- Page 1 Monkey bar PSTE105.031...
-
Page 2: Main Dimensions
Hoofdafmetingen Hauptabmessungen Dimensiones principales Dimensions principales 2,23 m 2,08 m 1,81 m 1,67 m 1,11 m 0,75 m 0,00 m 0,00 m PST 105 031 © Copyright BOERplay 30-3-2022 Revision: A... - Page 3 Zona libre de obstáculos Zone libre d’obstacles 4,22 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacles PST 105 031 © Copyright BOERplay 30-3-2022 Revision: A...
- Page 4 Bodemplan Bodenplan Plan de superficie Plan de surface 1,62 m 2,41 m 2,24 m Grondmarkering Ground level marker PST 105 031 © Copyright BOERplay 30-3-2022 Revision: A...
-
Page 5: Order Of Assembly
Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage Typeplaatje Identification plate Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Driepoot Adventure play Enterrek Adventure Play PST 105 031 © Copyright BOERplay 30-3-2022 Revision: A... - Page 6 2 - The maximum height is less than 2.20 m 3 - Controleer de afmetingen van de valbodem t.o.v. het toestel. 3 - Check the dimensions of the safety area with regard to the play equipment. PST 105 031 © Copyright BOERplay 30-3-2022 Revision: A...
- Page 7 LOGBOOK Type indication Adventure Play Article number PSTE105.031 Product Name Monkey bar Maximum fall height 2,1 m Construction year 2023 Certificate 035176 Inspection body TUV Nederland QA BV Ekkersrijt 4401 5692 DL Son Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk...
- Page 8 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...
-
Page 9: Inspection And Maintenance Intervals
Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear. - Page 10 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
- Page 12 Paal 14-16 Lengte =2000 Paal 14-16 Lengte =2700 Lengte =1800 Paal 14-16 Paal 14-16 Lengte =3000 Standaard plank 120x20 Lengte = 1400 Standaard plank 120x20 Lengte = 1000 Voetsteun Steun MOD PST 007 072 © Copyright BOERplay 30-11-2023 Revision: A...
- Page 13 5 x 70 - RVS A2-70 Lengte =1800 Paal 14-16 Paal 14-16 Lengte =2100 Paal 14-16 Lengte =3000 Standaard plank 120x20 Lengte = 1200 Standaard plank 120x20 Lengte = 1800 MOD PST 007 071 © Copyright BOERplay 30-3-2022 Revision: A...
