What You Need - modway EEI-6795 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Top Board
2 Bottom Board
3 Center Board Left
4 Center Board Right
5 Adjustable Shelf
6 Door Sliding
7 Back Board
8 Pilar
LB18C1 Leg
LC16A1 Center Leg
Provided hardware:
A Cam Bolt Ø6 x 35 mm
B
Cam Lock Ø15 mm
C Wood Dowel Ø8 x 30 mm
D Screw M 7 x 50 mm
E Allen Key
F Shelf Pin
G
Screw M 4.5 x 12.5 mm
H Screw Cap Ø15 mm
I Wood Dowel Ø6 x 30 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
x1
x1
x1
x1
x2
6
x2
x4
LB18C1
x4
x2
x4 PM3
x4
PM2

What you need:

x8
x4
Phillips
x2
x4
x24
x4
x8
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
you're assembling the product.
Keep all components and packaging out of reach of children or animals
1
8
7
3
5
2
LC16A1
Mounting Plate
Mounting Plate
Phillips Head Screwdriver
8
7
4
LB18C1
x4
x2
6
PAGE 2 OF 8
