V-TAC 11583 Instruction Manual

SKU DESCRIPTION
11390 SILVER RAIL 1200MM FOR SOLAR PANEL 4PCS/SET
11389 MIDDLE CLAMP 35MM FOR SOLAR PANEL 8PCS/SET
11391 ROOFTOP HOOK FOR SOLAR PANEL 5PCS/SET
11392 TT NUT FOR SOLAR PANEL 20PCS/SET
11393 SCREW M6*50MM FOR SOLAR PANEL 30PCS/SET
11394 SPLICE FOR SILVER RAIL 8PCS/SET
11395 GROUNDING PLATE FOR SOLAR PANEL 8PCS/SET
11388 END CLAMP 35MM FOR SOLAR PANEL 4PCS/SET
INSTRUCTION MANUAL
L FEET GROUP
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
SKU 11583
INTRODUCTION
Thank you for selecting and buying V-TAC Product.
V-TAC will serve you the best. Please read these
instructions carefully & keep this user manual handy
for future reference. If you have any another query,
please contact our dealer or local vendor from
whom you have purchased the product. They are
trained and ready to serve you at the best.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
11385 ADJUSTABLE REAR LEG (H280-415mm/10°-15°) FOR SOLAR PANEL
11386 ADJUSTABLE REAR LEG (H420-700mm/15°-30°) FOR SOLAR PANEL
11387 TRIANGLE SUPPORT WITH ADJUSTABLE ANGLE 10°-15° FOR SOLAR PANEL
11417 ADJUSTABLE FRONT LEG FOR SOLAR PANEL
11538 SILVER RAIL 2000MM FOR SOLAR PANEL 4PCS/SET
