Chapter 2: Jumpers and Connectors
Pin Definition
B1 12V
B2 12V
B3 12V
B4 GND
B5 SMBCLK
B6 SMBDAT
B7 GND
B8 3.3V
B9 NC
B10 3.3V AUX
B11 wake
B12 NC
B13 GND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B14 TXP
B15 TXN
B16 GND
B17 NC
B18 GND
B19 TXP
B20 TXN
B21 GND
B22 GND
B23 TXP
B24 TXN
B25 GND
B26 GND
Pin Definition
B27 TXP
B28 TXN
B29 GND
B30 NC
B31 NC
B32 GND
B33 TXP
B34 TXN
B35 GND
B36 GND
B37 TXP
B38 TXN
14
Pin Definition
B39 GND
B40 GND
B41 TXP
B42 TXN
B43 GND
B44 GND
B45 TXP
B46 TXN
B47 GND
B48 NC
B49 GND
