HIKVISION HiWatch HWI-D620H-Z User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
Hikvision HWI-
D620H-Z HWI-D620H-Z
o cerca il tuo prodotto tra le
migliori offerte di Videosorveglianza
Network Camera User Manual
Network Camera
User Manual
UD09513B
0

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION HiWatch HWI-D620H-Z

Summary of Contents for HIKVISION HiWatch HWI-D620H-Z

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Hikvision HWI- D620H-Z HWI-D620H-Z o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Network Camera User Manual Network Camera User Manual UD09513B...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS DATA DOCUMENTATION, CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL...
  • Page 4 Network Camera User Manual The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
  • Page 5 Network Camera User Manual  Make sure the power supply voltage is correct before using the camera.  Do not drop the camera or subject it to physical shock.  Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.
  • Page 6 Network Camera User Manual body so that the foam ring and the dome cover are attached seamlessly.

  • Page 7: Table Of Contents

    Network Camera User Manual Table of Contents Chapter 1 System Requirement ................10 Chapter 2 Network Connection ................11 Setting the Network Camera over the LAN ............11 Wiring over the LAN......................11 Activating the Camera ....................12 (Optional) Setting Security Question ................19 Setting the Network Camera over the WAN ............
  • Page 8 Network Camera User Manual Maintenance ....................51 Upgrade & Maintenance ....................51 Log ..........................52 System Service ........................ 53 Security Settings .................... 54 Authentication ........................ 54 IP Address Filter ......................55 Security Service....................... 56 User Management ..................57 User Management ......................57 Security Question ......................
  • Page 9 Network Camera User Manual Configuring Display Settings ................94 Day/Night Auto-Switch ....................94 Day/Night Scheduled-Switch ..................98 Configuring OSD Settings ................99 Configuring Privacy Mask ................101 Configuring Picture Overlay ................102 Chapter 10 Event Settings ................104 Basic Events ....................104 10.1.1 Configuring Motion Detection ..................
  • Page 10 Network Camera User Manual Chapter 13 Picture ..................167 Chapter 14 Application .................. 168 Face Capture Statistics.................. 168 People Counting Statistics ................168 Heat Map Statistics ..................169 Counting Statistics ..................170 Appendix ......................172 Appendix 1 SADP Software Introduction ............... 172 Appendix 2 Port Mapping ..................

  • Page 11: Chapter 1 System Requirement

    Network Camera User Manual Chapter 1 System Requirement Operating System Microsoft Windows XP SP1 and above version 2.0 GHz or higher 1G or higher Display 1024×768 resolution or higher Web Browser Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 30.0 and above version and Google Chrome 31.0 and above version.

  • Page 12: Chapter 2 Network Connection

    Network Camera User Manual Chapter 2 Network Connection Note:  You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center.

  • Page 13: Activating The Camera

    Network Camera User Manual computer with a network cable as shown in Figure 2-1.  Refer to the Figure 2-2 to set network camera over the LAN via a switch or a router. Connecting Directly Connecting via a Switch or a Router Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera.
  • Page 14 Network Camera User Manual to search the IP address. Activation via Web Browser 3. Create and input a password into the password field. A password with user name in it is not allowed. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 15 Network Camera User Manual 2. Check the device status from the device list, and select the inactive device. Select inactive device. Input and confirm password. SADP Interface Note: The SADP software supports activating the camera in batch. Refer to the user manual of SADP software for details.
  • Page 16 Network Camera User Manual failed, please make sure that the password meets the requirement and try again. 5. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address 6.
  • Page 17 Network Camera User Manual the figure below. Control Panel 2. Click the Device Management icon to enter the Device Management interface, as shown in the figure below.
  • Page 18 Network Camera User Manual Device Management Interface 3. Check the device status from the device list, and select an inactive device. 4. Click the Activate button to pop up the Activation interface. 5. Create a password and input the password in the password field, and confirm the password.
  • Page 19 Network Camera User Manual Activation Interface (Client Software) 6. Click OK button to start activation. 7. Click the Modify Netinfo button to pop up the Network Parameter Modification interface, as shown in the figure below. Modifying the Network Parameters 8. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.

  • Page 20: (Optional) Setting Security Question

    Network Camera User Manual (Optional) Setting Security Question Security question is used to reset the admin password when admin user forgets the password. Admin user can follow the pop-up window to complete security question settings during camera activation. Or, admin user can go to User Management interface to set up the function.

  • Page 21: Dynamic Ip Connection

    Network Camera User Manual 5. Visit the network camera through a web browser or the client software over the internet. Accessing the Camera through Router with Static IP Connecting the network camera with static IP directly  You can also save the static IP in the camera and directly connect it to the internet without using a router.
  • Page 22 Network Camera User Manual with port mapping. Note: Refer to Appendix 2 for detailed information about port mapping. 5. Apply a domain name from a domain name provider. 6. Configure the DDNS settings in the setting interface of the router. 7.
  • Page 23 Network Camera User Manual 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to Section 7.1.2 Configuring DDNS Settings for detailed configuration. 3. Visit the camera via the applied domain name.

  • Page 24: Chapter 3 Access To The Network Camera

    Network Camera User Manual Chapter 3 Access to the Network Camera Accessing by Web Browsers Note: For certain camera models, HTTPS is enabled by default and the camera creates an unsigned certificate automatically. When you access to the camera the first time, the web browser prompts a notification about the certificate issue.

  • Page 25: Accessing By Client Software

    Network Camera User Manual 4. Click Login. 5. (Optional) Install the plug-in before viewing the live video and operating the camera. Follow the installation prompts to install the plug-in Note: If you are using Google Chrome 45 and its above version or Mozilla Firefox 52 and its above version, plug-in installation is not required.
  • Page 26 Network Camera User Manual iVMS-4200 Main View...

  • Page 27: Chapter 4 Wi-Fi Settings

    Network Camera User Manual Chapter 4 Wi-Fi Settings Purpose: By connecting to the wireless network, you don’t need to use cable of any kind for network connection, which is very convenient for the actual surveillance application. Note: This chapter is only applicable for the cameras with the built-in Wi-Fi module. Configuring Wi-Fi Connection in Manage and Ad-hoc Modes Purpose:...
  • Page 28 Network Camera User Manual 3. Click to choose a wireless connection on the list. Wi-Fi Setting- Manage Mode 4. Check the radio button to select the Network mode as Manage, and the Security mode of the network is automatically shown when you select the wireless network, please don’t change it manually.
  • Page 29 Network Camera User Manual 2. Customize a SSID for the camera. 3. Choose the Security Mode of the wireless connection. 4. Enable the wireless connection function for your PC. 5. On the PC side, search the network and you can see the SSID of the camera listed.
  • Page 30 Network Camera User Manual WEP Mode Authentication - Select Open or Shared Key System Authentication, depending on  the method used by your access point. Not all access points have this option, in which case they probably use Open System, which is sometimes known as SSID Authentication.
  • Page 31 Network Camera User Manual Choose the type of client/server authentication being used by the access point; EAP-TLS or EAP-PEAP. EAP-TLS EAP-TLS Identity - Enter the user ID to present to the network.  Private key password – Enter the password for your user ID. ...

  • Page 32: Easy Wi-Fi Connection With Wps Function

    Network Camera User Manual strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.
  • Page 33 Network Camera User Manual PBC Mode: PBC refers to the Push-Button-Configuration, in which the user simply has to push a button, either an actual or virtual one (as the button on the configuration interface of the IE browser), on both the Access Point (and a registrar of the network) and the new wireless client device.

  • Page 34: Ip Property Settings For Wireless Network Connection

    Network Camera User Manual Use PIN Code If the PIN code is generated from the router side, you should enter the PIN code you get from the router side in the Router PIN code field. 3. Click Connect. You can generate the PIN code on the camera side. And the expired time for the PIN code is 120 seconds.
  • Page 35 Network Camera User Manual Setting WLAN Parameters 3. Customize the IPv4 address, the IPv4 Subnet Mask and the Default Gateway. The setting procedure is the same with that of LAN. If you want to be assigned the IP address you can check the checkbox to enable the DHCP.

  • Page 36: Chapter 5 Live View

    Network Camera User Manual Chapter 5 Live View Live View Page Purpose: The live view page allows you to view the real-time video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network camera to enter the live view page, or you can click Live View on the menu bar of the main page to enter the live view page.

  • Page 37: Starting Live View

    Network Camera User Manual For IE (Internet Explorer) users, plug-ins as webcomponents and quick time are selectable. And for Non-IE users, webcomponents, quick time, VLC or MJPEG are selectable if they are supported by the web browser. Note: If you are using Google Chrome 45 and its above version or Mozilla Firefox 52 and its above version, plug-in installation is not required.

  • Page 38: Recording And Capturing Pictures Manually

    Network Camera User Manual Icon Description Manually start/stop recording. Audio on and adjust volume /Mute. Turn on/off microphone. Start/stop digital zoom function. Note: The icons vary according to the different camera models. Recording and Capturing Pictures Manually In the live view interface, click on the toolbar to capture the live pictures or click to record the live view.
  • Page 39 Network Camera User Manual PTZ Control Panel Click the zoom/focus/iris buttons to realize lens control. Notes:  There are eight direction arrows ( , ) in the control panel. Click the arrows to realize adjustment in the relative positions.  For the cameras which support lens movements only, the direction buttons are invalid.

  • Page 40: Setting/Calling A Preset

    Network Camera User Manual Setting/Calling a Preset  Setting a Preset: 1. In the PTZ control panel, select a preset number from the preset list. Setting a Preset 2. Use the PTZ control buttons to move the lens to the desired position. •...

  • Page 41: Setting/Calling A Patrol

    Network Camera User Manual Calling a Preset Setting/Calling a Patrol Note: No less than 2 presets have to be configured before you set a patrol. Steps: 1. Click to enter the patrol configuration interface. 2. Select a path No., and click to add the configured presets.

  • Page 42: Chapter 6 Network Camera Configuration

    Network Camera User Manual Chapter 6 Network Camera Configuration Configuring Local Parameters Purpose: The local configuration refers to the parameters of the live view, record files and captured pictures. The record files and captured pictures are the ones you record and capture using the web browser and thus the saving paths of them are on the PC running the browser.
  • Page 43 Network Camera User Manual TCP: Ensures complete delivery of streaming data and better video quality, yet the real-time transmission will be affected. UDP: Provides real-time audio and video streams. HTTP: Allows the same quality as of TCP without setting specific ports for streaming under some network environments.

  • Page 44: Configure System Settings

    Network Camera User Manual clipped video files. Valid for the pictures you capture with the web browser.  Save snapshots in live view to: Set the saving path of the manually captured pictures in live view mode.  Save snapshots when playback to: Set the saving path of the captured pictures in playback mode.

  • Page 45: Configuring Time Settings

    Network Camera User Manual Online Upgrade Note: When the camera is upgrading, don't power off the camera. During upgrading, the camera may not be accessible. You need to wait 1 or 2 minutes before the upgrade finishes. Configuring Time Settings Purpose: You can follow the instructions in this section to configure the time synchronization and DST settings.
  • Page 46 Network Camera User Manual (1) Click to enable the NTP function. (2) Configure the following settings: Server Address: IP address of NTP server. NTP Port: Port of NTP server. Interval: The time interval between the two synchronizing actions with NTP server.

  • Page 47: Configuring Rs232 Settings

    Network Camera User Manual Time Sync Manually Click Save to save the settings.  Configuring RS232 Settings The RS232 port can be used in two ways:  Parameters Configuration: Connect a computer to the camera through the serial port. Device parameters can be configured by using software such as HyperTerminal.

  • Page 48: Configuring Rs485 Settings

    Network Camera User Manual RS232 Settings Note: If you want to connect the camera by the RS232 port, the parameters of the RS232 should be exactly the same with the parameters you configured here. 3. Click Save to save the settings. Configuring RS485 Settings Purpose: The RS485 serial port is used to control the PTZ of the camera.

  • Page 49: Configuring Dst Settings

    Network Camera User Manual RS-485 Settings 2. Set the RS485 parameters and click Save to save the settings. By default, the Baud Rate is set as 9600 bps, the Data Bit is 8, the stop bit is 1 and the Parity and Flow Control is None. Note: The Baud Rate, PTZ Protocol and PTZ Address parameters should be exactly the same as the PTZ camera parameters.

  • Page 50: Configuring External Devices

    Network Camera User Manual DST Settings 2. Select the start time and the end time. 3. Select the DST Bias. 4. Click Save to activate the settings. Configuring External Devices Purpose: For the device supported external devices, including the wiper on the housing or the LED light, you can control them via the Web browser.

  • Page 51: Configuring Vca Resource

    Network Camera User Manual the Start Time and End Time. Set Schedule  Auto: The LED will be turned on according to the environment illumination. 5. Click Save to save the settings. Configuring VCA Resource Purpose: VCA resource offers you options to enable certain VCA functions according to actual need when several VCA functions are available.

  • Page 52: Open Source Software License

    Network Camera User Manual the others are hidden. The function may not be supported by some camera models. • Open Source Software License Information about the open source software that applies to the IP camera can be checked if required. Go to Configuration > System Settings > About. Maintenance Upgrade &...

  • Page 53: Log

    Network Camera User Manual encryption password is required when you import the file to other cameras. Diagnose Information: click to download log and system information.  Import Config. File Configuration file is used for the batch configuration of the cameras. Steps: 1.

  • Page 54: System Service

    Network Camera User Manual Log Searching Interface 2. Set the log search conditions to specify the search, including the Major Type, Minor Type, Start Time and End Time. 3. Click Search to search log files. The matched log files will be displayed on the log list interface.

  • Page 55: Security Settings

    Network Camera User Manual ABF (Auto Back Focus), Auto Defog, or Status LED, you can select to enable or disable the corresponding service according to the actual demands. ABF: When ABF function is enabled, you can click on PTZ control panel to realize auxiliary focus.

  • Page 56: Ip Address Filter

    Network Camera User Manual Digest is the recommended authentication method for better data security. You must be aware of the risk if you adopt basic as the authentication method. 3. Click Save to save the settings. IP Address Filter Purpose: This function makes it possible for access control.

  • Page 57: Security Service

    Network Camera User Manual Add an IP (3) Click the OK to finish adding. Modify an IP Address  Steps: (1) Left-click an IP address from filter list and click Modify. (2) Modify the IP address in the text filed. Modify an IP (3) Click the OK to finish modifying.

  • Page 58: User Management

    Network Camera User Manual Security Service 2. Check the checkbox of Enable Illegal Login Lock. Illegal Login Lock: it is used to limit the user login attempts. Login attempt from the IP address is rejected if admin user performs 7 failed user name/password attempts (5 times for the operator/user).
  • Page 59 Network Camera User Manual accounts. The admin user cannot be deleted and you can only change the admin password. Steps: 1. Click Add to add a user. 2. Input the Admin Password, User Name, select Level and input Password. Notes: ●...

  • Page 60: Security Question

    Network Camera User Manual 4. Click OK to finish the user modification. Deleting a User  Steps: 1. Click to select the user you want to delete and click Delete. 2. Click OK on the pop-up dialogue box to confirm the deletion. As Operator or User ...

  • Page 61: Online Users

    Network Camera User Manual 2. Click Forget Password. 3. Answer security question. 4. Create new password. Note: User IP address is locked for 30 minutes after 7 failed attempts of answering security questions. Online Users Purpose: You can see the current users who are visiting the device through this interface. User information, such as user name, level, IP address, and operation time, is displayed in the User List.

  • Page 62: Chapter 7 Network Settings

    Network Camera User Manual Chapter 7 Network Settings Purpose: Follow the instructions in this chapter to configure the basic settings and advanced settings. Configuring Basic Settings Purpose: You can configure the parameters, including TCP/IP, DDNS, PPPoE, Port, and NAT, etc., by following the instructions in this section. Configuring TCP/IP Settings Purpose: TCP/IP settings must be properly configured before you operate the camera over...
  • Page 63 Network Camera User Manual TCP/IP Settings 2. Configure the basic network settings, including the NIC Type, IPv4 or IPv6 Address, IPv4 or IPv6 Subnet Mask, IPv4 or IPv6 Default Gateway, MTU settings and Multicast Address. 3. (Optional) Check the checkbox of Enable Multicast Discovery, and then the online network camera can be automatically detected by client software via private multicast protocol in the LAN.

  • Page 64: Configuring Ddns Settings

    Network Camera User Manual multicast group address. Before utilizing this function, you have to enable the Multicast function of your router.  A reboot is required for the settings to take effect. Configuring DDNS Settings Purpose: If your camera is set to use PPPoE as its default network connection, you can use the Dynamic DNS (DDNS) for network access.
  • Page 65 Network Camera User Manual Figure 7-2 DynDNS Settings  NO-IP: Steps: (1) Choose the DDNS Type as NO-IP. Figure 7-3 NO-IP DNS Settings (2) Enter the Server Address as www.noip.com (3) Enter the Domain name you registered. (4) Enter the User Name and Password. (5) Click Save and then you can view the camera with the domain name.

  • Page 66: Configuring Pppoe Settings

    Network Camera User Manual Configuring PPPoE Settings Steps: Enter the PPPoE Settings interface: Configuration > Network > Basic Settings > PPPoE PPPoE Settings 2. Check the Enable PPPoE checkbox to enable this feature. 3. Enter User Name, Password, and Confirm password for PPPoE access. Note: The User Name and Password should be assigned by your ISP.
  • Page 67 Network Camera User Manual You can set the port No. of the camera, e.g., HTTP port, RTSP port and HTTPS port. Steps: 1. Enter the Port Settings interface, Configuration > Network > Basic Settings > Port Port Settings 2. Set the ports of the camera. HTTP Port: The default port number is 80, and it can be changed to any port No.

  • Page 68: Configure Nat (Network Address Translation) Settings

    Network Camera User Manual Note: WebSocket and WebSockets protocol are used for plug-in free live view. For detailed information, see 7.2.11. 3. Click Save to save the settings. Note: A reboot is required for the settings to take effect. Configure NAT (Network Address Translation) Settings Purpose: NAT interface allows you to configure the UPnP™...

  • Page 69: Configure Advanced Settings

    Network Camera User Manual 3. Choose a friendly name for the camera, or you can use the default name. 4. Select the port mapping mode. Manual and Auto are selectable. Note: If you select Auto, you should enable UPnP™ function on the router. If you select Manual, you can customize the value of the external port and complete port mapping settings on router manually.
  • Page 70 Network Camera User Manual strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.
  • Page 71 Network Camera User Manual SNMP Settings 2. Check the checkbox of Enable SNMPv1, Enable SNMP v2c, Enable SNMPv3 to enable the feature correspondingly. 3. Configure the SNMP settings. Note: The settings of the SNMP software should be the same as the settings you...

  • Page 72: 7.2.2 Configuring Ftp Settings

    Network Camera User Manual configure here. 4. Click Save to save and finish the settings. Notes: A reboot is required for the settings to take effect. • To lower the risk of information leakage, you are suggested to enable SNMP v3 •...
  • Page 73 Network Camera User Manual FTP server login. For your privacy and to better protect your system against security risks, we  strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.

  • Page 74: 7.2.3 Configuring Email Settings

    Network Camera User Manual anonymous access to the FTP server. Note: The anonymous access function must be supported by the FTP server. 6. Click Save to save the settings. 7.2.3 Configuring Email Settings Purpose: The system can be configured to send an Email notification to all designated receivers if an alarm event is detected, e.g., motion detection event, video loss, video tampering, etc.
  • Page 75 Network Camera User Manual The SMTP port should be set as 465 for this encryption method. When you select SSL or TLS and enable STARTTLS, emails will be sent after encrypted by STARTTLS, and the SMTP port should be set as 25. Note: If you want to use STARTTLS, make sure that the protocol is supported by your e-mail server.

  • Page 76: Platform Access

    Network Camera User Manual Email Settings 4. Click Save to save the settings. Platform Access Purpose: Platform access provides you an option to manage the devices via platform. Steps: 1. Enter the Platform Access settings interface: Configuration > Network > Advanced Settings >...

  • Page 77: Wireless Dial

    Network Camera User Manual If you select Platform Access Mode as Hik-Connect, 1) Click and read "Terms of Service" and "Privacy Policy" in pop-up window. 2) Create a verification code or change the verification code for the camera. Note: The verification code is required when you add the camera to Hik-Connect •...
  • Page 78 Network Camera User Manual 2. Check the checkbox to enable the wireless dial settings. 3. Configure the dial parameters. 1) Select the dial mode from the drop-down list. Auto and Manual are selectable. If Auto is selected, you can set the arming schedule for dialing; If Manual is selected, you can set the offline time and manual dialing parameters.

  • Page 79: Https Settings

    Network Camera User Manual 4) (Optional) You can click Send Test SMS to send a message to the mobile phone for test. 5) Click Save to save the settings. HTTPS Settings Purpose: HTTPS provides authentication of the web site and its associated web server, which protects against Man-in-the-middle attacks.
  • Page 80 Network Camera User Manual HTTPS Configuration Interface 3. Create the self-signed certificate or authorized certificate. Create the self-signed certificate  (1) Select Create Self-signed Certificate as the Installation Method. (2) Click Create button to enter the creation interface. Create Self-signed Certificate (3) Enter the country, host name/IP, validity and other information.

  • Page 81: Configuring Qos Settings

    Network Camera User Manual (3) Download the certificate request and submit it to the trusted certificate authority for signature. (4) After receiving the signed valid certificate, import the certificate to the device. 4. There will be the certificate information after your successfully creating and installing the certificate.

  • Page 82: Configuring 802.1X Settings

    Network Camera User Manual 2. Configure the QoS settings, including Video/Audio DSCP, Event/Alarm DSCP and Management DSCP. The valid value range of the DSCP is 0 to 63. The bigger the DSCP value is, the higher the priority is. Note: DSCP refers to the Differentiated Service Code Point;...

  • Page 83: Integration Protocol

    Network Camera User Manual 802.1X Settings 2. Check the Enable IEEE 802.1X checkbox to enable the feature. 3. Configure the 802.1X settings, including Protocol, EAPOL version, User Name, Password and Confirm. Note: The EAPOL version must be identical with that of the router or the switch. 4.

  • Page 84: Bandwidth Adaptation

    Network Camera User Manual 1. Check the Enable ONVIF checkbox to enable the function. 2. Add ONVIF users. Up to 32 users are allowed. Set the user name and password, and confirm the password. You can set the user as media user, operator, and administrator. Note: ONVIF user account is different from the camera user account.

  • Page 85: Chapter 8 Video/Audio Settings

    Network Camera User Manual Chapter 8 Video/Audio Settings Purpose: Follow the instructions below to configure the video setting, audio settings, ROI, Display info. on Stream, etc. Configuring Video Settings For certain camera models, you can configure parameters for available video streams, for example, the main stream, the sub-stream, etc.
  • Page 86 Network Camera User Manual Video Settings 2. Select the Stream Type. Supported stream types are listed in the drop-down list. Notes: For some models, the Third Stream is not enabled by default. Go to System > • Maintenance > System Service> Software to enable the function is required. The main stream is usually for recording and live view with good bandwidth, •...
  • Page 87 Network Camera User Manual When bitrate type is selected as Variable, 6 levels of video quality are selectable. Frame Rate: Set the frame rate. The frame rate is to describe the frequency at which the video stream is updated and it is measured by frames per second (fps). A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout.
  • Page 88 Network Camera User Manual H.265+ reduces storage by up to 50% with the same maximum bitrate in most scenes. You need to reboot the camera if you want to turn on or turn off the H.264+/H.265+. If you switch from H.264+ to H.265+ directly, and vice versa, a reboot is not required by the system.

  • Page 89: Custom Video

    Network Camera User Manual bandwidth is insufficient. Smoothing: It refers to the smoothness of the stream. The higher value of the smoothing is, the better fluency of the stream will be, though, the video quality may not be so satisfactory. The lower value of the smoothing is, the higher quality of the stream will be, though it may appear not fluent.

  • Page 90: Configuring Audio Settings

    Network Camera User Manual Custom Video Settings Steps: 1. Click to add a stream 2. Change the stream name if needed. Note: Up to 32 letters and symbols (except &, <, >, ', or ") are allowed for the stream name. 3.

  • Page 91: Configuring Roi Encoding

    Network Camera User Manual Audio Settings 2. Configure the following settings. Note: Audio settings vary according to different camera models. Audio Encoding: G.722.1, G.711 ulaw, G.711alaw, G.726, MP2L2 and PCM are selectable. For MP2L2, the Sampling Rate and Audio Stream Bitrate are configurable.
  • Page 92 Network Camera User Manual Region of Interest Settings Steps: 1. Enter the ROI settings interface: Configuration > Video/Audio > ROI. 2. Select the Stream Type for ROI encoding. 3. Check the checkbox of Enable under Fixed Region item. 4. Set Fixed Region for ROI. (1) Select the Region No.

  • Page 93: Display Info. On Stream

    Network Camera User Manual (3) Click Drawing. Click and drag the mouse on the view screen to draw a red rectangle as the ROI region. You can click Clear to cancel former drawing. Click Stop Drawing when you finish. (4) Select the ROI level. (5) Enter a region name for the chosen region.

  • Page 94: Configuring Target Cropping

    Network Camera User Manual Configuring Target Cropping Purpose: You can specify a target area on the live video, and then the specified video area can be displayed via the third stream in certain resolution, providing more details of the target area if needed. Note: Target cropping function varies according to different camera models.

  • Page 95: Chapter 9 Image Settings

    Network Camera User Manual Chapter 9 Image Settings Purpose: Follow the instructions in this chapter to configure the image parameters, including display settings, OSD settings, privacy mask, and picture overlay. Configuring Display Settings Purpose: Configure the image adjustment, exposure settings, day/night switch, backlight settings, white balance, image enhancement, video adjustment, and other parameters in display settings.
  • Page 96 Network Camera User Manual 2. Set the image parameters of the camera. Note: In order to guarantee the image quality in different illumination, it provides two sets of parameters for users to configure.  Image Adjustment Brightness describes bright of the image, which ranges from 1 to 100. Contrast describes the contrast of the image, which ranges from 1 to 100.
  • Page 97 Network Camera User Manual and auxiliary focus manually. Semi-Auto: Camera will focus automatically when you adjust the zoom parameters.  Day/Night Switch Select the Day/Night Switch mode according to different surveillance demand. Day, Night, Auto, Scheduled-Switch, and Triggered by alarm input are selectable for day/night switch.
  • Page 98 Network Camera User Manual if the object is near the camera, the device adjusts the supplement light to lower power, and the light is in higher power if the object is far away. Backlight Settings  BLC Area: If you focus on an object against strong backlight, the object will be too dark to be seen clearly.

  • Page 99: Day/Night Scheduled-Switch

    Network Camera User Manual and the image is misty. It enhances the subtle details so that the image appears clearer. EIS (Electrical Image Stabilizer): EIS reduces the effects of vibration in a video. Grey Scale: You can choose the range of the grey scale as [0-255] or [16-235]. Video Adjustment ...

  • Page 100: Configuring Osd Settings

    Network Camera User Manual illumination. Day/Night Scheduled-Switch Configuration Interface Steps: 1. Click the calendar icon to select the start time and the end time of the switch. Notes: The start time and end time refer to the valid time for day mode. •...
  • Page 101 Network Camera User Manual OSD Settings Steps: 1. Enter the OSD Settings interface: Configuration > Image > OSD Settings. 2. Check the corresponding checkbox to select the display of camera name, date or week if required. 3. Edit the camera name in the text field of Camera Name. 4.

  • Page 102: Configuring Privacy Mask

    Network Camera User Manual 8. Click Save to save the settings. Configuring Privacy Mask Purpose: Privacy mask enables you to cover certain areas on the live video to prevent certain spots in the surveillance area from being live viewed and recorded. Steps: 1.

  • Page 103: Configuring Picture Overlay

    Network Camera User Manual you set without saving them. 6. Click Save to save the settings. Configuring Picture Overlay Purpose: Picture overlay enables you to overlay a picture on the image. This function enables a certain enterprise or users to overlay their logo on the image. Steps: 1.
  • Page 104 Network Camera User Manual 128*128.

  • Page 105: Chapter 10 Event Settings

    Network Camera User Manual Chapter 10 Event Settings This section explains how to configure the network camera to respond to alarm events, including basic event and smart event. Basic Events You can configure the basic events by following the instructions in this section, including motion detection, video tampering, alarm input, alarm output, and exception, etc.
  • Page 106 Network Camera User Manual 3. Check the checkbox of Enable Dynamic Analysis for Motion if you want to mark the detected objects with green rectangles. Note: Select Disable for rules if you don’t want the detected objected displayed with the green rectangles. Select disable rules from Configuration > Local Configuration >...
  • Page 107 Network Camera User Manual Task 2: Set the Arming Schedule for Motion Detection Arming Schedule Steps: 1. Click Arming Schedule to edit the arming schedule. 2. Click on the time bar and drag the mouse to select the time period. Arming Schedule Note: Click on the selected time period, you can adjust the time period to the...
  • Page 108 Network Camera User Manual save the settings. 4. Move the mouse to the end of each day, a copy dialogue box pops up, and you can copy the current settings to other days. 5. Click Save to save the settings. Note: The time of each period can’t be overlapped.
  • Page 109 Network Camera User Manual complete Email setup in advance.  Upload to FTP/Memory Card/NAS Capture the image when an alarm is triggered and upload the picture to a FTP server. Notes: Set the FTP address and the remote FTP server first. Refer to Section 7.2.2 ●...
  • Page 110 Network Camera User Manual Expert Mode of Motion Detection  Day/Night Switch OFF Steps: 1. Draw the detection area as in the normal configuration mode. Up to 8 areas are supported. 2. Select OFF for Switch Day and Night Settings. 3.

  • Page 111: 10.1.2 Configuring Video Tampering Alarm

    Network Camera User Manual 6. Set the arming schedule and linkage method as in the normal configuration mode. 7. Click Save to save the settings.  Day/Night Scheduled-Switch Steps: 1. Draw the detection area as in the normal configuration mode. Up to 8 areas are supported.

  • Page 112: 10.1.3 Configuring Alarm Input

    Network Camera User Manual 2. Check Enable Video Tampering checkbox to enable the video tampering detection. 3. Click Edit to edit the arming schedule for video tampering. The arming schedule configuration is the same as the setting of the arming schedule for motion detection.
  • Page 113 Network Camera User Manual Alarm Input Settings 3. Click Arming Schedule to set the arming schedule for the alarm input. Refer to Task 2: Set the Arming Schedule for Motion Detection in Section 10.1.1. 4. Click Linkage Method and check the checkbox to select the linkage method taken for the alarm input.

  • Page 114: 10.1.4 Configuring Alarm Output

    Network Camera User Manual 10.1.4 Configuring Alarm Output Alarm Output Settings Steps: 1. Enter the Alarm Output Settings interface: Configuration> Event > Basic Event > Alarm Output. 2. Select one alarm output channel in the Alarm Output drop-down list. You can also set a name for the alarm output (optional).

  • Page 115: 10.1.5 Handling Exception

    Network Camera User Manual 6. Click Save to save the settings. 10.1.5 Handling Exception The exception type can be HDD full, HDD error, network disconnected, IP address conflicted and illegal login to the cameras. Steps: 1. Enter the Exception Settings interface: Configuration > Event > Basic Event > Exception.
  • Page 116 Network Camera User Manual Configuration > Advanced Configuration> Basic Event> Wireless Alarm Setting Wireless Alarm 2. Select the wireless alarm number. Up to 8 channels of external wireless alarm input are supported. 3. Check the checkbox of Enable Wireless Alarm to activate the wireless alarm. 4.
  • Page 117 Network Camera User Manual A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector's field of view. The heat energy dissipated by a person, or any other warm blooded creature such as dogs, cats, etc., can be detected. Steps: 1.

  • Page 118: Smart Events

    Network Camera User Manual Figure 10-13 Arming PIR Alarm  Emergency Alarm Purpose: You can press the Emergency button on the remote control to trigger the Emergency Alarm in case of an emergency. Note: The remote control is required for the Emergency Alarm. Go to Configuration > System>...

  • Page 119: Configuring Audio Exception Detection

    Network Camera User Manual intrusion detection, and line crossing detection, etc. These events can trigger the linkage methods, such as Notify Surveillance Center, Send Email, Trigger Alarm Output, etc. Configuring Audio Exception Detection Purpose: Audio exception detection function detects the abnormal sounds in the surveillance scene, such as the sudden increase/decrease of the sound intensity, and some certain actions can be taken when the alarm is triggered.

  • Page 120: Configuring Defocus Detection

    Network Camera User Manual the sound steep rise in the surveillance scene. You can set the detection sensitivity and threshold for sound steep rise. 4. Check the checkbox of Sudden Decrease of Sound Intensity Detection to detect the sound steep drop in the surveillance scene. You can set the detection sensitivity and threshold for sound steep drop.

  • Page 121: Configuring Scene Change Detection

    Network Camera User Manual Configuring Defocus Detection 2. Check the checkbox of Enable to enable the function. 3. Click-and-drag the slider to set the detection sensitivity. The sensitivity value ranges from 1 to 100, and the higher the value is, the more easily the defocus image can trigger the alarm.

  • Page 122: Configuring Face Detection

    Network Camera User Manual Scene Change Detection 2. Check the checkbox of Enable to enable the function. 3. Click-and-drag the slider to set the detection sensitivity. The sensitivity value ranges from 1 to 100, and the higher the value is, the more easily the change of scene can trigger the alarm.
  • Page 123 Network Camera User Manual Enter the Face Detection settings interface, Configuration > Event > Smart Event > Face Detection. Check the Enable Face Detection checkbox to enable the function. Check the checkbox of Enable Dynamic Analysis for Face Detection, and then the detected face is marked with green rectangle on the live video.

  • Page 124: Configuring Intrusion Detection

    Network Camera User Manual Click Save to save the settings. Configuring Intrusion Detection Purpose: Intrusion detection function detects people, vehicle or other objects which enter and loiter in a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered.
  • Page 125 Network Camera User Manual 2. Check the checkbox of Enable to enable the function. 3. Select a region number from the drop-down list of Region. Region: A pre-defined vertexes area on the live view image. Targets, such as, people, vehicle or other objects, who enter and loiter in the region will be detected and trigger the set alarm.

  • Page 126: Configuring Line Crossing Detection

    Network Camera User Manual 10. Repeat the above steps to configure other regions. Up to 4 regions can be set. You can click the Clear button to clear all pre-defined regions. 11. Click Arming Schedule to set the arming schedule. 12.
  • Page 127 Network Camera User Manual Line Crossing Detection 2. Check the checkbox of Enable to enable the function. 3. Select the line from the drop-down list. 4. Click Area Settings tab and click Draw Area button, and a virtual line is displayed on the live video.
  • Page 128 Network Camera User Manual Max. Size: The maximum size of a valid target. Targets with larger sizes would not trigger detection. Min. Size: The minimum size of a valid target. Targets with smaller sizes would not trigger detection. 7. Select the direction for line crossing detection. And you can select the directions as A<->B, A ->B, and B->A.

  • Page 129: Configuring Region Entrance Detection

    Network Camera User Manual Configuring Region Entrance Detection Purpose: Region entrance detection function detects people, vehicle or other objects which enter a pre-defined virtual region from the outside place, and some certain actions can be taken when the alarm is triggered. Steps: 1.

  • Page 130: Configuring Region Exiting Detection

    Network Camera User Manual 4. Click Area Settings and click Draw Area button to start the area drawing. 5. Click on the live video to specify the four vertexes of the detection region, and right click to complete drawing. 6. Set the Max. Size and Min. Size for valid targets. Targets smaller or larger than the valid target size are not able to trigger detection.
  • Page 131 Network Camera User Manual from a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. Steps: 1. Enter the Region Exiting Detection settings interface, Configuration > Event > Smart Event > Region Exiting Detection. Region Exiting Detection 2.

  • Page 132: Configuring Unattended Baggage Detection

    Network Camera User Manual not trigger detection. Min. Size: The minimum size of a valid target. Targets with smaller sizes would not trigger detection. 7. Click Stop Drawing when finish drawing. 8. Drag the slider to set the sensitivity value. Sensitivity: Range [1-100].
  • Page 133 Network Camera User Manual Unattended Baggage Detection 2. Check Enable checkbox to enable the function. 3. Select the Region from the drop-down list for detection settings. 4. Click Area Settings and click Draw Area to start the area drawing. 5. Click on the live video to specify the four vertexes of the detection region, and right click to complete drawing.

  • Page 134: Configuring Object Removal Detection

    Network Camera User Manual Threshold: Range [5-100s], the threshold for the time of the objects left over in the region. If you set the value as 10, alarm is triggered after the object is left and stay in the region for 10s. 9.
  • Page 135 Network Camera User Manual Object Removal Detection 2. Check Enable checkbox to enable the function. 3. Select the Region from the drop-down list for detection settings. 4. Click Area Settings and click Draw Area button to start the area drawing. 5.

  • Page 136: Vca Configuration

    Network Camera User Manual disappears from the region for 10s. 9. Drag the slider to set the sensitivity value. Sensitivity: Range [1-100]. It stands for the percentage of the body part of an acceptable target that leaves the pre-defined region. Sensitivity = 100 –...
  • Page 137 Network Camera User Manual Behavior Analysis  Overlay & Capture Display information includes the display on picture and display on stream. Display VCA info. on Stream: The green frames will be displayed on the target if in a live view or playback. Display Target info.
  • Page 138 Network Camera User Manual be more accurate if the camera calibration is configured. Steps: 1. Check the checkbox of Camera Calibration to enable this function. 2. Select the calibration mode as Input Basic Data or Draw on Live View Video. Input Basic Data: Input the mounting height, viewing angle, and horizon ratio of the camera manually.
  • Page 139 Network Camera User Manual 4. You can click to delete the drawn lines. 5. Click Save to save the settings.  Shield Region The shield region allows you to set the specific region in which the behavior analysis will not function. Up to 4 shield regions are supported. Steps: 1.
  • Page 140 Network Camera User Manual Configure the Rule Filter type: Pixels and Actual Size are selectable. If Pixels is selected, draw the area of maximum size and minimum size on the live video for each rule. If Actual Size is selected, input the length and width of the maximum size and minimum size.
  • Page 141 Network Camera User Manual to left click on the live video to set the end points of the area and right click to finish the area drawing. Note: If the live view is stopped, the detection area / line cannot be draw and the rules cannot be set.
  • Page 142 Network Camera User Manual Advanced Configuration Detection Sensitivity [0~4]: Refers to the sensitivity of the camera detects a target. The higher the value, the easier a target be recognized, and the higher the misinformation is. The default value of 3 is recommended. Background Update Rate [0~4]: It refers to the speed of the new scene replaces the previous scene.

  • Page 143: Face Capture

    Network Camera User Manual 1. Check the checkbox of Global Size Filter to enable the function. 2. Select the Filter Type as Actual Size or Pixel. Actual Size: Input the length and width of both the maximum size and the minimum size.
  • Page 144 Network Camera User Manual if in a live view or playback. Display Target info. on Alarm Picture: There will be a frame on the target on the uploaded alarm picture if the checkbox is checked. Snapshot Setting: Select the picture quality for the captured picture. Good, better, and best are selectable.
  • Page 145 Network Camera User Manual 1. Check the checkbox of Rule to enable rules of face capture. 2. Click the rectangle sign to draw the minimum pupil distance. The distance of the drawn pupil will be displayed on the box below the live view. The minimize pupil distance refers to the minimum square size composed by the area between two pupils, and it is the basic standard for a camera to identify a target.
  • Page 146 Network Camera User Manual faster the target will be recognized. Setting the value quite low, and if there was a face in the configured area from the start, this face will not be captured. It can reduce the misinformation of the faces in the wall painting or posters. The default value of 3 is recommended.

  • Page 147: People Counting

    Network Camera User Manual People Counting Purpose: People function is used to calculate the number of object entered or exited a certain configured area and it is widely applied to the entrances or exits. Notes: It is recommended to install the camera right above the entrance/exit. To improve the counting accuracy, make sure your camera is installed horizontally.
  • Page 148 Network Camera User Manual 3. Set the detection line. An orange line, named as detection line can be set on the live video, and the object entering or exiting through the line will be detected and counted. 1) Click button on the left of the live view image. An orange line will appear on the image.
  • Page 149 Network Camera User Manual 3) Dragging the cursor or input a value to set the calibration with. You can set the value as suggested, or you can set according to your actual need. Figure 10-32 People Counting Configuration-Advanced 5. Counting data setting and display. 1) Check Enable OSD Overlay checkbox, and the real-time number of people entered and exited is displayed on the live video.

  • Page 150: Counting

    Network Camera User Manual Counting Counting function helps to calculate the number of people entered or exited a certain configured area and is widely applied to the entrances or exits. Compared with the people counting function supported by iDS camera, counting function needs no camera calibration.

  • Page 151: Heat Map

    Network Camera User Manual people entered and exited is displayed on the live video. 4. Set the detection line. An orange line, named as detection line can be set on the live video, and the object entering or exiting through the line will be detected and counted. 1) Click to draw a detection line, and an orange detection line will appear on the image.
  • Page 152 Network Camera User Manual Heat Map Configuration 2. Check Enable Heat Map checkbox to enable the function. 3. Go to Area Settings to draw detection area. Draw area by left click the end-points in the live view window, and right click to finish the area drawing. Up to 8 areas are configurable.

  • Page 153: Road Traffic

    Network Camera User Manual camera treats the cabinet (on which the good removed) as a new scene. The default value of 50 is recommended. Scene Change Level [0~100]: It refers to level of the camera responses to the dynamic environment, e.g., a swaying curtain. The camera may treat the swaying curtain as a target.
  • Page 154 Network Camera User Manual Note: Road traffic function varies according to different camera models.  Detection Configuration Steps: 1. Select the detection type from the list. Vehicle Detection and Mixed-traffic Detection are selectable. Note: Reboot the device to activate the new settings when switching the detection type of road traffic.

  • Page 155: Chapter 11 Storage Settings

    Network Camera User Manual Upload to FTP/Memory Card/NAS: Capture the image when an alarm is • triggered and upload the picture to a FTP server. And save the picture on the local SD card or connected NAS. 9. Click the Save button to activate the settings. Chapter 11 Storage Settings Before you start: To configure record settings, please make sure that you have the network storage...
  • Page 156 Network Camera User Manual Recording Schedule Interface 2. Check the checkbox of Enable to enable scheduled recording. 3. Click Advanced to set the camera record parameters. Record Parameters Pre-record: The time you set to start recording before the scheduled time or ...
  • Page 157 Network Camera User Manual The Post-record time can be configured as 5s, 10s, 30s, 1 min, 2 min, 5 min or 10 min. Stream Type: Select the stream type for recording.  Note: The record parameter configurations vary depending on the camera model. 4.

  • Page 158: Configure Capture Schedule

    Network Camera User Manual Record Triggered by Motion | Alarm  If you select Motion | Alarm, the video will be recorded when the external alarm is triggered or the motion is detected. Besides configuring the recording schedule, you have to configure the settings on the Motion Detection and Alarm Input Settings interfaces.
  • Page 159 Network Camera User Manual Capture Configuration 2. Go to Capture Schedule tab to configure the capture schedule by click-and-drag the mouse on the time bar. You can copy the record schedule to other days by clicking the green copy icon on the right of each time bar. 3.

  • Page 160: Configuring Net Hdd

    Network Camera User Manual number. Set Capture Parameters 6. Set the time interval between two snapshots. 7. Click Save to save the settings. Configuring Net HDD Before you start: The network disk should be available within the network and properly configured to store the recorded files, log files, pictures, etc.
  • Page 161 Network Camera User Manual Add Network Disk (2) Enter the IP address of the network disk, and enter the file path. (3) Select the mounting type. NFS and SMB/CIFS are selectable. And you can set the user name and password to guarantee the security if SMB/CIFS is selected.
  • Page 162 Network Camera User Manual Storage Management Interface (2) If the status of the disk is Uninitialized, check the corresponding checkbox to select the disk and click Format to start initializing the disk. When the initialization completed, the status of disk will become Normal. View Disk Status 3.

  • Page 163: Memory Card Detection

    Network Camera User Manual Note: Up to 8 NAS disks can be connected to the camera. Memory Card Detection Purpose: With memory card detection, you can view the memory card status, lock your memory card, and receive notification when your memory card is detected abnormal. Note: Memory card detection function is only supported by certain types of memory cards and camera models.
  • Page 164 Network Camera User Manual Method are set. Note: It is recommended that you change the memory card when the health status is not “good”. 3. Click R/W Lock tab to add a lock to the memory card. With the R/W lock added, the memory card can only be read and write when it is unlocked.

  • Page 165: Configuring Lite Storage

    Network Camera User Manual Remove the Lock  (1) Select the Lock Switch as OFF. (2) Input the correct password in Password Settings text field. (3) Click Save to save the settings. 4. Set the Arming Schedule and Linkage Method, if you want to receive a notification when the health status of the memory card is anything other than good.

  • Page 166: Chapter 12 Playback

    Network Camera User Manual Chapter 12 Playback Purpose: This section explains how to view the remotely recorded video files stored in the network disks or SD cards. Steps: 1. Click Playback on the menu bar to enter playback interface. Playback Interface 2.
  • Page 167 Network Camera User Manual The toolbar on the bottom of Playback interface can be used to control playing process. Playback Toolbar Table 12-1 Description of the buttons Button Operation Button Operation Play Capture a picture Start/Stop clipping video Pause files Audio on and adjust Stop volume/Mute...

  • Page 168: Chapter 13 Picture

    Network Camera User Manual Chapter 13 Picture Click Picture to enter the picture searching interface. You can search, view, and download the pictures stored in the local storage or network storage. Notes: Make sure HDD, NAS or memory card are properly configured before you ...

  • Page 169: Chapter 14 Application

    Network Camera User Manual Chapter 14 Application Click Application to enter the statistics counting interface. You can search, view, and download the counting data stored in the local storage or network storage. Note: Application function varies according to the different camera models. Face Capture Statistics After you enable the face capture function, you can view and download the captured face data from application tab.

  • Page 170: Heat Map Statistics

    Network Camera User Manual counting data from application tab. To get more intuitional results, you can display the data in different charts. Steps: 1. Select the report type. Daily report, weekly report, monthly report, and annual report are selectable. Note: Daily report calculates the data on the date you selected;...

  • Page 171: Counting Statistics

    Network Camera User Manual Note: Daily report calculates the data on the date you selected; weekly report calculates for the week your selected date belongs to; monthly report calculates for the month your selected date belongs to; and the annual report calculates for the year your selected date belongs to.
  • Page 172 Network Camera User Manual different charts. Steps: 1. Select the report type. Daily report, weekly report, monthly report, and annual report are selectable. Note: Daily report calculates the data on the date you selected; weekly report calculates for the week your selected date belongs to; monthly report calculates for the month your selected date belongs to;...

  • Page 173: Appendix

    Network Camera User Manual Appendix Appendix 1 SADP Software Introduction  Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices.
  • Page 174 Network Camera User Manual You can also click to refresh the online device list manually. The newly searched devices will be added to the list. You can click on each column heading to order the information; you can click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel.
  • Page 175 Network Camera User Manual Figure A.1.2 Modify Network Parameters...

  • Page 176: Appendix 2 Port Mapping

    Network Camera User Manual Appendix 2 Port Mapping The following settings are for TP-LINK router (TL-WR641G). The settings vary depending on different models of routers. Steps: 1. Select the WAN Connection Type, as shown below: Figure A.2.1 Select the WAN Connection Type 2.
  • Page 177 Network Camera User Manual another camera as 81, 8001, 555, 8201 with IP 192.168.1.24. Refer to the steps as below: Steps: 1. As the settings mentioned above, map the port 80, 8000, 554 and 8200 for the network camera at 192.168.1.23 2.
  • Page 178 Network Camera User Manual...

This manual is also suitable for:

Hiwatch series

Table of Contents
