Power Mode - CookTek HTF-9500-SH18-1 Owner's Manual

Owner's Manual
For CookTek Single Hobs, Double Hobs, and Woks
COOKING IN POWER MODE
Your CookTek Cooktop has two different cooking modes: Temperature Mode and Power (%) Mode.
NOTE: Woks only operate with Power Mode.
General Operation:
Plug cooktop into a grounded, single-phase receptacle. Models will run on 100-120VAC drawing up
to 1800W depending on model, or on 200-240VAC drawing a maximum of 3500W per hob depending
on model. Check rating plate on the unit to verify the correct voltage and wattage. Voltages below
120VAC or 240VAC can result in less than rated power and slower heating times.
NOTE: For proper operation, an independent dedicated circuit must be used for each unit installed.
Each circuit must be protected with a 20 amp circuit breaker. When your application requires high
intense heat or you want a quick temperature increase, the Power mode should be used.
• Turn the cooktop "ON" by pressing the power button on the user interface.
• Turn the control knob until the desired power % appears on the user interface.
• Turn the control knob to the left to decrease power and to the right to increase power.
• To turn the cooktop or wok off, press the power button. See images below.
IMPORTANT: You can switch between Temperature Mode and Power Mode at any time by pressing
the toggle arrows on the interface (single and double hobs only). See images below.
Power Off Switch Modes
Single Hob
DOC-1868 / Rev A / January 2024
Power Off
Switch Modes
Double Hob
Switch Modes
5
