BOERPLAY Waterworld San Blas Installation Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Waterworld San Blas
BBIE907.U

Advertisement

loading
Need help?

Need help?

Do you have a question about the Waterworld San Blas and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BOERPLAY Waterworld San Blas

Summary of Contents for BOERPLAY Waterworld San Blas

  • Page 1 Waterworld San Blas BBIE907.U...

  • Page 2: Installation Instructions

    Si el tierra no ayuda a la estabilidad del equipo que se está colocando, vierta 50L de hormigón por poste. FR - Important ! Si le sol ne contribue pas à la stabilité de l’équipement à placer, versez 50L de béton par poteau. BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 3 Hoofdafmetingen Hauptabmessungen Dimensiones principales Dimensions principales 0,90 m 0,87 m 0,03 m 0,00 m 0,78 m 0,10 m 0,00 m BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 4 Zone libre d’obstacles 3,86 m 1,50 m 1,50 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacles BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 5 Bodemplan Bodenplan Plan de superficie 1,53 m 0,80 m 1,53 m Plan de surface 1,70 m 0,44 m 1,70 m BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...

  • Page 6: Assembly Manual

    Roestvrij staal Kunststof Blauw aluminium Zwart aluminium Hout Edelstahl Kunststoff Blaues Aluminium Schwarzes Aluminium Holz Acero inoxidable Plastico Aluminio azul Aluminio negro Madera Acier inoxydable Plastique Aluminium bleu Aluminium noir Bois BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 7 Ø3 mm Ø5 mm Ø11 mm Ø12 mm 4,8mm Only for metal posts Alleen voor metalen staanders Nur für Pfosten aus Metall Solo para postes de metal Seulement pour poteaux en métal BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 8 1 / 5 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.918 assembly manual module MOD.BBI.042.x BOER PLAY maaiveld Mahfeld ground level sol naturel BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 9 2 / 5 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.912 assembly manual module MOD.BBI.917 assembly manual module MOD.BBI.047.x BOER PLAY maaiveld Mahfeld ground level sol naturel BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 10 3 / 5 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.915 assembly manual module MOD.BBI.045.x BOER PLAY maaiveld Mahfeld ground level sol naturel BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 11 4 / 5 assembly manual module MOD.BBI.916 5 / 5 BOER PLAY xxx.xxx.xxx EN 1176 www.boerplay.com BBI 907 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 12 LOGBOOK Type indication Figura Play Article number BBIE907.U Product Name Waterworld San Blas Maximum fall height 0,6 m Construction year 2023 Certificate 067613 Inspection body TUV Nederland QA BV Ekkersrijt 4401 5692 DL Son Manufacturer name Boer Speeltoestellen Hyacintstraat 2 - 4255 HX Nieuwendijk...
  • Page 13 LOGBOOK Inspection and maintenance Date of Time of Name Name Parts to be inspection inspection executor of executor of Found defects replaced maintenance maintenance inspection maintenance Accidents Date Age of Measures taken Probable cause of injury Occurred injury accident victim after accident...

  • Page 14: Inspection And Maintenance Intervals

    Inspection and maintenance intervals months Nr. Inspection Maintenance between inspections Verify equipment's stability, junctions and Add missing parts, secure joints, apply missing parts. Inspect bolts, screws and nuts for missing fixing agent and replace absence, jams, corrosion and wear. corroded parts. Replace worn parts and/or remove non- Check suspension for wear.
  • Page 15 7. Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the playground area. 8. Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing. Drawings can be found in the user guide. 9.
  • Page 17 Manuel de montage - module MOD.BBI.042.A MOD.BBI.042.B MOD.BBI.042.V BSR.014.005.052 BSR.014.005.052 BSR.014.005.052 KST.LAM.013.006 KST.LAM.013.006 KST.LAM.013.006 OME.KAP.100.524 OME.KAP.100.204 OME.KAP.100.204 OME.VRB.903.VZP OME.VRB.903.VZP OME.VRB.903.VZP S.BBI.032.R S.BBI.032.A S.BBI.032.B MOD.BBI.042.D MOD.BBI.042.U BSR.002.005.050 BSR.002.005.050 BSR.002.005.070 BSR.002.005.070 OME.KAP.100.204 OME.KAP.100.204 OME.VRB.903.VZP OME.VRB.903.VZP S.BBI.032.H S.BBI.032.K © Copyright BOERplay 23-11-2020 Revision: A MOD BBI 042...
  • Page 18 Aluminium noir Bois S.BBI.032.x 70 mm KST.LAM.013.006 BSR.002.005.070 OME.KAP.100 OME.KAP.100 Glue NL Lijm DE Kleber ES Pegamento 50 mm FR Colle ø5mm ø3mm x 30 BSR.002.005.050 BSR.014.005.052 18 mm OME.VRB.903.VZP OME.VRB.903.VZP MOD BBI 042 © Copyright BOERplay 23-11-2020 Revision: A...
  • Page 19 MOD.BBI.045.A MOD.BBI.045.B MOD.BBI.045.V BSR.014.005.052 BSR.014.005.052 BSR.014.005.052 KST.LAM.013.006 KST.LAM.013.006 KST.LAM.013.006 OME.KAP.100.524 OME.KAP.100.204 OME.KAP.100.204 OME.VRB.903.VZP OME.VRB.903.VZP OME.VRB.903.VZP S.BBI.040.R S.BBI.040.A S.BBI.040.B MOD.BBI.045.D MOD.BBI.045.U BSR.002.005.050 BSR.002.005.050 BSR.002.005.070 BSR.002.005.070 OME.KAP.100.204 OME.KAP.100.204 OME.VRB.903.VZP OME.VRB.903.VZP S.BBI.040.H S.BBI.040.K © Copyright BOERplay 12-4-2021 Revision: A MOD BBI 045 x...
  • Page 20 0,07 m mm KST.LAM.013.006 BSR.002.005.070 OME.KAP.100 OME.KAP.100 Glue NL Lijm DE Kleber ES Pegamento 0,05 m mm FR Colle ø5mm ø3mm x 30 BSR.002.005.050 BSR.014.005.052 0,02 m mm OME.VRB.903.VZP OME.VRB.903.VZP MOD BBI 045 x © Copyright BOERplay 12-4-2021 Revision: A...
  • Page 21 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 918 © Copyright BOERplay 9-6-2021 Revision:...
  • Page 22 1 / 4 SMD.BBI.701 Detail A (3x) KST.DOP.010.060 KST.DOP.010.060 BSR.010.010.010 BSR.010.010.010 BSR.030.010.002 BSR.030.010.002 KST.DON.010.060 KST.DON.010.060 OPE.BBI.356.022 OPE.BBI.357.072 BSR.002.005.035 BSR.030.010.002 BSR.030.010.002 BSR.002.005.035 BSR.010.010.010 BSR.023.010.060 BSR.030.010.002 BSR.023.010.060 KST.DON.010.060 BSR.023.010.060 KST.DOP.010.060 OPE.BBI.356.022 OPE.BBI.357.072 SMD.BBI.701 MOD BBI 918 © Copyright BOERplay 9-6-2021 Revision:...
  • Page 23 2 / 4 Detail B (1x) BSR.026.010.100 OPE.BBI.696.032 KST.SPT.005 KST.BUS.010.040 KST.DON.010.060 BSR.030.010.002 BSR.010.010.010 BSR.026.010.100 BSR.010.010.010 BSR.030.010.002 KST.BUS.010.040 KST.DON.010.060 KST.DOP.010.060 KST.DOP.010.060 KST.SPT.005 OPE.BBI.696.032 MOD BBI 918 © Copyright BOERplay 9-6-2021 Revision:...
  • Page 24 3 / 4 OPE.BBI.359.072 OPE.BBI.359.072 OPE.BBI.359.072 MOD BBI 918 © Copyright BOERplay 9-6-2021 Revision:...
  • Page 25 4 / 4 Detail C (8x) BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 BSR.030.010.002 BSR.021.010.140 KST.DOP.010.060 BSR.010.010.010 KST.DON.010.060 BSR.021.010.140 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 KST.DOP.010.060 MOD BBI 918 © Copyright BOERplay 9-6-2021 Revision:...
  • Page 26 A ( 1 : 5 ) Type Progr. Volgnr. Bew. Rev. Benaming Opmerking Schroef Assy 5 x 50 - RVS A2-70 Borgmoer M10 - RVS A2-70 Slotbout M10 x 120 - RVS A2-70 SLUITRING Donut zwart Beschermdop M10-M12 Beschermdop M10-M12 Dop zwart Voetplaat 100 x 100...
  • Page 27 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 912 © Copyright BOERplay 5-11-2020 Revision: A...
  • Page 28 1 / 1 Detail A (4x) ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 SMD.BBI.602 MOD BBI 912 © Copyright BOERplay 5-11-2020 Revision: A...
  • Page 29 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 915 © Copyright BOERplay 12-1-2021 Revision: A...
  • Page 30 1 / 3 SMD.BBI.612 Detail A (1x) BSR.023.010.035 BSR.023.010.035 KST.DON.010.060 KST.DON.010.060 BSR.030.010.002 BSR.030.010.002 BSR.010.010.010 BSR.010.010.010 KST.DOP.010.060 KST.DOP.010.060 SME.BBI.049.320 BSR.023.010.035 BSR.023.010.035 OPE.BBI.283.xxx BSR.010.010.010 BSR.023.010.035 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 BSR.030.010.002 BSR.030.010.002 OPE.BBI.283.xxx SMD.BBI.612 BSR.010.010.010 BSR.010.010.010 SME.BBI.049.320 MOD BBI 915 © Copyright BOERplay 12-1-2021 Revision: A...
  • Page 31 2 / 3 Detail B (4x) BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 BSR.030.010.002 BSR.021.010.140 KST.DOP.010.060 KST.DON.010.060 BSR.010.010.010 KST.DOP.010.060 BSR.021.010.140 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 MOD BBI 915 © Copyright BOERplay 12-1-2021 Revision: A...
  • Page 32 3 / 3 Detail C (2x) ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 MOD BBI 915 © Copyright BOERplay 12-1-2021 Revision: A...
  • Page 33 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 917 © Copyright BOERplay 9-6-2021 Revision: A...
  • Page 34 1 / 2 ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 OPE.BBI.558.072 OPE.BBI.558.072 MOD BBI 917 © Copyright BOERplay 9-6-2021 Revision: A...
  • Page 35 2 / 2 A (2x) Detail A (4x) BSR.010.010.010 BSR.030.010.002 KST.DON.010.060 BSR.030.010.002 BSR.021.010.140 KST.DOP.010.060 BSR.010.010.010 KST.DON.010.060 BSR.021.010.140 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 KST.DOP.010.060 MOD BBI 917 © Copyright BOERplay 9-6-2021 Revision: A...
  • Page 36 Manuel de montage - module MOD.BBI.047.A MOD.BBI.047.B MOD.BBI.047.V BSR.014.005.052 BSR.014.005.052 BSR.014.005.052 KST.LAM.013.006 KST.LAM.013.006 KST.LAM.013.006 OME.KAP.100.524 OME.KAP.100.204 OME.KAP.100.204 OME.VRB.903.VZP OME.VRB.903.VZP OME.VRB.903.VZP S.BBI.056.R S.BBI.056.A S.BBI.056.B MOD.BBI.047.D MOD.BBI.047.U BSR.002.005.050 BSR.002.005.050 BSR.002.005.070 BSR.002.005.070 OME.KAP.100.204 OME.KAP.100.204 OME.VRB.903.VZP OME.VRB.903.VZP S.BBI.056.H S.BBI.056.K © Copyright BOERplay 12-4-2021 Revision: MOD BBI 047 x...
  • Page 37 Aluminium bleu Aluminium noir Bois 70 mm KST.LAM.013.006 BSR.002.005.070 OME.KAP.100 OME.KAP.100 Glue NL Lijm DE Kleber ES Pegamento 50 mm FR Colle ø5mm ø3mm x 30 BSR.002.005.050 BSR.014.005.052 18 mm OME.VRB.903.VZP OME.VRB.903.VZP MOD BBI 047 x © Copyright BOERplay 12-4-2021 Revision:...
