- Page 1 Smart Bike Trainer User Manual...
- Page 2 Always keep the cooling holes clear and plug it in for extreme use to keep the fan working. Please use the T2 on a stable su ace with adjusted leveling feet before use. Use caution when standing while riding on T2.
-
Page 3: Packing List
Cassette pre-installed Thru-axle adapter-R pre-installed Thru-axle adapter-L pre-installed Quick release adapter-R Quick release adapter-L T2主机 Quick release 17mm Wrench for thru-axle adapter-R AC adapter Allen key for quick release adapter-R 8-10 speed cassette spacer AC cable Cassette adjustment spacer [5x]... - Page 4 2.1 Ground and stabilize T2 Press and hold the lock catch. Unfold the leg. Press to Release unlock to lock Align the lock catch with the notch, and make sure the latch pops up and locks angle of the leg.
- Page 5 2.2 Cassette Mounting T2 comes preinstalled with a cassette. Read instruction below if you need to mount another one. 1. For 8/9/10 speed cassettes, put on the spacer before installing the cassette. Cassette spacer With notch outward 8/9/10 speed cassette 2.For SRAM 12 speed cassettes, an XDR hub will be needed to buy...
- Page 6 T2, and do not force to install. For bikes with disc brake sets, make sure the disc brake set is not against the housing of T2. If you nd any contact or friction, do not force to install. Possible area in contact...
- Page 7 2.5 For Bikes with Rear Thru-Axles Install the Thru-axle adapter-R(03) with 17mm wrench(07) T2 comes preinstalled with thru-axle adapter. Install the Thru-axle adapter-L(04) Outwards for Outwards for Mountain bike Road bike...
- Page 8 ② Never adjust the quick release skewer or thru axle while someone is sitting on the bike. WARNING! ③ There're still a few bike frames incompatible with T2. Stop the installation immediately if any abnormalities occur. ④ Please refer to the disclaimer and don't hesitate to contact us for any installation problems.
- Page 9 2.5 For Bikes with Quick Release Skewers Install the Quick release adapter-R(05) with the Allen key(08). T2 comes preinstalled with quick release adapter. Remove it before installation. Install the Quick release adapter-L(06) Outwards for Outwards for Mountain bike Road bike &...
- Page 10 ② Never adjust the quick release skewer or thru axle while someone is sitting on the bike. WARNING! ③ There're still a few bike frames incompatible with T2. Stop the installation immediately if any abnormalities occur. ④ Please refer to the disclaimer and don't hesitate to contact us for any installation problems.
-
Page 11: Power Connection
AC adapter 3 Working Status 1. Working modes T2 has 2 working modes, unplugged mode and plug-in mode. Plug-in mode can provide a better riding experience. The main functional di erences between the two modes are as follows. Unplugged mode... - Page 12 CYCPLUS APP App Store Google Play 2. T2 is a true direct-drive trainer and requires no calibration. 3. T2 suppo s both Bluetooth and ANT+ wireless connection protocols when using indoor cycling Apps. We recommend using Bluetooth connection in preference, for more stable signal.
- Page 13 5.1 Cassette adjustment spacer(for loud chain noise) If the chain noise becomes too loud while training, it may be because the distance between the T2 cassette and the rear fork (A) and the distance between your original cassette and the rear fork (B) are di erent, and the bike chain and cassette do not t well.
-
Page 14: Speci Cations
5 Speci cations CYCPLUS T2 Model Type Intelligent Direct - Drive Trainer Magnet 50 neodymium magnets + 45 sets of electromagnets Foldable X-shape Structure Dimension(unfolded) 520*699*510 mm Dimension(folded) 300*257*510 mm Weight(with cassette) 33.5lbs(15.2kg) Power supply 48V/1.25A(Unplugged mode suppo ed) 2200 W Max power Output power（40km/h）... - Page 15 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
