Expectation Setting Document for the
FIERY Si DRIVER SUMMARY
FIERY Si DRIVER SUMMARY
•
Adobe v4.1 for Windows 95.
•
Adobe v3.0.1 for Windows 3.x (support for install on a local
client only).
•
Adobe v8.3.x for Macintosh.
•
There is no driver support for UNIX.
•
WIN NT 3.5 does not support PS Level 2 from Fiery Si
Server Driver.
•
Adobe PPD's supplied may not fully enable all features with
Win NT 4.0. XJ+ Server support for Win NT 4.0 is for the
beta level at this time. Not all XJ+ Server features are
supported in Win NT 4.0 since Win NT 4.0 does not support
an Adobe Driver.
•
There is no driver support for DOS Applications.
•
Support for the Adobe Driver and function in a networked
Windows environment is the responsibility of the customer.
The supplied driver has been validated to support Windows
on a local client only. Contact Adobe for driver support in a
network Windows environment.
•
Mac OS 8.x is not validated for printing with the v1.2 Sytem
Software.
•
Job notes are not supported when printing with LPR.
Terms and product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
Fiery Si v1.2
NETWORK SPECIFICATIONS
NETWORK SPECIFICATIONS
•
The Fiery Si supports a 10BaseT (RJ 45),10Base5
(Thicknet), or 10Base2(Thinnet) via a transceiver, network
connections.
•
The Fiery Si auto senses the following protocols:
AppleTalk, TCP/ IP, & IPX, as well as the Centronics
Parallel Port.
•
Frame types supported:
-IPX (Ethernet 802.2, Ethernet 802.3 and Ethernet_II)
-AppleTalk (Ethernet_snap)
-TCP / IP (Ethernet _II)
•
Four simultaneous network connections are available in
the Fiery Si compared to eight in the XJ / XJ+ Family.
•
Token Ring is supported as an option using the same IPX
Token Ring kit as the XJ / XJ+ Family.
•
The Token Ring option only supports Novell IPX.
•
Native Novell 4.x is not supported at this time. The Fiery Si
connection is through the Bindery Emulation Mode.
•
Win NT for non-Intel based platforms is not supported at
this time.
•
Novell 4.x AppleTalk connection to the Si is not supported.
•
All NT Support is through TCP/IP only.
•
Win NT printing is through TCP/IP.
•
Win 95 printing is through IPX.
•
Win 3.x printing is through IPX
•
Macintosh printing is through AppleTalk.
Fiery Si v1.2
MajestiK/ Regal/ Empress/ Countess
Launch Version 9/16/97
