Levelflex M FMP41C 4...20 mA HART
2.2.6 Turn housing
After mounting, the housing can be turned 350° in order to simplify access to the display and
the terminal compartment. Proceed as follows to turn the housing to the required position:
• Undo the fixing screws (1)
• Turn the housing (2) in the required direction
• Tighten up the fixing screws (1).
F12/F23 housing
2
1
2.3

Post-installation check

After the measuring instrument has been installed, perform the following checks:
• Is the measuring instrument damaged (visual check) ?
• Does the measuring instrument correspond to the measuring point specifications such as
process temperature/pressure, ambient temperature, measuring range, etc..?
• Are the measuring point number and labeling correct (visual check ?
• Is the measuring instrument adequately protected against rain and direct sunlight (see Chapter
"Accessories" in the Operating Instructions on the CD-ROM) ?
Endress+Hauser
T12 housing
2
1
allen key
4 mm/0.1"
Mounting
L00-FMP4xxxx-17-00-00-en-028
