- Page 1 7403-K150 Biometrics Module (Fingerprint Recognition) Kit Instructions Issue B...
-
Page 2: Revision Record
Revision Record Issue Date Remarks May 2009 First issue... -
Page 3: Kit Contents
Introduction This kit provides an integrated U.are.U ® Biometrics module for the 7403 terminal, providing fingerprint recognition capabilities. Biometrics Module 27625 Kit Contents Screw, 4-40 x 0.625 Pan Hd Biometrics Module 27624... -
Page 4: Installation Procedures
Installation Procedures Caution: Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer’s case for a few seconds. Avoid any contact with internal parts and handle cards only by their external edges. 1. - Page 5 c. Pivot the top of the Front Base Cover toward the front of the unit and remove it from the terminal. 26032 d. Disconnect the Power Cord from the Power Supply. AC Power Cord 26135...
- Page 6 2. Disconnect the Display Cable. 3. Loosen the Display thumbscrews (2). Thumbscrews Display Cable 26464...
- Page 7 4. Depress the Display Release Latches (2) and slide the Display Head toward the rear of the terminal to disengage it from the chassis. Display Latches 26151a...
- Page 8 5. Lay the Display Head on a flat, non-scratch surface to avoid scratches to the Touchscreen and Front Bezel. 6. Loosen the captive screws (2) that secure the Top Access Cover and then remove the cover from the Display Head. Top Access Cover 27639 7.
- Page 9 8. The below illustration shows how to fold the cable. It is easier to pre-fold the cable before assembling the module onto the Display Head. Fold the cable with a loop that routes through the slot in the Biometrics Module Back. Cable Loop 27641 9.
- Page 10 10. Install the Biometrics Module Assembly onto the Display Head. a. Position the front portion of the Biometrics Module Assembly on the Display Head. There is a square slot in the Rear Cabinet that the cable is routed through. Note: Make sure the Plastic Insulator is installed. Biometrics Module Back Plastic Insulator Biometrics Module Front...
- Page 11 12. Reassemble the unit using the reverse order. a. Install the Top Access Cover b. Install the Display Head onto the base c. Connect the Display Head Cable d. Connect the Power Cord e. Install the Front Base Cover. Driver/SDK Download The driver and SDK can be downloaded from the Digital Persona web site.
- Page 12 Using the Biometrics Module Guidelines for Fingerprint Registration High quality fingerprint templates are imperative for the security of the biometric security system. Low quality fingerprint templates can impact future read rates. Therefore, using the Biometrics Module should be done very carefully. In case of inexperienced users who are using the module for the first time, the process should be assisted (guided) by an administrator or experienced user.
- Page 13 The Biometric Module algorithms automatically recognize it if the fingerprint is placed too low, too high, or too far to the left or right side of the sensor and then provide the user with feedback to improve the fingerprint placement. Pressure: Put your finger gently on sensor.
-
Page 14: Troubleshooting
Troubleshooting & Cleaning Troubleshooting If the reader is having difficulty acquiring a scan of your fingerprint, consider the following: • The reader window may need cleaning, see Cleaning the Reader. You may not be touching the reader correctly. In order for the reader to acquire a •... - Page 15 Reader Maintenance Warnings There are several things you should never do when cleaning or using the reader Do not pour the glass cleaner directly on the reader window. • • Do not use alcohol-based cleaners. Never submerge the reader in liquid. •...
