- Page 1 Wobbly bridge MNPE638.002...
- Page 2 2,50 m 1,25 m 0,30 m 0,00 m Benaming TOE MNP 638 002 Wiebelbrug Title Tekening Opmerking Mini Play Drawing Comment BOER Datum Hoofdafmetingen Main dimensions 30-3-2016 Date SPEELTOESTELLEN...
- Page 3 3,90 m Opvangzone Impact area Obstakelvrije zone Obstacle free zone Benaming TOE MNP 638 002 Wiebelbrug Title Tekening Opmerking Mini Play Drawing Comment BOER Datum Obstakelvrije zone Obstacle free zone 30-3-2016 Date SPEELTOESTELLEN...
- Page 4 1,55 m 2,40 m 1,55 m (4x) Grondmarkering Ground level marker Benaming TOE MNP 638 002 Wiebelbrug Title Tekening Opmerking Mini Play Drawing Comment BOER Datum Bodemplan Groundplan 30-3-2016 Date SPEELTOESTELLEN...
- Page 5 Geleverde modules: Supplied modules: Zie tabel See table Montageinstructie: Assembly instruction: - De modules kunnen correct geassembleerd worden met de voorgeboorde gaten. - The modules can be assembled correctly using the predrilled holes. Montagevolgorde: Assembly sequence: 1 - Graaf de gaten volgens het bodemplan 1 - Dig the holes according to the ground plan 2 - Assembleer 1 met 3 2 - Assemble 1 with 3...
- Page 6 LOGBOOK Type indication Basic Play Article number MNPE638.002 Product Name Wobbly bridge Maximum fall height 0,3 m Construction year 2023 Certificate 2009287 Inspection body Keurmerkinstituut Groeneweg 2e, Zoetermeer 2718AA Zoetermeer Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk...
-
Page 7: Inspection And Maintenance
LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident... -
Page 8: Inspection And Maintenance Intervals
Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear. - Page 9 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
- Page 11 A ( 1 : 4 ) Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Schroef Assy 5 x 50 - RVS A2-70 D-sluiting 5 MM RVS Draadbus M10 x 40 - RVS A2-70 Zeskantmoer M12 - VZ 8.8 Slotbout M12 x 190 - VZ 8.8 Veerring M12 - VZ 8.8 Carrosseriering...
- Page 12 Type Progr. Volgnr Bew. Rev. Benaming Opmerking Frame Wiebelbrug B B B B e e e e n n n n a a a a m m m m i i i i n n n n g g g g MOD MNP 323 068 Frame Title...
- Page 13 Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Rebo 2500 Balk 145x68 met stalen kern Rebo 600 Paal 70x70 Benaming MOD MNP 638 002 Rebo pakket Title Opmerking Tekening Mini Play Drawing Comment BOER Datum Samenstelling module Assembly module 30-3-2016 Date SPEELTOESTELLEN...
- Page 14 Ø13 (2x) Ø13 (2x) A (8x) A (2x) A (1:2) All holes Ø22 unless otherwise stated. All holes pierce unless otherwise stated. All the holes in the heart of the post, unless otherwise stated. 45° Alle gaten Ø22 tenzij anders vermeld. Alle gaten doorboren tenzij anders vermeld.
