LED PROFILES
Product version:
V3
Software:
FIRMWARE V4.00
Date: 19/01/24
DN41159401 (EN)
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr
600 W LED
Model
Standard
8 – 16°
961SX (v3)
29 – 50°
963SX (v3)
15 – 40°
964SX (v3)
www.robertjuliat.com
North American
961CSX (v3)
963CSX (v3)
964CSX (v3)
Advertisement
Table of Contents
Related Manuals for Robert Juliat CHARLES 963SX
Summary of Contents for Robert Juliat CHARLES 963SX
- Page 1 963CSX (v3) 15 – 40° 964SX (v3) 964CSX (v3) Product version: Software: FIRMWARE V4.00 Date: 19/01/24 DN41159401 (EN) Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr www.robertjuliat.com...
-
Page 2: Table Of Contents
4.9.2 Control .........................23 4.10 Beam shaping ....................... 24 4.10.1 Range .........................24 4.10.2 Control ........................24 Robert Juliat reserve the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice. -
Page 3: User's Instructions
1 User’s instructions GENERAL INSTRUCTIONS Not for residential use. These fixtures must only be serviced by a qualified technician. In addition to the instructions indicated on this page, relevant health and safety requirements of the appropriate EU Directives must be adhered to at all times. This fixture is in compliance with section 17 - Lighting appliance for theatre stages, television, cinema and photograph studios. -
Page 4: Presentation
2 Presentation 2.1 Functions Description Hanging yoke 11. Identification plate Local display 12. Rear handle Control board 13. Power switch Tilt locking handle 14. Power connectors (IN and OUT) Shutter locking system 15. Thermal breaker Shutters 16. Data connectors (IN and OUT) Focus adjustment 17. -
Page 5: Identification Label
2.2 Identification label Description 1. MOD. : Model 18 15 16 2. VERS. : Version 3. U : Nominal voltage input (V) 4. I : Nominal intensity (A) 5. P : Maximum power input (W) 6. IP : International Protection Rating 7. -
Page 6: Optional Accessories
2.4 Optional accessories Reference Description IWSX755 Drop-in iris (monoplane) with holder G1000 215x215mm safety grid CAV700A Double slot front cassette for 215x215mm accessories CAV700AJ Double slot front cassette for 245x245mm accessories Front extension cassette for 215x215mm accessories with XLR7 fan RPF960 (recommended for dark colours on 960SX) Front extension cassette for 245x245mm accessories with XLR7 fan... -
Page 7: Set-Up
3 Set-up 3.1 Mechanics 3.1.1 Operating positions 3.1.2 Minimum distance between a flammable material and the lighting unit 0,2 m / 0.7 ft 3.1.3 Instructions for use Minimum : Maximum : 5°C 40°C 40°F 104°F IP20 - Indoor use only 3.1.4 Hanging •... -
Page 8: Safety Cable
3.1.5 Safety cable • When hung or flown, the fixture must be secured by an additional hanging accessory (such as a safety bond or cable) of suitable length. • The combined weight of both the fixture and the accessories must be considered when choosing the load-bearing capability of safety cable or bond. -
Page 9: Electrical Information
3.2 Electrical information 3.2.1 LED source Never touch or scratch the LED surface. Cf. 6.1.4 LED cleaning procedure if cleaning is necessary. 3.2.2 Power supply Power supply Voltage Frequency Input power Connectors 3 A / 660 W @ 230V Neutrik powerCON TRUE1 TOP 5.8 A / 680 W @ 120V 100 T 264 V 50-60 Hz... -
Page 10: Dmx 512-A / Rdm
Power ON 3.3 DATA 3.3.1 DMX 512-A / RDM Protocol Input connector Output connector USITT DMX 512-A XLR 5-pin XLR 5-pin DATA connectors PIN # Description Shielding Foil & Braided Shield DMX (-) conductor of 1 twisted pair DMX (+) conductor of 1 twisted pair Not used... -
Page 11: Art-Net / Sacn
3.3.2 Art-Net / sACN Protocol Input connector Output connector Art-Net (V3 & V4) RJ45 sACN DUAL (SACN + Art-Net) Art-Net sACN Network switch* Lighting desk interface (*) A 1000 base-T switch that supports IGMP (Internet Group Management Protocol) is necessary if the unit is connected to a network switch to control multiple devices. -
Page 12: Accessories
3.4 Accessories 3.4.1 Front filter holder Dimensions Cf. 4.8 The filter holder includes perforations designed for stapling to keep the gel in position. 3.4.2 Gobo holder 'A' size gobo Dimensions Cf. 4.6 Position 1 or Position 2 EN - 10 -... -
Page 13: Shutters
3.4.3 Shutters Step 1 Step 2 Step 3 EN - 11 -... -
Page 14: Internal Filter Holder
3.4.4 Internal filter holder Dimensions Cf. 4.8 3.4.5 Drop-in iris EN - 12 -... -
Page 15: Double Slot Front Cassette For Accessories
3.4.6 Double slot front cassette for accessories 3.4.7 Safety grid EN - 13 -... -
Page 16: Front Extension Cassette With Fan
3.4.8 Front extension cassette with fan EN - 14 -... -
Page 17: Operations
4 Operations 4.1 Light intensity 4.1.1 Range • Dimming 100% 4.1.2 Control Remotely with DMX512-A protocol Locally via Standalone mode DMX512-A HTP mode (Highest Takes Precedence): Light output is the highest value of DMX512 command or local control Focus mode: when standby screen displayed, Push Exit or up arrow for 3 secs →... -
Page 18: Master Control
4.1.3.3 Master control In order to supervise the operator from the console, master control DMX channel can be used. This channel limits the maximum value of the dimmer shutter. By using this function, it is possible to obtain synchronised fades with several spots or to give intensity limits (minimum and maximum) to the operator . -
Page 19: Strobe
4.2 Strobe 4.2.1 Range Strobe duration 255 = 20ms 0 = OFF 1 = 1ms Strobe speed 0 = 0.1Hz 255 = 10Hz 4.2.2 Control T Remotely with DMX512-A / Art-Net / sACN protocols. Mode 3 – 4 DMX512-A 4.3 Response time 4.3.1 Range X ms DMX 0 = 0 ms... -
Page 20: Beam Size Adjustment
4.4 Beam size adjustment 4.4.1 Range Beam angle Field angle Model Angles Minimum angle @ 29° Maximum angle @ 50° Beam angle 30° 48° 963SX Field angle 31° 52° Model Angles Minimum angle @ 15° Maximum angle @ 40° Beam angle 13°... -
Page 21: Orientation
4.5 Orientation 4.5.1 Range Function Range 360° TILT TU = 0 68° TD = 0 90° 4.5.2 Control Unlock Lock EN - 19 -... -
Page 22: Gobo
4.6 Gobo 4.6.1 Range Type Standard gobo - A size Ø100 mm Ø72 mm • Metal Dimensions Maximum • Glass image size Installation Cf. section: 3.4.2 4.6.2 Control "Click": Correctly in place. EN - 20 -... -
Page 23: Iris
4.7 Iris 4.7.1 Range 75% Closed 4.7.2 Control EN - 21 -... - Page 24 4.8 Colour 4.8.1 Range Location 1. Internal filter holder 2. Front filter cassette (option) Type Frosted or dichroic glass Coloured gel filter (option) 215 mm Dimensions 195 mm 215 mm Installation See 3.4.4 See 3.4.6 EN - 22 -...
- Page 25 4.9 Beam shaping 4.9.1 Range 4.9.2 Control Locking shutter system Locked Unlocked EN - 23 -...
- Page 26 4.10 Beam shaping 4.10.1 Range Function Range Gobo Shutters 4.10.2 Control Push the lever (1) to lock and unlock zoom rotation. Lock Unlock EN - 24 -...
-
Page 27: Controls And Parameters
5 Controls and parameters 5.1 Local display and controls 5.1.1 Display Function Exit the current menu option and/or go back Press for 3 secs to enter Focus mode Enter the current menu option and/or valid Scroll through menus and/or Increase data value Scroll through menus and/or Decrease data value Scroll through menus and/or Increase data value Scroll through menus and/or Decrease data value... -
Page 28: Menu
5.1.2 Menu DATA FACTORY STATUS SETUP BOOT MODE DEFAULT Reset to factory settings. Reboot the fixture. DISPLAY PROTOCOL • DMX • INTENSITY SELFTEST • ARTNET • AUTO OFF • SACN • DUAL • STANDALONE SYSTEM ID DATA SETUP • SERIAL NUMBER •... -
Page 29: Parameters
5.1.3 Parameters Selection in SETUP/DISPLAY MODE menu → Display Mode Description 000% Always ON Main display (home screen) always ON NODE MASTER SETUP DISPLAY INTENSITY Adjust the intensity of the screen Intensity Intensity : 4 To change value, press buttons : press OK Intensity Auto-Off... -
Page 30: Dmx512 - A Remote Control
5.2 DMX512 - A remote control 5.2.1 Protocol E1.11 – 2008, USITT DMX512-A 5.2.2 Configuration Set mode through web interface Set mode through RDM protocol Locally, through the local control compatible device 1 - Set DMX address 2 - Set personality mode (see 5.2.4. DMX chart) Data Mode Protocol Press OK... -
Page 31: Parameters
5.2.3 Parameters 5.2.3.1 DMX Hold T Set through RDM protocol, web interface or local control DMX512-A If data not detected Hold last values Reset DMX values Default value (Standalone value) EN - 29 -... -
Page 32: Dmx Chart
5.2.4 DMX chart Mode 1: Mode 2: Mode 3: Mode 4: DMX Channel Dimmer8B Dimmer16B Profile8B Profile16b Dimmer Dimmer Dimmer Dimmer Dimmer fine Strobe duration Dimmer fine Strobe speed Strobe duration Response time Strobe speed Control mode Response time Control mode 5.2.5 DMX ranges 5.2.5.1 Strobe duration Range min... -
Page 33: Data 8 5.3 Rdm Remote Control
5.3 RDM remote control 5.3.1 Protocol ANSI E1.20 – 2010 / ANSI E1.37 - 1 For more information about RDM protocol: http://www.rdmprotocol.org/ 5.3.2 Functions RDM COMPATIBILITY SULLY V2.7 VERSION Queued_ Description Standard Ack_Timer Message 4.00 Network Management DISCOVERY_UNIQUE_BRANCH E1.20 ✔ ✔ 00 01 DISCOVERY_MUTE E1.20... - Page 34 RDM COMPATIBILITY SULLY V2.7 SULLY Queued_ Description Standard Ack_Timer Message 4.00 Control IDENTIFY_DEVICE E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ 10 00 RESET_DEVICE E1.20 ✔ ✔ ✔ ✔ ✔ ✔ 10 01 PERFORM_SELFTEST E1.20 ✔ ✔ ✔ ✔ ✔...
-
Page 35: Art-Net Remote Control
5.4 Art-Net remote control 5.4.1 Protocol Artistic Licence Art-Net v3 & v4. For more information about Art-Net protocol: http://art-net.org.uk/ 5.4.2 Configuration Set mode through web interface Locally, through the local control (see 5.7 Web interface) Ethernet connection 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. -
Page 36: Local Set-Up
5.4.3 Local set-up Caution: (*) Activate Art-Net in protocol mode beforehand. step 1 DATA MODE Data Mode step 2 Protocol Press OK Press OK DATA MODE STATUS SETUP FAC PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate to enter step 2 step 1 DATA MODE... -
Page 37: Sacn Remote Control
5.5 sACN remote control 5.5.1 Protocol ANSI E1.31 – 2009 sACN (Streaming-ACN) 5.5.2 Configuration Locally, through the local control Set mode through web interface (see 5.7 Web interface) Ethernet connection 1 - If necessary, change IP settings 2 - Set sACN universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. -
Page 38: Local Set-Up
5.5.3 Local set-up Caution: (*) Activate sACN in protocol mode beforehand. step 1 DATA MODE Data Mode step 2 Protocol press OK press OK DATA MODE STATUS SETUP FAC PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate to enter step 2 step 1 DATA MODE... -
Page 39: Dual Remote Control
5.6 Dual remote control 5.6.1 Protocol Dual Mode: Available only on an Ethernet network It allows to send a DMX 512 signal through a Sacn data stream and at the same time to use an Artnet/ArtRdm data stream to control, set and monitor the equipment via RDM. This mode can be set by Web interface or the local control screen. -
Page 40: Local Set-Up
5.6.3 Local set-up Caution: (*) Activate sACN in protocol mode beforehand. step 1 DATA MODE Data Mode step 2 Protocol press OK press OK DATA MODE STATUS SETUP FAC PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate to enter step 2 step 1 DATA MODE... -
Page 41: Web Interface
5.7 Web interface 5.7.1 Control Ethernet connection The fixture must be connected to a compatible network or directly to a computer using an ethernet cable. 5.7.2 Default IP address By defaut : DHCP = OFF Address = 2.XXX.XXX.XXX Mask = 255.0.0.0 T If IP address unknown (due to a previous modification), a hard reset must be done (see 6.6 Factory defaults). -
Page 42: Fan Cooling Modes
5.8 Fan cooling modes 5.8.1 Range Modes Silent Normal Full < 40.5 dB(A) < 43.4 dB(A) < 45.8 dB(A) Cooling → → 100% Brightness 5.8.2 Control DMX512-A Remotely by DMX512-A Locally selection in → Mode 1 – 2 – 3 – 4 SETUP/COOLING 5.9 Gel Fan mode GEL FAN menu:... -
Page 43: Service
6 Service 6.1 Preventive maintenance 6.1.1 Frequency General maintenance should be performed at least once a year or more frequently if the equipment is operated in adverse conditions (smoke, heat, humidity, touring, etc.). 6.1.2 General cleaning Remove dust from the unit. Front glasses can be cleaned with solutions containing alcohol. -
Page 44: Inner Fans & Led Glass Protection Cleaning
6.1.6 Inner fans & LED glass protection cleaning Only use solutions containing alcohol to clean inner parts. Inner fans & LED access Caution: DISCONNECT the fan wire before removing the LED housing cover. Caution: DO NOT REMOVE the screws on the lower part of the LED housing. -
Page 45: Electronic Thermal Management System
6.3 Electronic thermal management system In case of overheating, light intensity will be reduced by the system. Power reduction and temperature values are available by using a RDM protocol compatible device. 6.4 Firmware update 1. Firmware available on www.robertjuliat.com/profilespots/CHARLES_960SX 2. Download and unzip the file There are 4 files contained in the folder: - Firmware (.upd2 format) - Firmware History... -
Page 46: Selftest
6.6 Selftest Select SELFTEST in the main menu : There are 9 tests available that will be performed by the fixture. STATUS At the end of each test, a PASS/FAIL message will be displayed. SELFTEST Press OK SELFTEST SYSTEM ID LIGHT SOUP to start SELFTEST... - Page 47 DMX Test DMX IN DMX data is required to complete this test. DMX IN fail or NO DMX DMX OUT Plug DMX OUT then press OK DMX OUT DMX OUT fail or NO DMX Signal Leds Test LEDS green LEDS blue LEDS Test Report...
