decoflame URBAN 104A Instruction Manual

Advertisement

Quick Links

HANGING FIREPLACE, MODEL:

CONTENTS :
 Hanging fireplace installation .....................p. 3
 Burner installation .......................................p. 3
 Burner ...........................................................p. 3
 Combustible .................................................p. 3
 Instructions ..................................................p. 4
-
-
-
-
-
 Cleaning the burner ....................................p. 5
Cleaning the fireplace .................................p. 5
Warranty....................................................p.6




























110 rue Robinson Sud, Granby  (Quebec)  J2G 7L4
Tel. : (450) 372-8008  Fax : (450) 372-8009
www.decoflame.ca
.
p. 2


















Read carefully before using your fireplace.
URBAN 104A



Please note your model & serial numbers here:


_______________________________


Model number


_______________________________


Serial number


_______________________________


Purchase date







Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the URBAN 104A and is the answer not in the manual?

Questions and answers

Summary of Contents for decoflame URBAN 104A

  • Page 1     110 rue Robinson Sud, Granby  (Quebec)  J2G 7L4  Tel. : (450) 372‐8008  Fax : (450) 372‐8009  www.decoflame.ca     HANGING FIREPLACE, MODEL:    URBAN 104A   CONTENTS :     Safety  instructions ……………..……………..… p. 2  Hanging fireplace installation …………………p. 3   Burner installation .………………………………..p. 3   Burner ………………...…………..………………….p. 3   Combustible …………………...…………………….p. 3   Instructions …………………………..……………p. 4  ‐ General rules  ‐ Filling  ‐ Lighting  ‐ Extinguishing  ‐ While using   Cleaning the burner ...……………………………p. 5   Cleaning the fireplace …………….……………..p. 5  ...
  • Page 2 Keep these instructions for future reference.    SAFETY INSTRUCTIONS  Read and follow the below instructions before using this device.    Not respecting the rules may cause serious injury (especially burns) for the user and others nearby, as  well as becoming a fire hazard.   decoflame  The  » fireplace is for decorative purposes only, and not to be used as your main heat  «  source.   Keep children and pets away while operating the fireplace, especially while lighting it up.   Caution! If your wall is covered with wallpaper, wood varnish ADD PLYWOOD TO COVER   Any furniture, curtains or other flammable materials must be located at a safe and secure distance  from the unit.    Ensure that there is sufficient air circulation in the room.   Never use an unvented decorative device in areas where flammable vapours or gas may be present.    Fasten the device on to the wall according to  the instructions.   Do not cover the fireplace; do not place any material or clothes on the fireplace.   Never light the combustible fuel in a burner that is not properly positioned.   decofuel  Only use  »  combustible fuel in your fireplace.  «   Never use any fuel other than the fuel specifically identified for use in an unvented decorative  appliance.  Never use gasoline, solvents, methylated or burning alcohol, thinner, ethanol gel, etc.    The use of an ethanol gel is strictly prohibited since this will render your tank unusable. ...
  • Page 3  Never use the unvented decorative appliance in areas where flammable vapours or gas may be  present.   Risk of Indoor Air Pollution – Use the unvented decorative appliance only in a well‐ventilated area and  with doors of adjacent rooms open. Do not obstruct air flow to the fuel holder box by piling logs over  the fuel holding box or in any other way with any other material.  People with breathing problems  should consult a physician before using the unvented decorative appliance.    The following or equivalent information for provision of combustion and ventilating air for unvented  decorative appliances: ''In a house of typical construction, that is, one that is not of unusually tight  construction due to heavy insulation and tight seals against air infiltration, an adequate supply of air  for combustion and ventilation is provided through infiltration.  The unvented decorative appliance    should not be used in a small room where less than 5.7 m  (200 ft of air space is provided for each  1000 Btu per hour of the unvented decorative appliance rating (considering the maximum burner  adjustment).  Do not use the unvented decorative appliance in a bathroom, a room where sleeping  accommodation is provided or any other small room.   Make sure that the shut off device works properly before lighting.      INSTALLATION OF THE HANGING FIREPLACE AND BURNER     The model URBAN 104A  is wall‐mounted.    A horizontal support and two vertical supports are provided with the fireplace.   Determine the location of your fireplace. It must be located at a minimum of 12’’ above the floor, at a  minimum of 24’’ from the ceiling, and allow a clear distance of 12’’from the right and left edge of the  unit.    .  To attach the hanging support, refer to the drawing for installation  Locate 2 wall studs (obligatory), that are at 16’’ center to center.   Attach the horizontal support (no 1) using a bubble level tool with 2 wood screws no.12 x 1 ½’’ (no.3). ...
  • Page 4         COMBUSTIBLE    decofuel  Only use  » liquid fuel.  «   CAUTION: DO NOT USE PAPER, NEWSPAPERS, STRAW, KINDLING WOOD OR ANY OTHER FLAMMABLE  PRODUCT TO START A FIRE.   The combustible fuel is a highly flammable product.  It should be kept away from any heat sources.   Never place in direct sunlight.  Do not store or carry fuel in a plastic or metal container that is not  designated for this purpose.  Never store fuel in the same location as the fireplace.  Keep it in a safe  place and keep it away from children.   In case of ingestion, inhalation and/or contact with eyes or skin, urgently contact the poison control  centre or consult a Doctor.        INSTRUCTIONS    Read and follow the instructions in their entirety before using the fireplace.    Never add fuel when the fireplace is functioning, wait until the tank and the fireplace has cooled (wait at least  15 minutes) before refilling.     GENERAL RULES :    Only use the fireplace according to these instructions.   Do not use the fireplace in a bathroom or any other small room.   Minimum room limitations: 1 000 ft  .  ...
  • Page 5  The flames will reach their maximum height within 15 to 30 minutes, depending on the combustible  fuel temperature.  During this period, a slight odour may appear. If necessary, air out the room for a  few minutes.    Let the fire burn until all of the fuel has been depleted. You can extinguish the fire at all times simply by  completely closing the burner.  If you have to relight the fireplace when the fuel is still hot, be very  careful as the gas residue is likely to cause a large flame.  Do not try to extinguish the flames with an  object other than the designated trap.   Keep children and pets away while operating the fireplace and especially while lighting it up. Never add  fuel if the fireplace is in operation, wait until the burner and the fireplace have cooled before refilling.   Do not touch the fireplace or the burner while it is in operation: serious burns may occur.      EXTINGUISHING :    Keep the glass doors closed.   Pull the trap door completely closed.        WHILE USING :    Constantly monitor the device as soon as the fire has been started.   Have class B fire extinction devices nearby.   In case of a burn, call the nearest hospital.   Consult a Doctor if in doubt of any severe burn.   Igniting the fireplace implies that you have carefully read and will follow these directions.          CLEANING THE BURNER   ...
  • Page 6   GARANTIE LIMITÉE    decoflame  garantit à l’aquéreur original (vente au détail) que ce produit ne présente pas de  défauts de matière ou de main d’œuvre, et s’engage à réparer ou à remplacer (à la discrétion de  decoflame) gratuitement tout produit défectueux pendant deux ans à compter de la date de  l’achat.   Une preuve d’achat, sous forme de reçu de vente daté, ticket de caisse, etc. indiquant le numéro de  série et le modèle de votre produit sera exigée avant toute intervention de nos concessionnaires sur le  produit sous garantie. Vous devrez obligatoirement assurer à vos frais la livraison ou l’expédition du  produit en cas de réparations sous garantie, ainsi que la reprise ou le retour du produit après  réparation.      decoflame We wish you the best moments with your   fireplace…  »  «                                   ...
  • Page 7     INSTALLATION OF THE HANGING FIREPLACE AND BURNER: URBAN 104A                        7 ...
