1060AW
en
Drive DeVilbiss® 10-Liter Oxygen Concentrator Instruction Guide
WARNING–Read instruction guide before operating this equipment.
ASSEMBLED IN USA
NO SMOKING
es
Guía de instrucciones del concentrador de oxígeno de 10-litros de Drive DeVilbiss®
ADVERTENCIA–Lea la guía de instrucciones antes de poner a funcionar este equipo.
ENSAMBLADO EN EE. UU.
NO FUMAR
fr
Guide d'instructions du concentrateur d'oxygène 10-litres Drive DeVilbiss®
AVERTISSEMENT–Lire le mode d'emploi avant d'utiliser ce dispositif.
ASSEMBLÉ AUX ÉTATS-UNIS
NE PAS FUMER
FPO
Update
front cover
images
Advertisement
Table of Contents
Related Manuals for Drive DeVilbiss 1060AW
Summary of Contents for Drive DeVilbiss 1060AW
- Page 1 WARNING–Read instruction guide before operating this equipment. ASSEMBLED IN USA NO SMOKING Guía de instrucciones del concentrador de oxígeno de 10-litros de Drive DeVilbiss® ADVERTENCIA–Lea la guía de instrucciones antes de poner a funcionar este equipo. ENSAMBLADO EN EE. UU.
-
Page 2: Table Of Contents
Service and Maintenance Guidance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . en - 17 WARNING Under certain circumstances, oxygen therapy can be hazardous . Seek medical advice before using an oxygen concentrator . Increase Drive DeVilbiss 10-Liter Concentrator EN - 2 SE-1060AW... -
Page 3: Symbol Definitions
Resonance Environment IMPORTANT SAFEGUARDS Read this entire guide before using your Drive DeVilbiss concentrator . Important safeguards are indicated throughout this guide . Pay special attention to all safety information . Imminently and potentially hazardous information is highlighted by these terms: DANGER Indicates an imminently hazardous situation which could result in death or serious injury to the user or operator if not avoided . - Page 4 6 . Open flames during oxygen therapy are dangerous and are likely to result in fire or death. Do not allow open flames within 2 m (6.5 feet) of the oxygen concentrator or any oxygen carrying accessories . 7 . Drive DeVilbiss oxygen concentrators are equipped with a fire mitigating outlet fitting that prevents propagation of fire into the unit. WARNING 1 .
- Page 5 WARNING Risk of injury or damage When the device is operated at the extremes of the environmental operating specifications (i.e., maximum temperatures and humidity), and in a single fault condition, which is a single component or performance malfunction, such as a blocked exhaust vent, blocked air intake, or an internal cooling fan failure, the temperature of the air coming out of the exhaust vents, located on the bottom left and bottom right sides of the unit can reach temperatures capable of causing a burn injury (see stated temperature and contact time values in the model specific tables below).
-
Page 6: Introduction
Indications For Use The DeVilbiss 1060AW 10 Liter oxygen concentrator is intended to provide supplemental oxygen to patients requiring oxygen therapy . The device may be used in the home or an institutional setting . The device is not intended to be life sustaining or life supporting . -
Page 7: Important Parts Of Your Concentrator
IMPORTANT PARTS OF YOUR CONCENTRATOR Please take time to familiarize yourself with your Drive DeVilbiss oxygen concentrator before operating . Replace Images Insert Filter Pictures Front & Back View (Figure A & B) Control Panel Label (Figure C & D) Control Panel / Operation (LED indicator panel) NOTE - Symbols on control panel are outlined b&w when not active and... -
Page 8: Setting Up Your Concentrator
Keep the oxygen concentrator and cannula at least 2 m (6.5 feet) from hot, sparking objects or naked sources of flame. Drive DeVilbiss oxygen concentrators are equipped with a fire mitigating outlet fitting that prevents propagation of fire into the unit . -
Page 9: Operation
Green Good O2 LED illuminates and will remain lit . The start-up mode may take up to 15 minutes . . NOTE– DeVilbiss recommends for optimal service life that the Drive DeVilbiss Oxygen Concentrator be operated for at least 30 minutes after it is powered on. Shorter periods of operation, operating in extreme temperature/humidity conditions or in the presence of contaminates, and/or handling and storage conditions outside those specified, may affect the long term reliable operation of the product. - Page 10 Cabinet Air Filter The cabinet air filter should be inspected when the Check Cabinet Filter LED illuminates and cleaned as needed by the user or caregiver. Replace if torn or damaged. To clean, follow these steps: NOTE– Frequency of inspection and cleaning of filter may be dependent upon environmental conditions like dust and lint. 1.
-
Page 11: Troubleshooting
TROUBLESHOOTING The following troubleshooting chart will help you analyze and correct minor oxygen concentrator malfunctions . If the suggested procedures do not help, call your biomed technician . Do not attempt any other maintenance . WARNING To avoid electric shock, do not plug the concentrator into an AC outlet if the concentrator cabinet is broken . Do not remove the concentrator cabinet . The cabinet should only be removed by an appropriately trained biomed technician . -
Page 12: Overview Of Alarms And Service Indicators
OVERVIEW OF ALARMS AND SERVICE INDICATORS This device contains an alarm system which monitors the state of the device and alerts of abnormal operation, loss of essential performance or failures . Alarm conditions are shown on the control panel. The alarm system functions are tested at power up by lighting all visual alarm indicators and sounding the audible alarm (beep). All alarms are Low Priority Technical Alarms . -
Page 13: Specifications
SPECIFICATIONS DRIVE DEVILBISS 10 - LITER SERIES Catalog Number 1060AW Delivery Rate 1 to 10 LPM Maximum Recommended Flow (@ nominal 10 LPM outlet pressures of zero and 7 kPa)** Outlet Pressure 8.5 ± 0.5 psig (58.6 ± 3.5 kPa) Electrical Rating 230 V~, 50 Hz, 3 .2 Amp... -
Page 14: Electromagnetic Compatibility Information
NOTE – Recommendations for preventative maintenance at 3-year intervals are outlined in the Service and Maintenance Guidance below. Drive DeVilbiss Healthcare recommends that at least the following procedures be carried out by the manufacturer or a qualified third party between uses by different patients. -
Page 15: Service And Maintenance Guidance
Exposure time of the disinfectant solution should be 10 minutes minimum to 15 minutes maximum . After the recommended exposure time, all surfaces of the concentrator should be wiped with a clean lint-free cloth dampened with drinking quality water no warmer than room temperature. - Page 16 EN - 16 SE-1060AW...
- Page 17 SE-1060AW EN - 17...
- Page 18 EN - 18 SE-1060AW...
- Page 20 FRANCE +33 (0) 3 83 495 495 ASSEMBLED IN USA SE-1060AW Rev A DRAFT 10-9-23 DeVilbiss Healthcare LLC • 100 DeVilbiss Drive • Somerset, PA 15501 • USA 800-338-1988 • 814-443-4881 • www.drivemedical.com DeVilbiss and OSD are registered trademarks of DeVilbiss Healthcare .
