Freelap Tx Gate Pro Manual

Further information
Battery and battery life
The Tx Gate Pro has 2 LR6 (AA) batteries (supplied), with a battery life of 15'000
starts.
• Low battery indicator: When the battery becomes low, the PWR led of the Tx Gate Pro
turns red.
• To change the batteries: Unscrew the 4 screws on the back of the device using a
screwdriver. Remove the cover and the gasket. Remove used batteries, and insert 2
new LR6 (AA) batteries. Put back the gasket, cover, and screw back the 4 screws.
Technical sheet
• Weight: 320 g
• Dimensions: 60 x 70 x 125 mm - Stick lenght: 410 mm
• Compatibility: FxChip / FxChip BLE
• Transmitter with 1 code: START
• Accuracy: 1/100 of a second
• Detection field: 1.5 meters
• Minimum time between 2 transmitters: 0.7 second
• Batteries: 2 x LR6 (AA)
• Life cycle: 15'000 starts
• Materials: Fiberglass stick
• Water resistance: IP67
• Operating temperatures: -20°C to +50°C
Technical support
Find our FAQ (Frequently Asked Questions), as well as other manuals and user guides,
on our website at: www.freelap.com/support
If you cannot find the answers to your questions, please contact your Freelap dealer.
Find the list of Freelap dealers at: www.freelap.com/freelap-contact
After-sales service & warranty
The Tx Gate Pro is guaranteed 2 years. If you have any questions or if you need
assistance with your device, please contact your Freelap dealer.
FREELAP SA
Av. D.-Jeanrichard 2A CH-2114 Fleurier – Switzerland
+41 32 861 52 42 - www.freelap.com
@freelap
Tx Gate Pro
Tx Gate Pro
PWR
V211223
