Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of
safe, reliable service.
MULTI-PURPOSE
PLANER STAND
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # 6588, 6588T
bit.ly/wenvideo
(M-F 8AM-5PM CST)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6588 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen 6588

Summary of Contents for Wen 6588

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Product Specifications

    Specific Rules for the Planer Stand Know Your Planer Stand Assembly Operation Exploded View and Parts List Warranty PRODUCT SPECIFICATIONS Model Number: 6588, 6588T Stand Height: 29.3 in. Tabletop Capacity: 220 lbs Tabletop Dimensions: 23.8 x 20.8 in. Shelf Capacity:...
  • Page 3 INTRODUCTION Thanks for purchasing a WEN Planer Stand. We know you are excited to mount your favorite planer onto the stand and roll it around your workshop, but first, please take a moment to read through this manual. It contains important information regarding the safe operation and assembly of this product.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
  • Page 5 KNOW YOUR PLANER STAND Make sure all the following parts are accounted for before discarding the packaging. If any part is missing or broken, contact our customer service at 1-800-232-1195. COMPONENTS 1. Tabletop 8. M8-1.25X60 Bolt 2. Shelf 9. M8 Washer 3.
  • Page 6 ASSEMBLY STEP 1: INSTALL THE LEGS ONTO THE TABLE TOP 1. Place the table top on the floor, install one leg to a corner of the table top using four carriage bolts, M8 washers and M8-1.25 hex nuts. Repeat with all four legs. Finger tighten the bolts to leave room for adjustments when attaching the base.
  • Page 7 ASSEMBLY STEP 3: INSTALL THE PEDAL ASSEMBLY 3. Attach the pedal assembly to the base using two M8- 1.25X60 hex bolts, M8 washers and M8-1.25 hex nuts. The wheel should be positioned inside the base assembly. Pedal Assembly x 1 M8-1.25X60 Bolts x 2 M8 Washers x 2 M8-1.25 Hex Nuts x 2...

  • Page 8: Operation

    ASSEMBLY STEP 5: ATTACH THE POWER TOOL 5. Now is the moment you’ve been waiting for. Unplug and Operating bring over your favorite power tool. Make sure the weight Direction does not exceed the stand capacity and the tool is wider than it is tall.

  • Page 9: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST Part Number Description 6588-001 Tabletop 6588-002 6588-003 Shelf 6588-004 Shelf Bracket 6588-005 Base Assembly 6588-006 Pivot Wheel Bracket 6588-007 Foot Pedal 6588-008 Shaft 6588-009 Spacer 6588-010 Foot 6588-011 Pedal Shaft 6588-012 M12 Washer 6588-013 Pivot Wheel...
  • Page 10 EXPLODED VIEW AND PARTS LIST...

  • Page 11: Limited Two-Year Warranty

    LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
  • Page 12 THANKS FOR REMEMBERING...
