Freelap PowerUnit Manual

7. Trigger the start
• To trigger the start, make a loud sound (e.g. clap or gunshot) close to the transmitter
(within approx. 1m for an optimal detection).
• When the transmitter detects the sound signal, it instantly triggers the start of the
transponder timer. The green MIC led flashes to indicate that the start has been
triggered.
Further information
Battery and battery life
The PowerUnit has a 3.7V 5AH LiPo rechargeable battery.
• Low battery indicator: When the battery is low, the PWR led flashes red.
• Recharging the battery:
- Connect the USB port of the power cable (supplied) to a USB socket. Unscrew the
sealing cap from CHG port and connect the power cable to the CHG port.
- It is recommended to make complete charges (charging time: 10h).
- When the battery is fully charged, the device has a battery life of 50h.
- The PowerUnit has an automatic shutdown function (after 12h), to save the battery.
Technical sheet
• Weight: 700 g
• Dimensions: PowerUnit 75 x 140 x 25 mm / SpaceUnit: Diameter 65 cm
• Compatibility: FxChip / FxChip BLE
• Transmitter with 2 modes: Tx / Mic
• Transmitter with 3 codes: START / LAP / FINISH
• Detection field: 6 m
• Minimum time between 2 transmitters: 0,7 s
• Accuracy: 2/100 of a second
• Water resistance: IP67
• Operating temperatures: -20°C to +50°C
Technical support
Find our FAQ (Frequently Asked Questions), as well as other manuals and user guides,
on our website at: www.freelap.com/support
If you cannot find the answers to your questions, please contact your Freelap dealer.
Find the list of Freelap dealers at: www.freelap.com/freelap-contact
After-sales service & warranty
The PowerUnit & SpaceUnit are guaranteed 2 years. If you have any questions or if
you need assistance with your device, please contact your Freelap dealer.
FREELAP SA
Av. D.-Jeanrichard 2A CH-2114 Fleurier – Switzerland
+41 32 861 52 42 - www.freelap.com
@freelap
PowerUnit & SpaceUnit
V220623
