- Page 1 w e l l m a d e f o r e v e r Two-Piece Toilet INSTALLATION INSTRUCTIONS www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com @SwissMadison #WellMadeForever...
-
Page 2: Prior To Installation
All dimensions are nominal! Be sure to measure your toilet prior to installation. • The step-by-step guidelines in the installation instructions are a general reference. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. •... -
Page 3: Installation
INSTALLATION TWO-PIECE TOILET INSTALLATION: Turn Off Water Supply Rough-In the Toilet • Close toilet supply valve and flush tank • Measure the wall from behind the toilet to completely, use towel to remove excess water. the middle of the closet bolt. Your rough-in •... - Page 4 INSTALLATION TWO-PIECE TOILET Install Toilet • Position toilet square to wall and with a rocking motion, press down fully on wax ring. Alternately tighten nuts until toilet is firmly sealed to floor. Do not overtighten. • Smooth off the bead of sealant around the base. Remove excess sealant. •...
- Page 5 INSTALLATION TWO-PIECE TOILET Position Tank onto Bowl Secure Tank to Bowl • Holes should line up so threaded • Slide metal washer & rubber washer onto bolt. rod can fit smoothly connecting • Thread bolts into the bottom of the tank then the cistern body to the bowl.
- Page 6 INSTALLATION TWO-PIECE TOILET Connect Push Button • Unscrew the big white nut on the push button and insert the button into the hole on the tank. • When the rods meeet the push buttons, measure the height (H) with a ruler. •...
- Page 7 INSTALLATION TWO-PIECE TOILET TOILET SEAT INSTALLATION Disassemble Construct Hinges • Insert screw and nut into the hole on the hinge. • Disassemble the cover cap and the hinge. • Attach blind hole screw fixing to the bottom of screw. Pull Attach Hinges Adjust and Cover Hinges •...
- Page 8 INSTALLATION TWO-PIECE TOILET Adjust and Attach Seat • Align seat to the hinges then firmly tighten the hinges. • Attach seat to the secure hinges. • Adjust seat to align to the bowl. TOILET SEAT USAGE • To remove, push middle button until you hear a “click”, then pull straight up. •...
-
Page 9: One-Year Limited Warranty
® customers with beautiful, durable, long-lasting products. Should there be any defects in materials or craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison ® will provide replacement parts at no charge, or at its discretion, replace any product or part of the product that is deemed defective, under normal installation, use, service or maintenance.
