Enter Differential Counts - Modulus COMP-U-DIFF 10-329 Operating Manual

TO ENTER DIFFERENTIAL COUNTS (CONTINUED)
1. Press the [COUNT] key until the word TOTAL is displayed on the screen.
2. Enter differential counts by depressing the appropriate key for each category (i.e.
SEGS, BANDS, MONOS, etc.).
3. Each time a count is entered, both the corresponding channel count and the total
count are increased by one and, an audible click will be heard (except for non-
totalizing channel where the count is deposited only in associated channel, but
not in the total count).
ADDITIONAL CELL CATEGORIES
To expand the COMP-U-DIFF Cell counting capabilities to accommodate more then
12 categories the user may redefine channels 9 and 10. The default for these
channels is:
Channel 9
Channel 10
The comment codes 801-807 are reserved for assigning cell types to channel 9 and
codes 901-907 are reserved for channel 10 (see exhibit 3). To assign cells to these
channels follow the steps described below (see comment entry).
1. Press [MORPH] key repeatedly until the comment screen is reached.
2. Press [INC] and [DEC] keys to access the required comment field.
3. Enter a valid cell category change comment.
4. Press [EXEC] key to save the comment.
5. The selected cell category is automatically inserted at the correct print location
on the ticket.
Promyelocyte
Immature Cells
9
