ASROCK IMB-1242 Settings Manual

IMB-1242
The terms HDMI ® and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
Revision History
Date Description
September 13, 2023 First Release
December 8, 2023 Second Release
1 : COM Port Pin9 PWR Setting Jumpers
PWR_COM1 (For COM Port1)
PWR_COM2 (For COM Port2)
1-2 : +5V (Default)
2-3 : +12V
2 : ESPI Header (ESPI1)
Pin Signal Name
1 GND
2 ESPI_CLK
3 GND
4 ESPI_CS#
5 ESPI_RESET#
6 GND
7 +3V
8 ESPI_CS#1
9 PLTRST#
10 COM_RST#
11 ESPI_IO0
12 ESPI_IO1
13 ESPI_IO2
14 ESPI_IO3
15 ALERT#1
16 +3VSB
17 Internal Use
18 +5VSB
19 ESPI_ALERT#
20 GND

3 : USB 3.2 Gen1 Header (USB3_3_4)

Pin Signal Name Signal Name Pin
1 DUMMY IntA_PA_D+ 2
3 IntA_PB_D+ IntA_PA_D- 4
5 IntA_PB_D- GND 6
7 GND IntA_PA_SSTX+ 8
9 DUMMY IntA_PA_SSTX- 10
11 DUMMY GND 12
13 GND IntA_PA_SSRX+ 14
15 DUMMY IntA_PA_SSRX- 16
17 DUMMY Vbus 18
19 Vbus 20
4 : 24-pin ATX Power Input Connector
(ATXPWR1)
Pin Signal Name Signal Name Pin
1 +3V +3V 13
2 +3V -12V 14
3 GND GND 15
4 +5V PSON# 16
5 GND GND 17
6 +5V GND 18
7 GND GND 19
8 PWROK_PS NA 20
9 ATX+5VSB +5V 21
10 +12V +5V 22
11 +12V +5V 23
12 +3V GND 24

Jumpers and Headers Setting Guide

PWR_COM2
32
COM2 COM1
31
1
30
VGA1
1
SATA_PWR1
29
USB 3.2 Gen2
28
Top: USB3_2
Bottom: USB3_1
USB 2.0
27
Top: USB2_8
Bottom: USB2_7
26
HDMI1 DP1
25
Mic-In Line-Out
SPDIF1
24
5 : DACC1_PCIE_PWR1
Pin
1 Open: No ACC (Default)
2
3
3
4
1
* Auto clear CMOS when system boot improperly.

6 : TPM Header (TPM1)

Pin Signal Name
1 TPM PWR
3
1 20
5 IRA
7 MISO
9 CLK

7 : USB 2.0 Header (USB2_5_6)

Pin Signal Name
1 USB_PWR
3 P-
5 P+
7 GND
9
8 : SMBUS_TEST1
Pin
1
2
3
4
2 20

9 : Digital Input/Output Pin Header (JGPIO1)

Pin Signal Name
1 19
1 SIO_GP71
3 SIO_GP72
5 SIO_GP73
7 SIO_GP74
9 JGPIOPWR_R
10 : Digital Input/Output Power Select
(JGPIO_PWR1)
1-2: +12V (Default)
2-3: +5V
1 12
11 : Digital Input/Output Default Value
13 24
Setting (JGPIO_SET1)
1-2: Pull-High (Default)
2-3: Pull-Low
12 : Chassis Intrusion Header (CI1_2)
Pin
1-2
Short: Active Case Open
Open: Active Case Open
3-4
1 2 3
PWR_COM1
1
1 1 1
ESPI1
1
USB3_3_4
1
1
M2_M1
1
M2 E1 _
LAN2
LAN1
BUZZ1
DC_4PIN1
1
HD_AUDIO1
1
1
PCIE1
23 22 21 20
Signal Name
1 4
Short: ACC*
PSON#
GND
9
Signal Name Pin
RST# 2
CS# 4
10
MOSI 6
GND 8
GND 10
Signal Name Pin
1 2
USB_PWR 2
P- 4
P+ 6
GND 8
DUMMY 10
9 10
Signal Name
1
GPP_E7
SMB_CLK_MAIN
4
SMB_DATA_MAIN
GND
Signal Name Pin
1 2
GPP_H23 2
GPP_I10 4
GPP_E5 6
GPP_E6 8
GND 10
9 10
1
3
1
3
Signal Name
1
Open: Normal
4
Short: Normal
4 5
1 DACC1_PCIE_PWR1
1
TPM1
ATXPWR1
1
1
USB2_ _
5 6
BIOS
ROM
_
DDR4 B1
_
DDR4 A1 1
SMBUS_TEST1
R 1
IMB-1242
Industrial
JGPIO1
1
CI1_2
PANEL1
1
BAT1
PWR_BAT1_SIO_AT1
CHA_FAN1
1
CPU_FAN1
1
1
HEATER1
1
CLRMOS1

13 : System Panel Header (PANEL1)

Pin Signal Name Signal Name Pin
1 HDLED+
3 HDLED-
5 GND PWRBTN#
7 RESET#
9 GND
14 : Battery Connector (BAT1)
Pin Signal Name
1
1 BAT+
2 GND
2
15 : PWR_BAT1_SIO_AT1
Pin Signal Name
1 PWR_BAT1:
Open: Normal (Default)
2 Short: Charge Battery*
3 SIO_AT1:
Open: ATX Mode (Default)
4 Short: AT Mode
* Only supported by chargeable battery.
16 : Chassis FAN Connector (+12V)
(CHA_FAN1)
Pin Signal Name
1 GND
2 +12V
3 CHA_FAN_SPEED
4 FAN_SPEED_CONTROL

17 : CPU FAN Connector (+12V) (CPU_FAN1)

Pin Signal Name
1 GND
2 +12V
3 CPU_FAN_SPEED
4 FAN_SPEED_CONTROL
18 : HEATER Header (HEATER1)
Pin Signal Name
1 Heater PWR
2 GND
3 NCT

19 : Clear CMOS Header (CLRMOS1)

1-2: Normal (Default)
2-3: Clear CMOS
20 : 4-pin ATX PWR Connector
(DC_4PIN1)
Pin Signal Name
1 GND
2 GND
3 DC Input (12V only)
4 DC Input (12V only)
6
7
8
9
1
10
11
1
12
1
13
14
1
15
16
17
18
19
1 2
PLED+ 2
PLED- 4
6
GND 8
10
9 10
1
2
1
4
4
1
4
1
1 3
1 3
2 4
1 3
