Chapter 2: Jumpers and Connectors
Jumper
CMOS Clear/AT_ATX
Connector type: 2x4 8-Pin (2.0 mm header)
Connector location: JP2
2
8
1
7
Pin
Definition
1
NC
3
CMOS
5
GND
7
NC
Default Setting
1-3 On
3-5 On
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
3.3V
4
AT_ATX_SEL
6
GND
8
NC
Status
RTC Normal
Clear CMOS
8
NSA 5190 User Manual
