NCR 7358-K589 Kit Instructions

Large basket angled module (v-bagwell)
Hide thumbs

Advertisement

Quick Links

Download this manual
Kit Instructions
Large Basket Angled Module (V-Bagwell)
7358-K589/K590/K591
Issue B

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7358-K589 and is the answer not in the manual?

Questions and answers

Related Manuals for NCR 7358-K589

Summary of Contents for NCR 7358-K589

  • Page 1 Kit Instructions Large Basket Angled Module (V-Bagwell) 7358-K589/K590/K591 Issue B...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3 Revision Record Issue Date Remarks May 2019 First issue. Nov 2019 Added the following sections: • Changing V-Bagwell Orientation page 24. • Removing Fences page 26. • Removing V-Bagwell page 29.
  • Page 4 • Large Basket Corner Module (Corner Bagwell)—a bagging area that provides customers an area where they can place their items after scanning. The NCR FastLane SelfServ™ Checkout (7358) R6L Plus with a Bagging Area (Bagwell) Module or Large Basket (Basket) Module can be configured for either Left-hand (LH) orientation or Right-hand (RH) orientation, which refers to the direction customers scan and bag items.
  • Page 5 Large Basket Angled Module Kit Contents Depending on the color variant of the V-Bagwell, refer to the following sections for information about kit contents: • 7358-K589 V-Bagwell Module (NCR Dark White) on the facing page. • 7358-K590 V-Bagwell Module (Walmart Light Blue) on page 5.
  • Page 6 Large Basket Angled Module 7358-K589 V-Bagwell Module (NCR Dark White) Note: For the purpose of illustration only, this image shows a unit with Left-hand (LH) orientation.
  • Page 7 Large Basket Angled Module Part Number Description 497-0525223 Kit - Large Basket Angled Module (NCR Dark White) 795-0278131 Walmart V-Bagwell Module (NCR Dark White) 006-8612443 Flexible leveling foot - 2'' dia. (5/16'' hex X 3.25'' length) (6 pcs) * 795-0274931 Walmart, V-Bagwell Assembly, Right (NCR Dark White) 795-0275531 V-Bagwell Side Fence (NCR Dark White)
  • Page 8 Large Basket Angled Module 7358-K590 V-Bagwell Module (Walmart Light Blue) Note: For the purpose of illustration only, this image shows a unit with Left-hand (LH) orientation.
  • Page 9 Large Basket Angled Module Part Number Description 497-0525224 Kit - Large Basket Angled Module (Walmart Light Blue) 795-0278112 Walmart V-Bagwell Module (Walmart Light Blue) 006-8612443 Flexible leveling foot - 2 in dia. (5/16 in hex X 3.25 in length) (6 pcs) 795-0275212 Corner Fence (Walmart Light Blue) 795-0269812...
  • Page 10 Large Basket Angled Module 7358-K591 V-Bagwell Module (Walmart Medium Gray) Note: For the purpose of illustration only, this image shows a unit with Left-hand (LH) orientation.
  • Page 11 Large Basket Angled Module Part Number Description 497-0525225 Kit - Large Basket Angled Module (Walmart Medium Gray) 795-0278128 Walmart V-Bagwell Module (Walmart Medium Gray) 006-8612443 Flexible leveling foot - 2 in dia. (5/16 in hex X 3.25 in length) (6 pcs) 795-0275628 V-Bagwell End Fence (Walmart Medium Gray) 497-0524425...
  • Page 12 Note: The Large Basket Angled Module can hold up to two (2) bag racks (497- 0509740) that are ordered separately. To order bag racks, contact an NCR Customer Service Representative. 6. Level the SelfServ Checkout and Large Basket (Basket) Module assembly. For more...
  • Page 13 Large Basket Angled Module Installing Skirt Panels To install the Bagwell Skirts, follow these steps: 1. Install the side skirt panels by doing the following: a. Attach each skirt panel to the corresponding skirt brackets by aligning the open slots in the skirt panel with the screw holes in the skirt bracket. b.
  • Page 14 Large Basket Angled Module 2. Install the front and back skirt panels by doing the following: a. Attach the skirt panel to the skirt brackets by aligning the open slots in the skirt panel with the screw holes in the bracket. b.
  • Page 15 Large Basket Angled Module Installing V-Bagwell To install the V-Bagwell, follow these steps: Note: For the purpose of illustration only, this procedure shows images using Left-hand (LH) orientation. 1. Install the Corner Bagwell. For more information, refer to 7358-K580/K583/K584: Large Basket Corner Module Kit Instructions.
  • Page 16 Large Basket Angled Module 3. Align the screw slots of the V-Bagwell to the corresponding holes on the Corner Bagwell. Note: Depending on the orientation of the SelfServ Checkout, one of the cable access holes is opened by default. 4. Using four (4) Phillips pan head screws, secure the V-Bagwell to the Corner Bagwell, as shown in the image below.
  • Page 17 Large Basket Angled Module Installing Bumpers There are two bumpers to be installed on the V-Bagwell. To install the bumpers, follow these steps: Note: For the purpose of illustration only, this procedure shows images using Left-hand (LH) orientation. 1. Remove the top cover tray to access the mounting holes, if necessary. 2.
  • Page 18 Large Basket Angled Module 3. Do the following: a. Position the assembly so that the screws are aligned with the holes on the V- Bagwell. b. Secure each Bumper on the Bagwell using two (2) nuts.
  • Page 19 Large Basket Angled Module 4. Install the top cover tray to close the V-Bagwell. 5. Push and turn the Service screws clockwise to lock the top cover trays in place, as shown in the image below.
  • Page 20 Large Basket Angled Module Installing Fences To install the fences, follow these steps: 1. Ensure that the Corner Bagwell and V-Bagwell are installed. For more information, refer to the following kit instructions: 2. Install the fences on the Corner Bagwell by doing the following: a.
  • Page 21 Large Basket Angled Module b. Secure the side fences on the Corner Bagwell using seven (7) screws, as shown in the image below. c. Secure each side fence to the corner fence, as shown in the image below.
  • Page 22 Large Basket Angled Module 3. Install the fences on the V-Bagwell by doing the following: a. Secure the corner fence using two (2) screws, as shown in the image below. b. Secure the side fences on the V-Bagwell using screws, as shown in the image below.
  • Page 23 Large Basket Angled Module c. Secure each side fence to the corner fence, as shown in the image below.
  • Page 24 Large Basket Angled Module Installing Hole Label Covers Attach the hole label covers on the areas shown in the image below. Note: For the purpose of illustration only, the image below shows a unit with Left-hand (LH) orientation.
  • Page 25 To install the bag racks on the Bagwells, follow these steps: Note: The Large Basket (Basket) Module can hold up to four (4) bag racks (497-0509740) that are ordered separately. To order bag racks, contact an NCR Customer Service Representative. 1. Ensure that the Corner Bagwell and V-Bagwell are installed. For more information, refer to the following: 2.
  • Page 26 Large Basket Angled Module 4. Secure each bag rack to the top cover tray using two (2) screws, as shown in the image below. Note: Attach the screws on opposite corners.
  • Page 27 Large Basket Angled Module Changing V-Bagwell Orientation This procedure should be done before installing the Large Basket Angled Module (V- Bagwell) to the Corner Bagwell. To change the orientation of the V-Bagwell, follow these steps: Note: For the purpose of illustration only, this procedure shows images using Left-hand (LH) orientation.
  • Page 28 For more information, refer to 7358-K582 Bottom-of- Basket Camera Kit Instructions. 4. Level the SelfServ Checkout and Large Basket (Basket) Module assembly. For more information, refer to the "Leveling SelfServ Checkout Unit" section of NCR FastLane SelfServ™ Checkout (7358) R6L Plus Hardware Installation Guide (BCC5-0000-5263).
  • Page 29 Large Basket Angled Module Removing Fences To remove the fences, follow these steps: 1. Remove the fences from the V-Bagwell by doing the following: a. Remove the two (2) screws securing each side fence to the corner fence, as shown in the image below. b.
  • Page 30 Large Basket Angled Module c. Remove the two (2) screws securing the corner fence on the V-Bagwell, as shown in the image below. 2. Remove the fences from the Corner Bagwell by doing the following: a. Remove the two (2) screws securing each side fence to the corner fence, as shown in the image below.
  • Page 31 Large Basket Angled Module b. Remove the seven (7) screws securing the side fences on the Corner Bagwell, as shown in the image below. c. Remove the two (2) screws securing the corner fence on the Bagwell using , as shown in the image below.
  • Page 32 Large Basket Angled Module Removing V-Bagwell To remove the V-Bagwell, follow these steps: Note: For the purpose of illustration only, this procedure shows images using Left- hand (LH) orientation. 1. Do the following: a. On both sides of the top cover tray, turn the Service screw counterclockwise to unlock the tray from the Corner Bagwell.
  • Page 33 Large Basket Angled Module 2. Remove the four (4) Phillips pan head screws securing the V-Bagwell to the Corner Bagwell, as shown in the image below.
