Expectation Setting Document for Fiery X2 V1.01
Digital Front End for 5765, 5790 DocuColor 5750/ 5799
Customer Support
The Xerox Customer Support Centers are available to provide general information, answer questions and take
service calls. You can reach the Customer Support Center at the following toll-free phone numbers:
Your Xerox Color Analyst will provide fee-based training upon request.
General Specifications
Physical and Environmental
Server
Weight
Dimensions
Operating Temperature
Relative Humidity
Altitude
Electrical Requirements and Compliance
Server
Line Voltage
100 to 125 / 200 to 240 VAC RMS single phase, automatically configured
Frequency
50 to 60 Hz single phase
Power
150 W maximum
Fiery X2 Optional Kits
Token Ring Connectivity Kit
X-Rite DTP32 Densitometer
BNC Transceiver
Fiery X2 Specifications
200 MHz R5000 MIPs Processor
160 MB RAM
2 GB IDE hard drive
10/100 BaseT Network capability
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
Post Launch Version
Page 1 of 7
United States
Canada
English Units
12 lb.
10 x 6 x 14 inches
50º - 104º F
5% to 95% (noncondensing)
0 to 10,000 ft.
1-800-821-2797
1-800-939-3769
Metric Units
5.44 kg.
24 x 14.4 x 33.6 cm
10º - 40º C
5% to 95% (noncondensing)
0 to 3,048 m
26 May 1999
X2_Majestik_ced.doc
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Xerox 5750
Summary of Contents for Xerox 5750
-
Page 1: Customer Support
Digital Front End for 5765, 5790 DocuColor 5750/ 5799 Customer Support The Xerox Customer Support Centers are available to provide general information, answer questions and take service calls. You can reach the Customer Support Center at the following toll-free phone numbers:... - Page 2 • order, etc. Print Speed / System Performance The maximum print speed for the X2 system is limited by the print speed of the 5765, 5790 and DocuColor 5750/ • 5799. The 5765, 5790 and DocuColor 5750/ 5799 are document printers; therefore the print engine will not cycle up until •...
- Page 3 The maximum image size from an application is limited to the image size produced by the 5765, 5790 and • DocuColor 5750/ 5799. The application and the 5765, 5790, DocuColor 5750/ 5799 setup controls image position. Non-imageable area for the DocuColor 5790/ 5799 is listed as follows: •...
- Page 4 Optimal print quality is achieved by using a densitometer. For RGB emitting applications (PowerPoint, Word, and • Excel), use the 5765, 5790 and DocuColor 5750/ 5799 calibration target. For CMYK applications (Quark, Pagemaker) use the SWOP target. Print Quality and Color Management The appearance of the document displayed on the monitor screen may not match the output print because the •...
-
Page 5: Reference Material
Expectation Setting Document for Fiery X2 V1.01 Digital Front End for 5765, 5790 DocuColor 5750/ 5799 Reference Material The X2 is shipped with a complete set of documentation for the installation and use of the server. This documentation is in one of two formats and is provided in the Customer Media Package bundled with each server. - Page 6 Provide spared parts (when FSMA is purchased) Provide service (when FSMA is purchased) Xerox responsability when a Field Service Maintenance Agreement (FSMA) is purchased. If FSMA is not purchased, this action becomes a customer responsability Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
- Page 7 Expectation Setting Document for Fiery X2 V1.01 Digital Front End for 5765, 5790 DocuColor 5750/ 5799 Primary Customer X2 Fiery Applications: Special Considerations or performance limitations identified by Xerox and agreed to by the customer: I have reviewed and understand this product information: Customer...
