Hobo U10 Mounting Instructions

HOBO U10 Temperature Data Logger (Part # U10-001)
®
Inside this package:
• HOBO U10 Temperature Logger
• Mounting kit with magnet, hook-
and-loop tape, and 3/8" double-
sided tape.
Doc # 11195-B, MAN-U10-001
Onset Computer Corporation
Specifications
Measurement
-20° to 70°C (-4° to 158°F)
range
± 0.53°C from 0° to 50°C (± 0.95°F from 32° to
Accuracy
122°F), see Plot A
Resolution 0.14°C at 25°C (0.25°F at 77°F), see Plot A
Drift 0.1°C/year (0.2°F/year)
10 minutes in airflow of 1 m/s (2.2 mph), typical
Response time
to 90%
Approximately ± 1 minute per month at 25°C
Time accuracy
(77°F), see Plot B
Logging: -20° to 70°C (-4° to 158°F); 0 to 95%
Operating range
RH (non-condensing)
Battery life 1 year typical use
Memory 64K bytes (52,000 10-bit measurements)
Weight 26 g (0.82 oz)
Dimensions 45 x 60 x 20 mm (1.8 x 2.38 x 0.77 inches)
The CE Marking identifies this product as
complying with the relevant directives in the
European Union (EU).
© 2005–2012 Onset Computer Corporation
Part #: MAN-U10-001, Doc #: 11195-B
Thank you for purchasing a HOBO data logger.
With proper care, it will give you years of
accurate and reliable measurements.
The HOBO U10-001 is a one-channel
Temperature Data Logger with 10-bit resolution
and capacity for 52,000 measurements. The
logger uses a direct USB interface for launching
and data readout by a computer.
HOBOware
operation. Visit www.onsetcomp.com for details.
Plot A
®
software is required for logger
Connecting the logger
The U-Series logger requires an Onset-supplied USB interface
cable to connect to the computer. If possible, avoid connecting
at temperatures below 0°C (32°F) or above 50°C (122°F).
1. Plug the large end of the USB interface cable into a USB
port on the computer.
2. Plug the small end of the USB interface cable into the side
of the logger as shown in the following diagram.
3. Load and use logger software to operate the logger (see
software manual).
Important: Press this
button for 3 seconds
when logger is
launched with "Trigger
Start" or press for 1
second to record an
event while logging
If the logger has never been connected to the computer before,
it may take a few seconds for the new hardware to be detected
Important: If you configure the logger to start with a
trigger start, be sure to press and hold down the button on
the front of the logger for at least three seconds when you
want to begin logging. When you release the button, the
Plot B
USB interface
cable plugged
into logger
