Koplus KOLO DUO Assembly Instructions Manual

Hide thumbs Also See for KOLO DUO:

Advertisement

Quick Links

Download this manual
KOLO
DUO
Assembly
Instructions
acoustic collection - kolo duo
[left hand open - outlet on right - without furniture - type A/B]
koplus b.v. | koplus.eu
hello@koplusbrand.com
version
231206

Advertisement

loading
Need help?

Need help?

Do you have a question about the KOLO DUO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Koplus KOLO DUO

Summary of Contents for Koplus KOLO DUO

  • Page 1 KOLO Assembly Instructions acoustic collection - kolo duo [left hand open - outlet on right - without furniture - type A/B] koplus b.v. | koplus.eu hello@koplusbrand.com version 231206...
  • Page 3 24W. The power cord fuse is set at 7amp to prevent overloading. Kolo Duo comes with 2 AC power outlets and 2 USB charging outlets. DO NOT plug in any electronic devices that uses over 5amp.
  • Page 5 90 Degree Drill Adaptor Rubber Mallet Ratchet Wrench - Metric Socket Phillips Screw Driver Allen Key Set Page 03 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 6 M4x40mmL Nº1-10 Nº6 Nº1-11 Nº2-1 Screw Cover Double Bottom Socket Cover Tile Floor Corner Page 04 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 7 Horizontal Frames Horizontal Frame Covers Nº9-2 Nº9-1 Nº10 Vertical Frame Covers Vertical Frames Frame Corners Page 05 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 8 Center Floor PET Tile Side Floor PET Tiles Top Side Panels Nº17 Bottom Side Panels Page 06 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 9 A / B Spring Washer M8 x 50 M8 x 25 M4 x 25 Page 07 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 10 Dowel Pin M8 x 50 Nº2-1 Floor Corner Nº6 Nº2-2 Floor Floor Corner + Electric Page 08 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 11 Nº4 Side Wall + Electric Nº5 Side Wall M8 x 50 M8 x 50 Page 09 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 12 M8 x 50 Nº3-1 Roof Corner Nº7 Roof Nº3-2 Roof Corner + Electric Nº1-3 Dowel Pin Page 10 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 13 Step 4. M8 x 50 M8 x 50 Page 11 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 14 Step 5. Spring Washer Nº8-1 Horizontal Frame M8 x 25 Page 12 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 15 Step 6. Spring Washer M8 x 25 Nº9-1 Vertical Frame Nº10 Frame Corner Page 13 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 16 Step 7. Nº11 Nº12 Nº11 Side Glass Back Glass Side Glass Page 14 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 17 Step 8. Nº9-1 Vertical Frame Nº10 Frame Corner Nº8-2 Horizontal Frame Cover Page 15 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 18 Step 9. Spring Washer M8 x 25 Page 16 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 19 Nº10 Frame Corner Nº9-2 Vertical Frame Cover Nº9-2 Vertical Frame Cover Nº10 Frame Corner Page 17 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 20 Step 11. Spring Washer M8 x 25 Page 18 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 21 Step 12. Nº8-1 Spring Washer Horizontal Frame M8 x 25 Page 19 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 22 Step 13. Spring Washer M8 x 25 Nº8-1 Horizontal Frame Nº10 Frame Corner Page 20 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 23 M4x40mmL Nº1-6 Rose INTERIOR EXTERIOR Nº1-7 Interior Handle Nº1-5 Nº1-4 Mounting Plate Exterior Handle Page 21 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 24 Step 15. Nº11 Nº13 Nº11 Side Glass Glass Door Side Glass Page 22 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 25 Horizontal Frame Nº10 Frame Corner Nº8-1 Nº10 Nº8-2 Horizontal Frame Frame Corner Horizontal Frame Cover Page 23 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 26 Step 17. Spring Washer M8 x 25 Nº8-1 Horizontal Frame Page 24 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 27 Nº10 Frame Corner Nº9-2 Nº9-2 Vertical Frame Cover Nº10 Vertical Frame Cover Frame Corner Page 25 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 28 Step 19. Spring Washer M8 x 25 Nº8-1 Horizontal Frame Page 26 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 29 M4 x 25 Nº1-10 Screw Cover Double Nº1-9 Screw Cover Single Nº1-9 Screw Cover Single Page 27 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 30 8 glides, levelling the Duo so that the seams and shadow-lines are square Page 28 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 31 Side Floor PET Tiles Nº14 Nº6 Nº1-11 Center Floor PET Tile Bottom Socket Cover Tile Page 29 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 32 Step 23. Nº16 Top Side Panels Nº17 Bottom Side Panels Page 30 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
  • Page 33 Step 24. Nº1-2 Tool Kit: Power Cord Page 31 Koplus B.V. | Kolo Duo | Left Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instructions...
