U N D E R C O U N T E R I N S TA L L A T I O N I N S T R U C T I O N S
I N S TA L L AT I O N R E C O M M E N D AT I O N S
S I T E P R E P A R AT I O N
Make sure that the finished rough opening
where the Undercounter unit is to be installed
is properly prepared. Refer to the Installation
Specifications illustration for rough opening
dimensions, door swing clearance and location
of electrical and plumbing (Model UC-24C).
IMPORTANT NOTE: To operate properly, the
door must open a minimum of 90˚. Use a
minimum 2" (51) filler in corner installations to
assure a 90˚ door opening. Allow enough clear-
ance in front of the unit for full door swing.
IMPORTANT NOTE: Make sure the floor under
the unit is level with the surrounding finished
floor.
T O O L S A N D M AT E R I A L S R E Q U I R E D
The following is a list of tools and materials
that should be available for proper installation.
Appliance dolly able to support 130 lbs
(59 kg)
Level—2' (.6 m) and 4' (1.2 m)
recommended
Phillips and slotted screwdriver sets
Wrench set and allen wrench set
Crescent wrenches
Various sized pliers
5
/ " hex bolt nut driver
16
Drill and assorted drill bits
1
4' (1.2 m) of / " copper tubing and saddle
4
valve for the water line—part #4200880
(Model UC-24C)
Copper tubing cutter (Model UC-24C)
1
Masonite, plywood, /
cardboard or other suitable material to
protect finished flooring
Dimensions in parentheses are in
millimeters unless otherwise specified.
" pressed fiberboard,
8
I N S TA L L A T I O N S P E C I F I C AT I O N S
1
15 / "
2
L
2"
(51)
(394)
LOCATE WATER LINE
(MODEL UC24C ONLY)
WITHIN SHADED AREA
TOP VIEW
24"
(610)
ROUGH OPENING
WIDTH
ANTI-TIP BRACKET
LOCATE ELECTRICAL
AND WATER LINE
(MODEL UC24C ONLY)
WITHIN SHADED AREA
1
15 / "
2
(394)
2"
(51)
FRONT VIEW
NOTE: Water line is required for Model UC-24C only.
F
90˚
3
25 / "
8
(644)
26"
(660)
DOOR CLEARANCE
NOTE: Door swing clearances are based on stainless
steel door and handle dimensions.
2
1
/ "
2 ( 13 )
24"
(610)
ROUGH
OPENING
DEPTH
1
34 /
(876)
ROUGH
OPENING
HEIGHT
1
34 /
(870)
MINIMUM
HEIGHT
REQUIRED
3"
( 76 )
3
7
23
(606)
145˚
MAXIMUM
DOOR SWING 3
25
(645)
44"
(1118)
DOOR CLEARANCE
"
2
"
4
/ "
8
/ "
8
3
