6771
Fax: 021-8690 6777

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UX90-002 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hobo UX90-002 Series

Summary of Contents for Hobo UX90-002 Series

  • Page 1 You can also use the LCD screen to quickly calibrate the logger to the light level in your building or you can set calibration to preset sensitivity thresholds with HOBOware. There are two models of the HOBO Light On/Off data logger: the UX90-002 has 128 KB of memory while the UX90-002M has 512 KB.
  • Page 2 USB Port: Use this port to connect the logger to the computer start logging on a particular date/time. The display or the HOBO U-Shuttle via USB cable (see Setting up the Logger will count down to the start date/time until logging begins.
  • Page 3 Time or %. remain on until the logger is offloaded to a computer or HOBO U-Shuttle (unless launched with the “Turn LCD Off” 6. If the logger is configured to record runtime, choose a option). Once the logger has been offloaded and...
  • Page 4 • Maximize the signal strength on the logger LCD screen Time Approximate Approximate Between Total Data Logging Duration Logger Part by adjusting the light pipe while looking at the signal Events Points (1 Year Battery Life) Number bars (see Calibrating the Light Sensor for more details on signal strength).
  • Page 5 Battery Information the computer with a USB cable and read out it with HOBOware, or connect it to a HOBO U-Shuttle (U-DT-1, firmware version The logger is installed with a 3V CR2032 battery (HRB-TEMP). 1.15m030 or higher) and then offload the data files from the Expected battery life varies based on the ambient temperature U-Shuttle to HOBOware.
  • Page 6 4. With the LCD screen still facing up, slide the tray back into the logger. The LCD should display “HOBO” briefly after correctly installing the battery. WARNING: Do not cut open, incinerate, heat above 85°C (185°F), or recharge the lithium battery. The battery may explode if the logger is exposed to extreme heat or conditions that could damage or destroy the battery case.
