- Page 1 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks CAUTION: Read all instructions before using these units. DOC-1868 / Rev A / January 2024...
-
Page 2: Table Of Contents
Table of Contents Model Numbers................1 Preparing Your Cooktop..............2 Electrical Installation Requirements..........2 Installation Guidelines..............3-4 Approved for Commercial Use............4 Power Mode..................5 Temperature Mode................6 Double Hobs..................7 Woks....................8 Cleaning and Maintenance..............9 Important Information and Safety Precautions......10-11 Warranty..................11 Clearance and Dimensions............12-19 Troubleshooting................20 Error Codes..................21 DOC-1868 / Rev A / January 2024... -
Page 3: Model Numbers
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks MODEL NUMBERS Countertop Single Hobs: HTF-9500-SH18-1, HTF-9500-SH25-1, HTF-9500-SH35-1 Drop-in Single Hobs: HTD-9500-SH18-1, HTD-9500-SH25-1, HTD-9500-SH35-1 Countertop Double Hobs: HTF-9500-FB25-1, HTF-9500-FB35-1, HTF-9500-SS25-1, HTF-9500-SS35-1 Drop-in Double Hobs: HTD-9500-FB25-1, HTD-9500-FB35-1, HTD-9500-SS25-1, HTD-9500-SS35-1 Countertop Woks: HTF-9500-WK18-1, HTF-9500-WK25-1, HTF-9500-WK35-1... -
Page 4: Preparing Your Cooktop
Before you Begin: Some units may come equipped with a removable IEC power cord. Please make sure that this power cord is firmly attached to your CookTek unit BEFORE plugging the unit into the power receptacle and before attempting operation. -
Page 5: Installation Guidelines
• Do not install the unit near other equipment that generates excessive heat or grease that can be pulled into the CookTek unit by its fan (i.e. griddles, fryers, etc.). • Do not place the unit near items that generate excessive steam that can be pulled into the CookTek unit by its fan (i.e. -
Page 6: Approved For Commercial Use
APPROVED FOR COMMERCIAL USE CookTek cooktops have been tested to be in conformance with UL 197 and CSA C22.2 standards and bear the commercially rated approvals. CookTek’s cooktops have been tested to be in conformance with the European Economic Area standards and bear the CE marking signifying European Conformity. -
Page 7: Power Mode
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks COOKING IN POWER MODE Your CookTek Cooktop has two different cooking modes: Temperature Mode and Power (%) Mode. NOTE: Woks only operate with Power Mode. General Operation: Plug cooktop into a grounded, single-phase receptacle. Models will run on 100-120VAC drawing up to 1800W depending on model, or on 200-240VAC drawing a maximum of 3500W per hob depending on model. -
Page 8: Temperature Mode
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks COOKING IN TEMPERATURE MODE - SINGLE AND DOUBLE HOBS ONLY When your recipe requires a precise and even temperature to be maintained over a period of time, use Temperature Mode. -
Page 9: Double Hobs
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks DOUBLE HOB COOKTOPS • Turn the cooktop “ON” by pressing the power button on the user interface. • The unit defaults to Power Mode. • Each hob has its own, separately controlled Temperature/Power Mode toggle arrows. -
Page 10: Woks
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks WOKS Wok operation is similar to the standard single hob cooktop operation with a few differences. • On wok units, as with cooktop units, after turning the power off, you will notice that the internal cooling fan will continue to run for a short period of time. -
Page 11: Cleaning And Maintenance
For CookTek Single Hobs, Double Hobs, and Woks CLEANING AND MAINTENANCE Your CookTek Induction Cooktop is easy to keep clean. Follow the instructions below. • Turn the unit OFF and remove the plug from any power outlets prior to cleaning. -
Page 12: Important Information And Safety Precautions
• This product may only be serviced by an authorized service agent or by CookTek personnel. Do not attempt to open the unit or perform service of any kind. For service information, contact CookTek at +1 (214) 379-6000. -
Page 13: Warranty
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks • The cooktops/woks are designed to work with CookTek recommended induction compatible cookware only. • Users wearing a pacemaker should consult their doctor or the pacemaker manufacturer prior to operating CookTek induction equipment. The electro-magnetic field may interfere with the proper function of the pacemaker. -
Page 14: Clearance And Dimensions
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks CLEARANCE AND DIMENSIONS Clearance: All units require a minimum clearance of two 2” (51 mm) between all sides of the hous- ing and any surface or obstacle. All drop-in units require a minimum clearance of open space below the unit of 6”... - Page 15 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Countertop Double Hobs, Front-to-Back: HTF-9500-FB25-1, HTF-9500-FB35-1 32.13 4.95 13.50 1.28 Countertop Double Hobs, Side-to-Side: HTF-9500-SS25-1, HTF-9500-SS35-1 18.40 4.95 27.25 1.28 DOC-1868 / Rev A / January 2024...
- Page 16 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Countertop Woks: HTF-9500-WK18-1, HTF-9500-WK25-1, HTF-9500-WK35-1 20.04 7.41 15.60 1.31 Drop-in Single Hobs: HTD-9500-SH18-1, HTD-9500-SH25-1, HTD-9500-SH35-1 13.50 12.75 3.30 12.00 4.00 13.50 2.42 3.59 4.49 12.75 11.25 DOC-1868 / Rev A / January 2024...
- Page 17 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Drop-in Single Hobs Cutout Dimensions - FLUSH MOUNT Drop-in Single Hobs Cutout Dimensions - TOP SURFACE MOUNT DOC-1868 / Rev A / January 2024...
- Page 18 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Drop-in Double Hobs, Front-to-Back: HTD-9500-FB25-1, HTD-9500-FB35-1 26.50 27.25 3.30 12.00 4.00 13.50 2.42 3.73 11.25 12.75 Drop-in Double Hobs, Side-to-Side: HTD-9500-SS25-1, HTD-9500-SS35-1 27.25 13.50 12.75 3.30 4.00 12.00 2.42 3.73 26.50...
- Page 19 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Drop-in Double Hobs Cutout Dimensions - FLUSH MOUNT Drop-in Double Hobs Cutout Dimensions - TOP SURFACE MOUNT DOC-1868 / Rev A / January 2024...
- Page 20 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Drop-in Woks: HTD-9500-WK18-1, HTD-9500-WK25-1, HTD-9500-WK35-1 16.50 15.38 11.34 3.30 4.00 16.50 12.00 2.42 6.12 7.03 11.25 DOC-1868 / Rev A / January 2024...
- Page 21 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks Drop-in Woks Cutout Dimensions - FLUSH MOUNT Drop-in Woks Cutout Dimensions - TOP SURFACE MOUNT DOC-1868 / Rev A / January 2024...
-
Page 22: Troubleshooting
Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks TROUBLESHOOTING Symptom Error Cause Displayed Message • Plug unit into appropriate receptacle. • Make sure that receptacle is energized. • Unit unplugged. • Check wall switches. No power (no lights •... -
Page 23: Error Codes
For CookTek Single Hobs, Double Hobs, and Woks ERROR CODES In the event of a possible malfunction, your CookTek cooktop/wok will display and Error Code on the interface, and the unit will beep the number of times indicated by the error. Please consult the following table when encountering an Error code. - Page 24 Owner’s Manual For CookTek Single Hobs, Double Hobs, and Woks CookTek Induction Systems, LLC Phone: 1-800-908-8726 | +1 214-379-6000 Fax: +1 214-379-6073 Email: ARP@turbochef.com Website: cooktek.com DOC-1868 / Rev A / January 2024...
