Sub-Zero UC-24C Install Manual page 4

U N D E R C O U N T E R
E L E C T R I C A L
A 115 V AC, 60 Hz, 15 amp circuit breaker and
electrical supply are required. A separate
circuit, servicing only this appliance, is
required.
The power supply cord has a 3-prong ground-
O P T I O N A L
ing plug, which must be plugged into a mating
C O M P O N E N T S
3-prong grounding-type wall receptacle. Follow
the National Electrical Code and local codes
Optional installa- and ordinances when installing the receptacle.
tion components
For location of the electrical supply, refer to the
are available
Installation Specifications illustration on page 3.
through your
IMPORTANT NOTE: The electrical outlet must
Sub-Zero dealer.
For questions
be placed so the grounding prong is to the right
relative to the
of the thinner blades. The outlet must be flush
installation, call
with the back wall.
Sub-Zero at
800-222-7820.
The Model UC-24RO is designed and safe for
use in outdoor applications. When installed
outdoors, a ground fault circuit interrupter
(GFCI) is required to reduce the risk of electrical
shock. A GFCI is not recommended for use with
other Undercounter models and may cause
interruption of operation.
4
I N S T A L L A T I O N I N S T R U C T I O N S
R E Q U I R E M E N T S
Do not use an extension cord or two-
prong adapter. Electrical ground is
required on this appliance.
P L U M B I N G R E Q U I R E M E N T S
Model UC-24C comes with an automatic ice
maker. The illustration on page 3 shows the
precise placement of the water line. When
routing through the side walls, you must place
1
the water line within / " (13) of the floor and
2
as close as possible to the back wall. A
minimum of 26" (660) of copper tubing is
required for the water line.
1
Connect the / " water line from the ice maker
4
water valve to the house water supply. Use an
easily accessible shut-off valve between the
water supply and the unit. This shut-off valve
should not be installed behind the unit. Do not
use self-piercing valves. A saddle valve kit
(part #4200880) is available from your
Sub-Zero dealer.
A line filter is required when water conditions
have a high sediment content. The ice maker
operates on water pressure of 20 psi (1.4 bar)
to 100 psi (6.9 bar).
A reverse osmosis system can be used,
provided there is a consistent water pressure
of 20 psi (1.4 bar) to 100 psi (6.9 bar) supplied
to the water valve at all times.
IMPORTANT NOTE: In some cases a reverse
osmosis water filter system may not be able
to maintain the minimum water pressure
consistently.
