TrayDock eSATA™
• Drives are easily removable / replaceable via the front panel
• Footprint is very small relative to storage volume
Anodized silver aluminum case. It's beautiful and durable.
Table of Contents
Usage with Macs
Installation Instructions
1.
Check the accessories with your TrayDock. Please contact WiebeTech if any items are missing or
damaged. The box should contain:
T r a y D o c k e S A T A U s e r ' s M a n u a l
USER'S MANUAL
Revised September 28, 2006
Features
• Available with either 2 or 4 drive bays
• 2 or 4 eSATA ports (one per bay)
• Utilizes SATA drives
• Supports hot-swappable SATA ports
• Ideal for audio / video editing
• LED displays power status
• Power switch
TrayDock containing 2 or 4 trays
Power cable
eSATA cables
Packet of drive screws and keys
CD with Manual and Warranty information
1
3
3
4
1
1
2 or 4
1 or 2
1
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDKES2 and is the answer not in the manual?

Questions and answers

Summary of Contents for WiebeTech TDKES2

  • Page 1 Usage with Macs Usage with Windows Computers Technical Specifications Installation Instructions Check the accessories with your TrayDock. Please contact WiebeTech if any items are missing or damaged. The box should contain: TrayDock containing 2 or 4 trays Power cable eSATA cables...
  • Page 2 Install the appropriate drivers for the card. These are usually found on the CD or diskette that came with the card. The drivers for WiebeTech cards are found on the “Product Information & Manuals” CD. Browse to the folder PCIe Host Cards”...
  • Page 3: Usage With Macintosh Computers

    WiebeTech LLC Usage with Macintosh computers Mounting and Unmounting Volumes When you connect the unit to the Mac for the first time and turn on the power, you may see a message saying that the disks are unreadable. This is because you must format the drives before use.
  • Page 4: Technical Specifications

    WiebeTech offers free phone support for 90 days after purchase (1-866-744-8722). Email support is available at support@wiebetech.com. TrayDock eSATA is a trademark of WiebeTech LLC. Other marks are the property of their respective owners. © 2005 WiebeTech LLC. All rights reserved.
