- Page 1 Electric height adjustable desk Assembly instructions 2-leg standing desk 2-leg standing meeting table NOTICE! If you're building a desk with 3 legs, please follow the instructions that are included in the 3rd Leg Box.
-
Page 2: Package Contents
PACKAGE CONTENTS DESK COMPONENTS Crossbar rail Side bracket Feet Extension bar* * Extension bars are included only with table tops of 2400mm length. HARDWARE 2mm rubber Screw clamp M8x14 5mm rubber M6x12 M6x10 Screw guide bush Control box Handset* Power cable Leg cable Hex key Tapping screw 5x20... - Page 3 ASSEMBLY INSTRUCTIONS Screw clamp 2mm rubber 5mm rubber Screw guide bush M6x12...
- Page 4 M6x12 NOTICE! If you're building a table with length 2400 mm, please proceed to page 10.
- Page 5 Rectangular shape table top M6x10 M8x14 Wave shape table top M6x10 M8x14...
- Page 6 L-shape table top ! Use the longer feet and side bracket that is included in your package for the deepest side of the table top. M6x10 M8x14...
- Page 7 5-10cm 5-10cm Handset Tapping screw 5x20 Control box Tapping screw 5x16...
-
Page 8: Underside View
Power cable Leg cable Underside view... - Page 9 Assembly instructions - 2 leg desk English Step 1 (D3) The crossbar rails are compressed when delivered. 1. Loosen the set screws slightly and extend the inner rail. 2. Attach rubber bushing (H6) and plastic screw guide bushing (H4) on the thicker part of the crossbar rail. 3.
- Page 10 2-LEG TABLE 2400 MM M8x14 M6x10...
- Page 11 2-LEG TABLE 2400 MM 15-20cm 15-20cm Handset Tapping screw 5x20 Control box Tapping screw 5x16...
- Page 12 2-LEG TABLE 2400 MM Power cable Leg cable Underside view...
- Page 13 Assembly instructions - 2 leg meeting table English Step 1 (D3) The crossbar rails are compressed when delivered. 1. Loosen the set screws slightly and extend the inner rail. 2. Attach rubber bushing (H6) and plastic screw guide bushing (H4) on the thicker part of the crossbar rail.
- Page 14 Assembly instructions - 2 leg meeting table English Step 8 1. Connect the handset (H11) into the control box (H10) in port labelled “HS”. 2. Connect the leg cable which is nearest to the control box in port labelled “M2”. 3.
