Freelap TX GATE PRO Instructions For Use

3
FURTHER INFORMATION
BATTERY AND BATTERY LIFE
Your Tx Gate Pro has 2 LR6 (AA) batteries (supplied), with a battery life
of 15'000 starts.
> Low battery indicator: When the battery becomes low, the "PWR" led
of your Tx Gate Pro turns red.
> To change the batteries: Unscrew the 4 screws on the back of the
device using a screwdriver, then remove the cover and the gasket.
Remove used batteries, and insert 2 new LR6 (AA) batteries. Put back the
gasket, cover, and screw back the 4 screws.
TECHNICAL SHEET
• Weight: 320 g
• Dimensions: 60 x 70 x 125 mm
• Compatibility: FxChip / FxChip BLE
• Transmitter with 1 code: Start
• Accuracy: 1/100 of a second
• Detection field: 1.5 meters
• Minimum time between 2 transmitters: 0.7 second
• Batteries: 2 x LR6 (AA)
• Life cycle: 15'000 starts
• Materials: Fiberglass rod
• Water resistance: 3ATM
• Operating temperatures: -20°C to +50°C
TECHNICAL SUPPORT
Our FAQ (Frequently Asked Questions), as well as other manuals and user
guides, can be found on our website at:
http://www.freelap.ch/support/
If you cannot find the answers to your questions, please contact your
Freelap dealer. Find the list of Freelap dealers at:
http://www.freelap.ch/freelap-contact/
AFTER-SALES SERVICE & WARRANTY
Your TX Gate Pro is guaranteed 2 years. If you have any questions or if
you need assistance with your device, please contact your Freelap
dealer.
www.freelap.ch
Follow Freelap on &
MADE BY FREELAP SA
Av. D.-Jeanrichard 2A
CH-2114 Fleurier – Switzerland
+41 32 861 52 42 - www.freelap.ch
TX GATE PRO
FREELAP START TRANSMITTER SPECIALLY
DESIGNED FOR SKIING.
INSTRUCTION FOR USE
