DIFFCOUNT III ä
MODEL 10-312P
DIFFERENTIAL CELL COUNTERS
INSPECTION
Carefully unpack and examine your new unit for any accidental shipping damage. If damaged,
contact the carrier for claim filing instruc<ons. Save all packing materials un<l all claims are
se?led.
DESCRIPTION
DIFFCOUNT III is the world's finest product line of differen<al cell counters, providing a fast and
reliable means for tallying various leukocyte categories and conver<ng each cell category into
percentage of total count. All cell coun<ng categories and the TOTAL cell count are shown
simultaneously, each on its own display. DIFFCOUNT III is easy to use. All models feature soK-
touch keys, a calculator-type keyboard designed for operator comfort, and easily changed key
assignments.
OPERATION
Check the electrical specifica<on of the wall power adaptor. It must be the same as your local
power (i.e., 110 or 220 AC), to provide an output of 9 volts AC at 200 mA to the DIFFCOUNT III.
POWER ON/OFF SWITCH
Switch power to the ON posi<on. The power switch is located on the rear panel, next to the
power input socket. All channels should display zeros and the word TOTAL should appear on the
display. If your DIFFCOUNT will not turn on, check your electrical outlet. If there is power at the
outlet, then inspect the instrument fuse. (Fuse=1Amp. Slow- Blow type).
CLEAR KEY
Before beginning a new count, the contents of the memory must be erased. By pressing the
CLEAR key, the operator clears the memory and prepares the unit for the next specimen count.
Advertisement
Table of Contents
Related Manuals for Modulus DIFFCOUNT III 10-312P
Summary of Contents for Modulus DIFFCOUNT III 10-312P
- Page 1 DIFFCOUNT III ä MODEL 10-312P DIFFERENTIAL CELL COUNTERS INSPECTION Carefully unpack and examine your new unit for any accidental shipping damage. If damaged, contact the carrier for claim filing instruc<ons. Save all packing materials un<l all claims are se?led. DESCRIPTION DIFFCOUNT III is the world's finest product line of differen<al cell counters, providing a fast and reliable means for tallying various leukocyte categories and conver<ng each cell category into percentage of total count.
- Page 2 COUNTING KEYS Each <me a coun<ng key is pressed, the corresponding display is increased by one and a "click" will be heard. An "alert tone" also will be given for each 100 cells counted. DECREMENT FUNCTION To subtract one count from any channel, hold down the COUNT key and press the key for the channel you wish to decrease.
- Page 3 NON-TOTAL KEY DIFFCOUNT III units are factory-set with the UPPER RIGHT key as NON-TOTALIZING. This feature is an op<on. If you wish to change all keys to count into the grand total, refer to the following instruc<ons: Unplug the unit and turn it over. Remove the four retaining screws and remove the case top, being careful not to damage the LCD ribbon cable.
- Page 4 WARRANTY Modulus Data Systems, Inc., warrants the DIFFCOUNT against defects in manufacturing workmanship or materials), for a period of twelve (12) months from the date of receipt by the user. The units will be repaired or replaced without charge provided it has received normal and proper usage according to the instruc<ons provided on this card.
- Page 5 SPECIFICATIONS DIMENSIONS Width: 6 in. (15 cm); Depth 9 in. (23 cm); Height: 2 ¼ in. (6 cm) ELECTRICAL 110-125 VAC, 50-60 Hz, 5 wa?s Max. 220-250 VAC, 56-60 Hz (Op<onal power adaptor) TEMPERATURE 32-120 Degrees F (0-49 Degrees C) ADDITIONAL ACCESSORIES AND PARTS 10-008 Extra key assignment overlays for 10-308.
