KOLO
DUO
[right hand open - outlet on right - without furniture - type A]
Assembly
Instructions.
acoustic collection - kolo duo
koplus b.v. | koplus.eu
info@koplusbrand.com
version
120919

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOLO DUO and is the answer not in the manual?

Questions and answers

Related Manuals for Koplus KOLO DUO

Summary of Contents for Koplus KOLO DUO

  • Page 1 KOLO Assembly Instructions. acoustic collection - kolo duo [right hand open - outlet on right - without furniture - type A] koplus b.v. | koplus.eu info@koplusbrand.com version 120919...
  • Page 3 Right Hand Open Door Outlet on Right No Furniture Type A/B Plug...
  • Page 4 Before we start, here are some things to be aware of: This is the assembly instruction for right hand opening door with no stool. A packaged Duo unit weights 550 kg and will require 2-3 persons to install. It takes an average of 45 - 90 min to install Duo.
  • Page 5 90 Degree Drill Adaptor Rubber Mallet Ratchet Wrench - Metric Socket Phillips Screw Driver Allen Key Set Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 03...

  • Page 6: Table Of Contents

    Side Wall + ElectricTile Side Wall Nº8-1 Nº6-1 Nº6-2 Nº7 Bottom Bottom Center Tile Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 04...
  • Page 7 Vertical Frame Covers Frame Corners Narrow Glass Walls Nº13 Nº12 Glass Door Glass Wall Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 05...

  • Page 8: Tool Kit: Screw Pack X1

    M8 x 35 M8 x 50 M8 x 25 Spring Washer M4 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 06...

  • Page 9: Bottom X1

    Nº2-1 Bottom Corners M8 x 35 Nº2-1 Bottom Corners Nº6-1 Nº2-1 Bottom Bottom Corners Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 07...

  • Page 10: Nº4

    Step 2. Nº4 Nº5 Side Wall + Electric Side Wall M8 x 35 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 08...

  • Page 11: Nº7

    Nº3-1. Nº3-1 Top Corners Nº3-1 Top Corners Nº7 Nº3-1 Top Corners M8 x 35 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 09...
  • Page 12 Use inner carton buffers or any platform to slightly prop up the unit. Page 10 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction...
  • Page 13 M8 x 35 power cords are properlly connected before proceeding. Nº1-2 Tool Kit: Power Cord Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 11...
  • Page 14 Step 6. Nº8-1 Horizontal Frame Spring Washer M8 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 12...

  • Page 15: Vertical Frame Covers X4

    Step 7. M8 x 25 Spring Washer Nº9-1 Vertical Frame Nº10 Frame Corner Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 13...

  • Page 16: Nº12

    Make sure that the stickers are facing outwards and the arrows are pointing towards the center glass wall or glass door. Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 14...

  • Page 17: Horizontal Frame Covers

    Step 9. Nº9-1 Vertical Frame Nº10 Frame Corner Nº8-2 Horizontal Frame Cover Page 15 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction...
  • Page 18 Step 10. Spring Washer M8 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 16...
  • Page 19 Nº10 Frame Corner Nº8-2 Horizontal Frame Cover Nº8-1 Horizontal Frame Nº9-1 Vertical Frame Cover Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 17...
  • Page 20 Step 12. Spring Washer M8 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 18...
  • Page 21 Step 13. Nº8-1 Horizontal Frame Spring Washer M8 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 19...
  • Page 22 Step 14. M8 x 25 Spring Washer Nº9-1 Vertical Frame Nº10 Frame Corner Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 20...

  • Page 23: Nº13

    Make sure that the stickers are facing outwards and the arrows are pointing towards the center glass wall or glass door. Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 21...
  • Page 24 Step 16. Nº9-1 Vertical Frame Nº10 Frame Corner Nº8-2 Horizontal Frame Cover Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 22...
  • Page 25 Step 17. Spring Washer M8 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 23...
  • Page 26 Nº10 Frame Corner Nº8-2 Horizontal Frame Cover Nº8-1 Horizontal Frame Nº9-1 Vertical Frame Cover Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 24...
  • Page 27 Step 19. Spring Washer M8 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 25...
  • Page 28 Step 20. M4 x 25 Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 26...
  • Page 29 Step 21. Nº2-3 Bottom Side Tiles Nº6-2 Bottom Center Tiles Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 27...
  • Page 30 Step 22. Nº3-2 Top Finishing Panels Nº2-2 Bottom Finishing Panels Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 28...
  • Page 31 Make sure to start from one end and slowly work your way to the other end. Koplus B.V. | Kolo Duo | Right Hand Open Door | Outlet on Right | Without Furniture | Type A/B Plug | Assembly Instruction Page 29...
