Wen 10714 Instruction Manual

INSTRUCTION MANUAL
THANKS FOR
REMEMBERING
INSTRUCTION MANUAL

SPECIFICATIONS

Model
Magnetic Force
Mounting Holes
Base
Height (Base to Top of Pole)

KNOW YOUR MAGNETIC BASE

Fig. 1
7
WARNING! If you use a pacemaker, do not use the magnetic base. The magnetic force on the magnetic
base may cause your pacemaker to malfunction.
V. 2022.11.14
MAGNETIC BASE
Compatible with 10702 and 10703 (1-Inch Dial Indicator)
10714
176 lbf (80kg)
3/8 Inch (9.53mm) / 6mm / 8mm / 4mm (with bushing)
2-1/2 in. x 2 in. x 2-1/8 in.
63.5mm x 50.8mm x 54mm
14-1/2 Inches
1. Magnetic Base
2. Lever
6
3. Pole
4. Clamping Knob
5. Fine Adjustment Knob
5
6. Dial Indicator Clamp Knob
7. Dial Indicator Mounting Holes
8. Bushing (stored in the dial indicator mounting holes)
3

FEATURES

4
• The magnetic base is a support for dial indicators, and can be
used in multiple measuring positions.
3 • The device can be mounted horizontally, vertically, or upside
down with the magnetic base.
• Mount to flat surfaces using the back or bottom of the base, and
mount to cylindrical surfaces with the base v-groove.
• Fine adjustment knob for performing precise adjustments to the
2
measuring device's orientation and zero point.
1
• Quickly reposition the dial indicator with a simple turn of the
clamping knob.
MODEL 10714
