Summary of Contents for Imesa ES7PEHP
- Page 1 Operating Instructions Tumble dryer IMESA ES7PEHP...
- Page 3 Operating Instructions Tumble dryer IMESA ES7PEHP Dear IMESA customer! Welcome to the family of IMESA customers. We hope that you will have many years of use from your new machine. The machine has many features. To make the most of its functions, we recommend that you read the operating instructions before using the machine.
-
Page 4: Table Of Contents
Contents Before using your machine for the first Troubleshooting time The machine will not start Language selection The machine loses all power during a programme Safety instructions The machine leaks water Safety Drying takes too long Transport/Winter storage Error messages Packing material Technical information Recycling... -
Page 5: Before Using Your Machine For The First Time
Before using your machine for the first time Language selection You will be prompted to select the display language when you have connected your machine and start it for the first time. Do as follows: 1. Turn the programme selector to choose from: US English, English, Svenska, Dansk, Norsk, Suomi, Français, Deutsch, Italiano, Espanol, Русский, Nederlands. -
Page 6: Safety Instructions
Safety instructions Read the operating instructions Safety and keep them in a safe place! • The machine must not be used for drying items that have been dry-cleaned at home or fabrics that may contain residues of flammable liquids. • A float shuts off the machine in the event of a blockage in the condensed water hose or if there is a risk of the condensed water container overflowing. -
Page 7: Child Safety
Child safety General Activating/deactivating Child-safe start. WARNING! Do as follows to open the settings menu: Do not allow children to play with 1. Turn off the machine using the main power the tumble dryer. switch. • If the door is opened when a programme is 2. -
Page 8: Description Of The Tumble Dryer
Description of the tumble dryer 1. Main power switch 5. Lint filter 2. Condensed water container 6. Outer door 3. Panel 7. Evaporator and filter 4. Type plate... -
Page 9: Advice And Tips Before You Tumble-Dry
Advice and tips before you tumble-dry Static electricity Here are some tips that may help you before you begin tumble-drying. To reduce the risk of static electricity in the laundry after tumble drying you can: Have the clothes been spun? •... -
Page 10: Tumble Drying
Tumble drying Below are step-by-step instructions to help you achieve the best possible tumble-drying results. Sort your fabrics You will achieve the most uniform drying results if the items are made of the same type of material. Do up zips and buttons, fasten belts, sort the items and adjust the load and temperature. -
Page 11: Select The Programme
Tumble drying Select the programme Start Stop Programme selector Programme name Select a programme by turning the programme selector. The selected programme is shown in the display window. Guidelines as to what specific Auto extra dry (low temperature) programmes can be used for: Energy Save. - Page 12 Tumble drying Programme chart Here we present the energy and time consumption of a few different programmes. The table shows the effect of using different spin speeds when washing the load. Consumption can vary depending on room temperature, humidity, load, variations in the power supply and selected options. For the consumption values given below, the requirements are as follows: Temperature of intake air: 23 °C...
-
Page 13: Press The Start Button
Tumble drying Press the Start button Remaining drying time TIP! An estimate of the remaining drying time will be shown on the display a few minutes after The condensed water is decalcified and can be the drying programme starts. For example, 1:35 used in steam irons. -
Page 14: Settings
Settings You can carry out the following settings • Language • Child-safe • Audible Volume How to choose the settings: Do as follows to open the settings menu: 1. Turn off the machine using the main power switch. 2. Press the Stop button and switch on the machine with the main power switch. Then press the Stop button 5 times within 10 seconds. -
Page 15: Care And Cleaning
Care and cleaning Cleaning the lint filter 3. Use your hand or a soft cloth to remove the lint The lint filter must be cleaned after each load. from all sides of the filter. If necessary, use a 1. Grasp the filter holder handle and pull it damp sponge and a small amount of washing- towards you to open the lint filter. -
Page 16: Emptying The Condensed Water Container
Care and cleaning Emptying the condensed water 2. Remove the plinth. container 3. Open the evaporator door. 4. Pull out the filter by grasping the "handle" in the middle. If you have not connected the machine to a separate drain the condensed water container must be emptied after each load. -
Page 17: Cleaning The Auto Filter
Care and cleaning Cleaning the auto filter 6. Remove the foam filter (B) found behind the net filter. Wash the foam filter in a washing machine Clean the filter at the intervals shown on the using a rinse or quick wash programme. No machine's display or more often detergent or hot wash is necessary. -
Page 18: Troubleshooting
Troubleshooting The machine will not start Error messages • If Over Flow appears on the display, the Check condensed water container is full or the • that the door is properly closed. evaporator filter is blocked. Empty the • that the main power switch is on. container, clean the filter and restart the •... -
Page 19: Technical Information
Technical information Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight (net): 52 kg Cylinder volume: 112 l Max. drying capacity: 7 kg Speed: 50-55 rpm Rated power: See type plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel. -
Page 20: Information On Energy Labelling
Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 392/2012 Imesa Model designation IMESA ES7PEHP Max. drying capacity 7 kg Energy efficiency class Annual energy consumption (AE 212 (kWh/year) Energy consumption Auto normal dry with full load (E... -
Page 21: Service
Service Before contacting the service division See the Troubleshooting and Care and cleaning chapters to see whether you can rectify the problem. If you need to contact the service division, make sure that you know the model designation, type designation and serial number. The model designation (1) can be found on the first page of the operating instructions and on the machine panel. -
Page 22: Positioning The Tumble Dryer
The tumble dryer can be placed on top of a 4. Attach the plastic cups for fixing the tumble IMESA washing machine. Use the two foot cups dryer’s front feet to the washing machine’s found in the document bag included with the top cover. -
Page 23: Adjusting The Feet
Installation left-hand side. Then remove the paper from 8. Lower the tumble dryer’s front feet into the the self-adhesive surface under the plastic plastic cups and adjust the tumble dryer to cups. ensure it is level. 5. Fit the plastic cups so that the “tags” marked Adjusting the feet with arrows are against the front edge or side edge of the cover and press them firmly onto... - Page 24 Installation Connection on delivery • 230V, 1-Phase, 10A • 50Hz • Use a type A residual-current device.
-
Page 25: Door Hanging
Door hanging 1. Hinge pins (top and bottom) 4. Locking hook 2. Cover plate 5. Hinges (left + right side) 3. Plastic plugs (on the upper and lower edges) 6. Plinth... -
Page 26: Follow These Instructions
Door hanging You can choose whether the door is hung on the right or the left. Follow these instructions: 1. Remove the plinth. 2. Remove the hinge, two screws. 8. Reattach the inner part of the door with the screws (13 in total). 9. -
Page 27: Quick Guide
Quick guide Fabrics Press the Start button • Dry fabrics of the same type together to ensure that they dry as evenly as possible. Turn on the main power Drying programme finished switch • Done appears on the display when the programme is finished. - Page 28 Art. No.: 8094267. Rev. 02. We reserve the right to make changes. TD70.C SPK HP en (10-13)
