ASROCK IMB-156L Settings Manual

*15G06M054000AK*
P/ N: 15G06M054000AK V1.0
IMB-156
The terms HDMI ® and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
1 : EDP_LVDS Jumpers
EDP_LVDS_J1:
1-2: eDP
2-3: LVDS
EDP_LVDS_J2:
1-2: eDP
2-3: LVDS
* Standard BOM supports LVDS output only.
2 : Clear CMOS Jumper
Open: Normal
Short: Clear CMOS
3 : 4-Pin CPU FAN Connector
(+12V)
4 : DDR3 SO-DIMM Slots
5 : 4-pin ATX PWR Con
(Input +12V or +19V~+24V)
1-2: GND
3-4: DC Input
6 : LVDS Panel Connector
Jumpers and Headers Setting Guide
42 HDMI1
1
EDP_LVDS_J2 1
E DP_LVDS_J1
CLRMOS2
1
41
COM
COM
40
Port 2 Port 1
39
COM
38
VGA1
mini-PCIe
Port 3
VGA2
1
37
36
35
1 1
USB 3.0
Top:
T: USB1
34
LAN1
B: USB0
1
33
32
31
USB 3.0
Top:
30
T: USB3
LAN2
B: USB2
1
1
29
SPDIF1
1
28 27
7 : BL1, BL2
8 : Backlight Volume Control (BLT_VOL1)
PIN Signal Name
1 GPIO_VOL_UP
2 GPIO_VOL_DW
3 PWRDN
4 LVDS1 BLUP
5 LVDS1 BLDW
6 GND
7 GND
9 : Backlight Power Connector (BLT_PWR1)
FAN_SPEED_CONTROL
PIN Signal Name
FAN_SPEED
+12V
1 GND
GND
2 GND
3 BL CTL
1 2 3 4
4 BL EN
2 4
5 LCD_BLT_VCC
6 LCD_BLT_VCC
10 : Panel Power Select (LCD_VCC)
1 3
(PNL_PWR1)
1-2: LVDD: +3V
2-3: LVDD: +5V
4-5: LVDD: +12V
11 : Digital Input / Output Power Select
(JGPIO_PWR1)
1-2: +12V
2-3: +5V
3-4: +5V
4-5: GND
12 : 20-pin ATX Power Input
Connector
13 : System Panel Header
1 2
1
BL1
1
1
BL2
BLT_PWR1 BLT_VOL1
1 1
1
1 1
USB7_S_M2
1
PNL_PWR1
BKT_PWR1
USB2_PWR_H1
1
1
USB2_PWR_H2
USB2_6_7
1
USB6_S_MPCIE1
1
1
1
USB2_4_5
SATA3_1
PWR_COM4
SATA_PWR1
1
LPC1
PWR_JP1 CI1 CI2
JGPIO_SET1
1 1
1
1
LPT_GPIO1
PCIE1
1
1
26 25 24 23 21 20 19 18
22
1
1
10 20
1 11
PLED+
PLED-
PWRBTN#
GND
1
GND
RESET#
GND
HDLED-
HDLED+
3
CPU_FAN1
IMB-156
Industrial
ATX12V1
PLED PWRBTN
PANEL1
JGPIO_PWR1
1
HDLED RESET
1
1
PWR_COM5 PWR_COM6
1
BUZZ1
1 1
COM4 COM5 COM6
17 16
14 : COM Port PWR Setting Jumpers
PWR_COM4 (For COM Port4)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
1-2: +5V
2-3: +12V
15 : 4-Pin Chassis FAN Connector (+12V)
GND
1
2 +12V
FAN_SPEED
3
4 FAN_SPEED_CONTROL
16 : 2-Pin Buzzer Header
17 : COM4, 5, 6 Headers (RS232)
Signal Signal Signal
PIN PIN PIN
Name Name Name
1 DDCD# 3 TTXD 5 GND
2 RRXD 4 DDTR# 6 DDSR#
18 : Digital Input / Output Default Value
Setting (JGPIO_SET1)
1-2: Pull-High
2-3: Pull-Low
19 : Backlight Power Select
(LCD_BLT_VCC) (BKT_PWR1)
1-2: LCD_BLT_VCC: +5V
2-3: LCD_BLT_VCC: +12V
4-5: LCD_BLT_VCC: DC_IN
4
5
6
7
8
9
10
11
12
13
14
15
1
2
Signal Signal
PIN PIN
Name Name
7 RRTS# 9 PWR
8 CCTS# 10 N/A
